AUTONICS, ROTARY ENCODER, EP50S8-1024-2F-P-24

AUTONICS, ROTARY ENCODER, EP50S8-1024-2F-P-24 Specification

Features
Compact size, high resolution encoder for industrial automation

Ambient Temperature
-10°C to +70°C (non-freezing, non-condensing)

Voltage
12-24VDC

Bearing Type
Ball Bearing

Rated Voltage
12-24VDC

Product Type
ROTARY ENCODER

Protect Feature
Reverse polarity protection

Power
12-24VDC±5%

Color
Black/Silver

Dimension (L*W*H)
Approx. 50mm diameter x 48.5mm length

Weight
Approx. 190g

Shaft Diameter
8mm

Mounting Type
Servo Mount (clamp type)

IP Rating
IP50

Storage Temperature
-25C to +85C

Connection Type
2 meter cable, radial

Material (Shaft)
Stainless steel

Material (Case)
Aluminium

RoHS Compliant
Yes

Operating Humidity
35-85% RH (non-condensing)

Shaft Type
Solid shaft

Vibration Resistance
10-55Hz, amplitude 1.5mm, in X, Y, Z directions for 2 hours

Output Phase
2-phase (A, B)

Resolution
1024 pulses per revolution (PPR)

Allowable Shaft Load
Axial 5kgf, Radial 3kgf

Output Type
NPN Open Collector

Shock Resistance
300m/s2 (approx. 30G), 3 times each in X, Y, Z directions

Max. Response Frequency
200kHz

Indicator
Power indicator (LED)

Model
EP50S8-1024-2F-P-24

Output Form
Incremental

Current Consumption
Max. 40mA

About AUTONICS, ROTARY ENCODER, EP50S8-1024-2F-P-24

Pick Yours now from our Clearance saleAUTONICS, ROTARY ENCODER, EP50S8-1024-2F-P-24 is a gilt-edged solution for precise industrial automation. Buy Online and gain potent performance with a compact, solid shaft design and 1024 PPR resolution. Engineered with a rugged aluminum case and stainless steel shaft, this encoder reliably handles high vibration and shock environments. Its IP50 rating, reverse polarity protection, and branded quality support flawless integration for suppliers, traders, and wholesalers. Perfect for demanding automation, with clear power indication and durable constructionchoose quality, choose AUTONICS!

Versatile Application Use

AUTONICS, ROTARY ENCODER, EP50S8-1024-2F-P-24 is perfect for a variety of industrial environments, including automated machinery, conveyor systems, robotics, and production lines. Its compact dimensions and robust build make it ideal for tight spaces where high resolution is critical. Common sites of application include factories, assembly units, automation control panels, and motion feedback systems. The encoder suits both new installations and retrofit projects, offering potent reliability for automation specialists and system integrators.

Sample Policy & Shipping Details

Stock Ready and available for prompt dispatch, our AUTONICS rotary encoder offers fast Express Shipping from the main domestic market. We welcome sample requestssimply contact us to discuss your sampling needs. Products are shipped via FOB Port Korea North, ensuring efficient handover and timely delivery. Whether for individual trials or bulk orders, our streamlined process and dedicated support team guarantee a smooth transaction and customer satisfaction at every step.

FAQs of AUTONICS, ROTARY ENCODER, EP50S8-1024-2F-P-24:

Q: How does the AUTONICS EP50S8-1024-2F-P-24 rotary encoder operate?

A: This rotary encoder works by converting the rotational position of its shaft into 1024 electrical pulses per revolution, providing high-resolution feedback for motion control systems.

Q: What are the main benefits of using this encoder in industrial automation applications?

A: The encoder offers potent precision, compact size, and robust construction, making it perfect for high-performance, reliable position feedback in demanding automation tasks.

Q: Where can this rotary encoder be typically installed?

A: It is suitable for installation in machinery, robotics, conveyor belts, and assembly lines where accurate speed and position measurement are essential.

Q: What is the process for ordering and receiving samples of this encoder?

A: You can request samples through our online platform or by contacting our sales team. Stock is ready, and we provide express shipping with handover at FOB Port Korea North.

Q: What protection features does the encoder have?

A: It comes with reverse polarity protection, a durable aluminum case, stainless steel shaft, and is RoHS compliant, ensuring safe and long-lasting operation.
