OMRON ROTARY ENCODER 5VDC, E6B2-CWZ1X 1000P/R

OMRON ROTARY ENCODER 5VDC, E6B2-CWZ1X 1000P/R Specification

Ambient Temperature
Operating: -10C to +70C (no freezing or condensation)

Standard
RoHS Compliant

Rated Voltage
5VDC

Current Type
DC

Features
Incremental Rotary Encoder, High-resolution, Compact size, Shielded Cable

Sealed Type
IP50

Bearing Type
Ball bearing

Voltage
5VDC

Product Type
Rotary Encoder

Protect Feature
Reverse connection protection

Phase
2-Phase (AB, Z) Output

Power
5VDC

Color
Black

Dimension (L*W*H)
Diameter: 40mm, Length: 39.5mm (excluding shaft)

Weight
Approx. 200g

Shaft Diameter
6mm

Mounting Type
Servo Mount

IP Rating
IP50

Connection Method
Pre-wired

Pulses per Revolution
1000 P/R

Rotation Direction
Clockwise/Counterclockwise

Output Configuration
NPN Open Collector

Shock Resistance
1,000 m/s2, 3 times each in X, Y, Z directions

Vibration Resistance
10 to 55 Hz, Double Amplitude 1.5mm

Model Number
E6B2-CWZ1X

Shaft Type
Solid Shaft

Maximum Response Frequency
100 kHz

Cable Length
2 meters

Humidity Range
35% to 85% RH (no condensation)

About OMRON ROTARY ENCODER 5VDC, E6B2-CWZ1X 1000P/R

Experience instant savings and upgrade your automation with the OMRON ROTARY ENCODER E6B2-CWZ1X 1000P/R, a top-rated and best-seller in its category. Its inestimable precision, phenomenal durability, and imposing build make it the ideal choice for demanding industrial environments. This incremental rotary encoder boasts a high resolution of 1000 pulses per revolution, sturdy solid shaft, and robust IP50 sealing. Engineered for versatility, it features NPN open collector output, 5VDC operation, comprehensive shock/vibration resistance, and reverse connection protection. RoHS compliant, with a compact form and shielded two-meter cable.

Advantages and Versatile Applications of OMRON E6B2-CWZ1X

The phenomenal OMRON E6B2-CWZ1X 1000P/R rotary encoder provides inestimable accuracy for machinery alignment, motor feedback, robotics, and conveyor automation. Because of its imposing build quality and reliability, it is widely used by OEMs, automation engineers, and industrial system integrators. This versatile device adapts effortlessly across sectors such as manufacturing, packaging, and process control, empowering users to achieve superior operational performance and reduced downtime.

Delivery Schedules, Packaging, and Export Markets: OMRON E6B2-CWZ1X

Market value and supply consistency are assured with the OMRON E6B2-CWZ1X rotary encoder, offering secure packaging to maintain product integrity during transit. Delivery time typically ranges from 3 to 7 business days, depending on domestic mar or export requirements. The encoder is conveniently available for FOB shipment from major China ports, optimizing expenditure for both domestic and international clients seeking cost-efficient sourcing and reliable supply chains.

FAQ's of OMRON ROTARY ENCODER 5VDC, E6B2-CWZ1X 1000P/R:

Q: How does the OMRON E6B2-CWZ1X rotary encoder enhance industrial automation accuracy?

A: The OMRON E6B2-CWZ1X provides high-resolution feedback with 1000 pulses per revolution, enabling precise position and speed control in automated equipment, resulting in superior accuracy for machinery alignment and motion control.

Q: What are the primary usage scenarios for the OMRON E6B2-CWZ1X encoder?

A: This rotary encoder is commonly used in robotics, conveyor systems, motor feedback applications, and manufacturing automation where high-resolution incremental feedback and reliability are essential.

Q: When can buyers expect delivery after ordering the OMRON rotary encoder?

A: Typically, delivery is completed within 3 to 7 business days, depending on order quantity, stock availability, and location, either for domestic or international markets.

Q: Where can the OMRON E6B2-CWZ1X model be shipped from?

A: The encoder is supplied, traded, and wholesaled with shipments arranged FOB from leading Chinese ports, ensuring efficient export distribution.

Q: What benefit does the IP50 rating offer for users of this rotary encoder?

A: The IP50 rating provides reliable protection against dust and moderate environmental factors, ensuring stable performance in indoor industrial applications without frequent maintenance.

Q: How does the reverse connection protection feature benefit users?

A: Reverse connection protection guards the encoder against wiring mistakes, significantly reducing the risk of operational failure or device damage during installation.
