ORBITAL INCREMENTAL ENCODER,ISC5806-001G-1000BZ3-5-24L

ORBITAL INCREMENTAL ENCODER,ISC5806-001G-1000BZ3-5-24L Specification

Ambient Temperature
-20C to +85C

Voltage
5-24 VDC

Current Type
DC

Sealed Type
IP65 sealing

Features
Incremental encoder, High precision, Robust build, Easy installation

Bearing Type
Ball bearing

Standard
CE, RoHS compliant

Rated Voltage
5-24 VDC

Product Type
Incremental Encoder

Protect Feature
Encapsulated electronics, surge protection

Color
Black/Silver

Dimension (L*W*H)
Approx. 58 mm diameter x 45 mm length

Weight
Approx. 280 grams

Shaft Diameter
10 mm

Mounting Type
Clamp flange mount

IP Rating
IP65

Pulses Per Revolution (PPR)
1000

Storage Temperature
-25C to +90C

Insulation Resistance
>100M at 500 VDC

Dielectric Strength
500 VAC, 60 s

Max Response Frequency
100 kHz

Output Signal
A/B/Z quadrature channels

Model
ISC5806-001G-1000BZ3-5-24L

Output Type
Line Driver (RS422 compatible)

Shaft Loading (axial/radial)
20N/30N

Operating Humidity
35% to 85% RH (non-condensing)

Housing Material
Aluminum

Connection Type
Radial cable, 2 m length

About ORBITAL INCREMENTAL ENCODER,ISC5806-001G-1000BZ3-5-24L

Discover the praiseworthy ORBITAL INCREMENTAL ENCODER, ISC5806-001G-1000BZ3-5-24L-now available at an affordable, price cut rate. This peerless solution is engineered for precision, boasting 1000 PPR with robust Line Driver (RS422 compatible) outputs to ensure excellent signal integrity. Its durable aluminum build, IP65 sealing, and surge-protected, encapsulated electronics make installation effortless and reliable, even in challenging environments. Setting an industry standard for excellence, this encoder is CE and RoHS compliant, designed for long-term, professional performance. Benefit from the latest advances and competitive pricing, sourced directly from top Chinese suppliers, traders, and wholesalers.

Versatile Usage and Competitive Edge

The ORBITAL INCREMENTAL ENCODER, ISC5806-001G-1000BZ3-5-24L is easy to integrate with various automation and positioning systems. Trusted for general use across industrial sectors, its peerless accuracy and robust IP65 build offer distinct advantages-ensuring a long lifespan and minimal maintenance. Simple clamp flange mounting and a radial cable design streamline application. Its high response frequency, surge protection, and compatibility with standard interfaces set it apart as a dependable, competitive choice for your precise motion control needs.

Domestic Market Focus, Sampling & Packaging

We offer the ORBITAL INCREMENTAL ENCODER at a highly competitive list price, tailored for the main domestic market. Interested buyers can request samples based on our clear sample policy, ensuring informed purchasing decisions. Each unit is meticulously packaged to secure its condition during transit and storage, maintaining product excellence. Attractive rates and flexible supply options are available for bulk orders, supporting wholesalers and traders seeking reliability and value from a leading supplier in China.

FAQ's of ORBITAL INCREMENTAL ENCODER,ISC5806-001G-1000BZ3-5-24L:

Q: How does the ORBITAL INCREMENTAL ENCODER, ISC5806-001G-1000BZ3-5-24L ensure reliable performance in industrial environments?

A: The encoder features an IP65 sealing standard, aluminum housing, surge-protected encapsulated electronics, and operates efficiently within wide temperature and humidity ranges to provide reliability in challenging settings.

Q: What specific advantages does the Line Driver (RS422 compatible) output offer?

A: This output type ensures high signal integrity over long distances and in noisy environments, supporting accurate A/B/Z quadrature channel outputs for reliable position and speed feedback.

Q: Where is the product primarily available and who supplies it?

A: The encoder is primarily offered in the domestic Chinese market, supplied by reputable traders, wholesalers, and suppliers with competitive list prices and flexible rates.

Q: When can I request a product sample and what is included in the packaging?

A: Product samples are offered according to our sample policy; each encoder is securely packaged to prevent damage, including all necessary documentation for installation and usage.

Q: What is the process for installing the ORBITAL INCREMENTAL ENCODER?

A: Installation is straightforward using the clamp flange mount and radial cable connection. The robust design and included mounting instructions ensure quick and accurate setup.

Q: How does the ISC5806-001G-1000BZ3-5-24L benefit process automation applications?

A: With its high 1000 PPR resolution, excellent build, and reliable signal output, the encoder enhances system accuracy, reduces maintenance downtime, and delivers peerless value for automation projects.
