AUTONICS, ROTARY ENCODER, E30S4-3-T-24

AUTONICS, ROTARY ENCODER, E30S4-3-T-24 Specification

Bearing Type
Ball Bearing

Voltage
12-24VDC±5%

Rated Voltage
12-24VDC±5%

Ambient Temperature
-10°C to +70°C (No condensation or freezing)

Standard
CE Certified

Current Type
DC

Features
Rotary Encoder

Product Type
AUTONICS ROTARY ENCODER E30S4-3-T-24

Protect Feature
IP50

Color
Black White Orange Brown Shield

Dimension (L*W*H)
30 mm (diameter) x 30 mm (length)

Weight
Approx. 70g

Shaft Diameter
4 mm

Mounting Type
Clamp-type

IP Rating
IP50

Pulse per Revolution (PPR)
30, 50, 100, 200, 360, 500, 600, 1000 (specify required)

Shock Resistance
490m/s2 (approx. 50G)

Shaft Type
Solid Shaft

Insulation Resistance
Over 100M (at 500VDC)

Connection Type
Cable (Lead wire)

Maximum Response Frequency
25kHz

Output Type
NPN Open Collector

Housing Material
Aluminum

Allowable Radial Load
30 N

Vibration Resistance
10-55Hz, amplitude 1.5mm

Model Name
E30S4-3-T-24

Type
Incremental Rotary Encoder

Allowable Axial Load
20 N

Cable Length
2 meters

Dielectric Strength
500VAC 50/60Hz

AUTONICS, ROTARY ENCODER, E30S4-3-T-24 About

Introducing the AUTONICS E30S4-3-T-24, a new release incremental rotary encoder recognized for its flawless design and excellent performance. With a reduced diameter of 30 mm and a lightweight, laureate aluminum housing, this device delivers ephemeral yet precise measurements. Offering versatile outputs (from 30 to 1000 PPR), the solid shaft model withstands challenging environments thanks to its high IP50 rating and robust ball bearing. Featuring a 2-meter lead-wire cable, it ensures secure connectivity. With CE certification, this encoder suits demanding industrial uses, supporting superior process accuracy and longevity.

Outstanding Build for Industrial Excellence

Constructed with a premium aluminum housing, the AUTONICS E30S4-3-T-24 proves highly durable for demanding applications. Its solid shaft and ball bearing ensure stable rotation, while the 2-meter cable accommodates flexible installations. Suitable for automation systems, motor feedback, and robotics, this flawless encoder excels in environments requiring precise movement detection. With resistance to shock and vibration, it is the perfect laureate for manufacturing, assembly lines, and machine tool operations seeking reliable, long-term performance.

Secure Packaging, Certifications, and Sample Options

Each AUTONICS E30S4-3-T-24 rotary encoder is securely packaged to prevent damage during transit, with express shipping available for expedited orders. All units hold CE certification, ensuring quality and safety standards are met. Product samples can be requested, giving you the chance to estimate suitability before purchase. In case of requirements mismatch, exchange processes are streamlined. This approach supports confident procurement and swift integration into your specific automation or industrial site.

FAQs of AUTONICS, ROTARY ENCODER, E30S4-3-T-24:

Q: How can I choose the appropriate pulses per revolution (PPR) for my application?

A: You can select from various PPR options (30, 50, 100, 200, 360, 500, 600, or 1000) depending on the required resolution and application needs. Consider the movement accuracy and feedback required for your equipment.

Q: What environments is the AUTONICS E30S4-3-T-24 best suited for?

A: This encoder is excellent for use in automation, robotics, and machine tool environments, offering resistance to vibration and shock, and operable within temperatures ranging from -10C to +70C.

Q: When can I expect to receive my order after placing it?

A: Express shipping is available for the AUTONICS E30S4-3-T-24, providing quick delivery. Estimated shipping times depend on your location and chosen shipping method.

Q: Where can I request a sample of this rotary encoder?

A: You can request samples directly from the supplier, trader, or wholesaler for evaluation and suitability testing before committing to a full order.

Q: What certifications does the AUTONICS E30S4-3-T-24 hold?

A: The encoder is CE certified, verifying compliance with rigorous international quality and safety standards for industrial electrical equipment.

Q: How does the exchange process work if the product does not meet my requirements?

A: If the product does not match your needs, a straightforward exchange process is available. Contact the supplier with details to initiate a smooth exchange procedure.
