AUTONICS ROTARY ENCODER 12-24VDC, E80H30-3200-3-T-24

AUTONICS ROTARY ENCODER 12-24VDC, E80H30-3200-3-T-24 Specification

Bearing Type
Ball Bearing

Ambient Temperature
-10C to +70C

Standard
CE certified

Features
Incremental rotary encoder with high precision and durable construction

Efficacy
Optical Rotary Encoder

Rated Voltage
12-24V DC

Current Type
DC

Voltage
12-24V DC

Product Type
Rotary Encoder

Protect Feature
Robust aluminum housing

Speed
6000 RPM max

Color
Silver/Black

Dimension (L*W*H)
80mm x 57mm (outer diameter x length)

Weight
Approx. 600g

Shaft Diameter
10mm

Mounting Type
Clamping flange mount

IP Rating
IP65

Humidity Range
35-85% RH (non-condensing)

Insulation Resistance
Over 100M at 500VDC

Output Current (max)
Max. 30mA

Output Phase
A, B, Z phase

Output Type
Totem Pole (NPN/PNP)

Model
E80H30-3200-3-T-24

Vibration Resistance
10~55Hz, amplitude 1.5mm (for 2 hours each axis)

Supply Voltage Tolerance
10%

Cable Length
2 meters

Resolution
3200 pulses per revolution (PPR)

Shock Resistance
490m/s2, 3 times each in X, Y, Z directions

Connection Type
Cable outgoing

Shaft Material
Stainless Steel

Storage Temperature
-25C to +85C

About AUTONICS ROTARY ENCODER 12-24VDC, E80H30-3200-3-T-24

Experience elite precision and unbeatable value with the AUTONICS ROTARY ENCODER 12-24VDC, E80H30-3200-3-T-24. Engineered for high-performance in demanding environments, this rotary encoder offers a remarkable resolution of 3200 PPR and versatile Totem Pole (NPN/PNP) output. Its uncommon design includes a robust aluminum housing and stainless steel shaft, ensuring long-lasting durability. The device is IP65 rated, delivers high speed up to 6000 RPM, and is CE certified, making it a valuable addition to any automation setup. Take advantage of our sale for premium quality at competitive pricing.

Application & Versatile Features

The AUTONICS ROTARY ENCODER 12-24VDC, E80H30-3200-3-T-24 is used in motion control systems for precise position and speed feedback. With an easy clamping flange mount and a cable length of 2 meters, it fits seamlessly into conveyor systems, robotics, and machinery. Its high-resolution incremental output, stainless steel shaft, and robust aluminum housing provide uncommon reliability, making it ideal for industrial automation and process control applications.

Shipping & Export Details

Goods departure is managed via a reliable FOB China port, ensuring rapid processing and global transport. The main export markets include Asia, the Middle East, and Africa, with prompt arrival at your destination. Delivery time usually ranges from 7 to 15 business days depending on location. Efficient charging applies to transport and handling, ensuring valuable goods reach you swiftly and securely with consistent updates throughout the transit process.

FAQ's of AUTONICS ROTARY ENCODER 12-24VDC, E80H30-3200-3-T-24:

Q: How is the AUTONICS ROTARY ENCODER typically used in industrial applications?

A: The encoder is primarily used for precise position and speed measurement in various industrial automation systems such as conveyor belts, robotics, and machinery requiring accurate motion control.

Q: What are the key features that make this encoder valuable for automation processes?

A: Key features include high resolution (3200 PPR), robust aluminum housing, stainless steel shaft, IP65 protection, CE certification, and compatibility with both NPN and PNP outputs, ensuring durability and versatility.

Q: When can buyers expect the goods to arrive after placing an order?

A: Delivery times usually range from 7 to 15 business days post-order confirmation, depending on your location and shipping preference.

Q: Where does the FOB shipment of the rotary encoder originate?

A: All orders are shipped FOB from China, ensuring efficient handling and processing for global exports.

Q: What is the installation process for the E80H30-3200-3-T-24 encoder?

A: Installation involves mounting the device using its clamping flange, connecting the outgoing cable to your control system, and configuring the output phases as required by your application.

Q: How does the rotary encoder benefit automation systems?

A: It offers precise measurement capabilities, high durability, and reliable performance in harsh industrial environments, which improves system efficiency and reduces downtime.
