AUTONICS , ROTARY ENCODER, EP50S8-1024-2F-P-24

AUTONICS , ROTARY ENCODER, EP50S8-1024-2F-P-24 Specification

Ambient Temperature
-10C to 70C (non-freezing) (storage: -20C to 80C)

Bearing Type
Ball bearing

Current Type
DC

Voltage
12-24VDC 5%

Sealed Type
IP50 (Dust Protected)

Standard
CE Certified

Features
Solid shaft, Quadrature (A, B, Z) output, Robust construction, Reverse connection protection, Various output circuit options

Rated Voltage
24V DC

Product Type
Incremental Rotary Encoder

Protect Feature
Reverse connection protection

Color
Silver / Black

Dimension (L*W*H)
Diameter 50mm x Length 37mm (approx)

Weight
Approx. 200g

Shaft Diameter
8 mm

Mounting Type
Clamping/tapered shaft mounting

IP Rating
IP50

Encoder Type
Incremental

Output Phase
A, B, Z (phase) channels

Material
Aluminum case, Stainless steel shaft

Shaft Type
Solid shaft

Max Allowable Revolution
6000 rpm

Power Consumption
Max. 70 mA

Output Connection
5-pin Cable, radial type

Max Allowable Shaft Load
Radial 30 N, Thrust 20 N

Resolution
1024 pulses per revolution (PPR)

Operating Humidity
35-85% RH (no condensation)

Output Signal
Line Driver (HTL, Push-pull)

Model
EP50S8-1024-2F-P-24

Maximum Response Frequency
120 kHz

About AUTONICS , ROTARY ENCODER, EP50S8-1024-2F-P-24

Experience unmatched reliability and affordability with the AUTONICS ROTARY ENCODER EP50S8-1024-2F-P-24, designed for first-string performance in industrial settings. Personalise your system integration with its potent incremental encoder, offering a resolution of 1024 PPR. Its valiant aluminum case and stainless steel shaft guarantee robust durability, while the price cut ensures maximum value without compromising quality. Enjoy efficient signal processing with A, B, Z channels and line driver output. With certified standards and protective features, this encoder proves an ideal choice for various automation applications.

Versatile Usage and Optimal Application

The AUTONICS EP50S8-1024-2F-P-24 rotary encoder is suitable for a wide range of automation and industrial applications, such as motor feedback, conveyor systems, and position detection. Its robust, dust-protected build and high response frequency make it ideal for continuous or intermittent operation. To use, mount the clamping/tapered shaft securely, connect the 5-pin cable, and ensure alignment with your control system to track motion precisely in either rotation direction.

Packaging, Shipping, and Supply Information

Each AUTONICS rotary encoder arrives securely packaged to prevent damage during transportation. Express shipping options ensure speedy arrival, whether by air cargo or local express services. Payment terms are flexible for traders, suppliers, and wholesalers. With steady supply ability, bulk orders are managed efficiently for assured and timely deliveries, supporting your ongoing business needs.

FAQ's of AUTONICS , ROTARY ENCODER, EP50S8-1024-2F-P-24:

Q: How should the AUTONICS EP50S8-1024-2F-P-24 rotary encoder be mounted?

A: Mounting is achieved using its solid shaft with clamping or tapered shaft mounting. Make sure to align the encoder properly with your system and use the supplied 5-pin cable for reliable connection.

Q: What types of outputs does this encoder support?

A: The encoder offers a line driver output (HTL, push-pull) and provides quadrature output with A, B, Z (phase) channels, making it versatile for various control systems.

Q: When is this encoder most beneficial for industrial use?

A: The AUTONICS rotary encoder is most beneficial when precision and robustness are required, such as in motor control, conveyor tracking, or automation processes requiring reliable positioning feedback.

Q: Where can this rotary encoder be applied?

A: It is suitable for use in industrial automation, manufacturing lines, robotics, and anywhere accurate rotational position feedback is essential.

Q: What is the process for ordering and receiving this encoder?

A: Ordering is straightforward for traders and wholesalers, with flexible payment terms. Products are shipped promptly with express options and protective packaging to ensure safe arrival.
