AUTONICS ROTARY ENCODER, E40S6-1024-3-T-24

AUTONICS ROTARY ENCODER, E40S6-1024-3-T-24 Specification

Current Type
DC

Noise Level
Not Specified

Rated Voltage
12-24VDC ±5%

Features
Incremental Type, Compact Size, Easy Installation, Solid Shaft

Ambient Temperature
-10°C to +70°C (Non-Freezing/No Condensation)

Voltage
12-24VDC ±5%

Power Rating
Not Specified

Bearing Type
Ball Bearing

Sealed Type
Not Sealed

Product Type
Rotary Encoder

Protect Feature
IP50 Rated

Power
12-24VDC ±5%

Color
Black and Silver

Dimension (L*W*H)
40 mm Diameter (Housing)

Weight
Approx. 140g

Shaft Diameter
6 mm

Mounting Type
Clamp Flange Mount

IP Rating
IP50

Shaft Type
Solid Shaft

Output Capacity
30VDC, 40mA Max

Dielectric Strength
500VAC 50/60Hz for 1 minute

Housing Material
Aluminum

Resolution
1024 PPR (Pulses Per Revolution)

Response Time
Max. 1s

Output Phase
A, B, Z (3-phase)

Shock Resistance
300m/s2 (approx. 30G), 3 times in each direction

Vibration Resistance
50Hz, 1.5mm amplitude, 2 hours

Connection Type
Radial Cable Type (Cable Length: 2m)

Model
E40S6-1024-3-T-24

Allowable Shaft Load
Radial 40N, Thrust 20N

Output Type
Totem Pole

Insulation Resistance
Min. 100M at 500VDC

Additional Product Specifications

Mass Moment of Inertia
Max. 10gcm2

About AUTONICS ROTARY ENCODER, E40S6-1024-3-T-24

Explore the famed AUTONICS ROTARY ENCODER E40S6-1024-3-T-24, a blue-ribbon solution for precision motion measurement. With a first-class 1024 PPR resolution, this solid shaft encoder delivers instant savings through reliable and accurate feedback in automation setups. Suitable for dynamic environments, its robust aluminum housing, totem pole output, and 3-phase output (A, B, Z) ensure seamless integration. Featuring first-rate vibration and shock resistance, plus IP50 protection, this encoder is a top pick for suppliers, traders, and wholesalers seeking durability and value in Vietnam.

Versatile Applications and Exceptional Features

The AUTONICS ROTARY ENCODER E40S6-1024-3-T-24 excels in a wide range of commercial and industrial domains, including robotics, manufacturing automation, conveyors, and machine tools. Its compact size, incremental output, and easy-install clamp flange mount make it suitable for tight spaces and rapid setups. The robust aluminum housing, solid shaft, and IP50 rating assure durability in demanding settings. Flexible connectivity through a 2m radial cable furthers seamless integration into existing systems.

Export Markets, Payment Terms, and Certifications

Primarily exported to Southeast Asian markets, including Vietnam, the AUTONICS E40S6-1024-3-T-24 ensures swift handover and dependable delivery. Payment terms are typically negotiable, aligning with supplier or distributor preferences. Buyers may inquire about asking price, available documentation, and product certifications to guarantee compliance. Certifications may vary; requesting relevant certificates at the point of delivery is recommended to ensure your purchase meets global and local quality standards.

FAQs of AUTONICS ROTARY ENCODER, E40S6-1024-3-T-24:

Q: How can I install the AUTONICS ROTARY ENCODER E40S6-1024-3-T-24 in my automation setup?

A: The encoder features a clamp flange mount and a 2-meter radial cable, allowing for easy and flexible installation in various machinery and automation systems.

Q: What applications are best suited for this rotary encoder model?

A: It is ideal for robotics, industrial conveyors, manufacturing equipment, and machine tools requiring precise positioning and feedback.

Q: Where is the AUTONICS E40S6-1024-3-T-24 commonly exported?

A: This model is popular with suppliers and traders in Vietnam and other Southeast Asian markets.

Q: When should I request product certifications for my order?

A: It is best to request certificates such as compliance and quality documentation during the order process or prior to delivery.

Q: What are the benefits of the solid shaft design in this encoder?

A: A solid shaft enhances durability, maintains reliable signal generation, and simplifies alignment for easy integration into existing mechanical systems.

Q: How does the IP50 rating affect usage?

A: The IP50 rating protects the encoder against dust entry, making it suitable for most indoor, non-sealed environments where moderate dust protection is necessary.
