ORBITAL INCREMENTAL ENCODER, ISC3806-001G-200-ABZ1-5-30K

ORBITAL INCREMENTAL ENCODER, ISC3806-001G-200-ABZ1-5-30K Specification

Standard
IEC standard

Rated Voltage
5-30V DC

Cooling Method
Air

Features
200 PPR, ABZ, Push pull output, compact size, robust build, reverse polarity protection

Ambient Temperature
-20C to +85C

Voltage
5-30V DC

Starting Type
Direct

Efficacy
High Signal Precision

Sealed Type
Sealed

Noise Level
Low

Current Type
DC

Bearing Type
Ball bearing

Product Type
Incremental Encoder

Protect Feature
Short-circuit and over-voltage protection

Phase
Single phase/Three phase (depends on wiring)

Speed
6000 RPM max

Color
Black/Silver

Dimension (L*W*H)
38 mm x 38 mm x 60 mm

Weight
Approx. 350 g

Shaft Diameter
6 mm

Mounting Type
Clamp or Servo Mount

IP Rating
IP65

Pulse per Revolution (PPR)
200

Shaft Type
Solid Shaft

Shock Resistance
980 m/s2, 6 ms

Rotational Direction
Bidirectional, indicated by AB phase sequence

Insulation Resistance
>100 M at 500V DC

Output Connector
Radial cable outlet

Cable Length
2 meters (standard)

Model Number
ISC3806-001G-200-ABZ1-5-30K

Vibration Resistance
10~200 Hz, 1.5 mm double amplitude

Output Signal
ABZ (Quadrature plus index)

Response Time
Less than 1 microsecond

Output Circuit
Push-pull (Line Driver available on request)

About ORBITAL INCREMENTAL ENCODER, ISC3806-001G-200-ABZ1-5-30K

Experience phenomenal precision with the ORBITAL INCREMENTAL ENCODER, Model ISC3806-001G-200-ABZ1-5-30K. This paragon of engineering delivers 200 pulses per revolution, a robust solid shaft, and a push-pull ABZ output for exceptional signal quality. Protected by IP65 sealing, it endures both harsh environments and rigorous use. Available at an unbeatable price during our exclusive sale-limited stock ensures rapid turnaround. Trust this encoder's high-speed response and reliability for demanding automation and manufacturing applications. Secure yours before stock vanishes!

Distinguished Features and Versatile Uses

The ORBITAL INCREMENTAL ENCODER ISC3806-001G-200-ABZ1-5-30K boasts exceptional build quality with robust IP65 sealing, 200 PPR for optimal signal resolution, and superior shock and vibration resistance. Its compact design suits industrial automation, CNC machinery, robotics, and conveyor systems. Engineers, system integrators, and OEMs rely on this encoder for high-precision control and position feedback in complex systems, making it a trusted choice across diverse industrial landscapes.

Packaging, Supply, and Swift Handover

Each encoder is securely packed to prevent damage during transit, ensuring product integrity upon arrival. With substantial supply ability, bulk and custom orders can be accommodated quickly. We provide a straightforward handover process upon payment confirmation. The asking price is transparent and competitive, with express shipping options available worldwide for urgent requirements. Clients may process payments via major accepted terms, ensuring a hassle-free procurement experience for every order.

FAQ's of ORBITAL INCREMENTAL ENCODER, ISC3806-001G-200-ABZ1-5-30K:

Q: How does the ORBITAL INCREMENTAL ENCODER ensure high signal precision?

A: The encoder utilizes a 200 PPR solid shaft design with ABZ quadrature output and push-pull circuitry, allowing for accurate and rapid signal transmission with minimal error and less than 1 microsecond response time.

Q: What environments is the ISC3806-001G-200-ABZ1-5-30K suitable for?

A: Thanks to its IP65-rated sealed construction, strong shock and vibration resistance, and wide temperature range (-20C to +85C), the unit performs reliably in harsh industrial environments, including automation, robotics, and CNC machinery.

Q: When should I consider choosing this model for my application?

A: Select this encoder when your application demands high durability, precise positional feedback, and robust protection features. Its versatility makes it ideal for automated manufacturing, conveyor control, and motion detection projects.

Q: Where can I purchase the ISC3806-001G-200-ABZ1-5-30K encoder?

A: This model is available through reputable suppliers, traders, and wholesalers in China. Given limited stock during the current sale, early purchase is recommended to secure your order.

Q: What is the process for ordering and receiving the product?

A: Place your order with the verified supplier, complete payment using accepted terms, and benefit from express shipping after the handover process. Products are carefully packaged to arrive safely and promptly wherever your facility is located.
