OMRON ROTARY ENCODER 12-24VDC, E6B2-CWZ5G 1500P/R

OMRON ROTARY ENCODER 12-24VDC, E6B2-CWZ5G 1500P/R Specification

Bearing Type
Ball bearing

Sealed Type
Splash proof

Current Type
DC

Standard
CE, RoHS

Features
Incremental Encoder, High Accuracy, Compact Design

Torque
Starting torque: 3.0 mNm max.

Ambient Temperature
Operating: -10C to +70C, Storage: -25C to +85C

Rated Voltage
12 to 24 VDC 5%

Voltage
12-24VDC

Product Type
Rotary Encoder

Protect Feature
IP64 Protection

Phase
Two-phase (A, B, Z) Quadrature Output

Speed
Max. Response Speed: 100 kHz

Color
Black / Silver

Dimension (L*W*H)
40 mm (diameter) 39.5 mm (length)

Weight
Approx. 120 g

Shaft Diameter
6 mm

Mounting Type
Servo Mount (Clamping Flange/Bracket)

IP Rating
IP64

Shaft Type
Solid

Shock Resistance
500 m/s2, 3 times each in X/Y/Z directions

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude

Model Number
E6B2-CWZ5G 1500P/R

Pulse Per Revolution (PPR)
1500

Cable Type
Standard cable, 2 m length

Output Circuit Type
NPN open-collector output

Cable Entry
Side

Material (Case)
Aluminum

About OMRON ROTARY ENCODER 12-24VDC, E6B2-CWZ5G 1500P/R

Ending Soon: Secure the OMRON ROTARY ENCODER E6B2-CWZ5G 1500P/R at a ravishing sale price! Experience lofty performance with 1500 pulses per revolution, reliable NPN open-collector output, and a robust aluminum build capable of withstanding aggressive vibration and shock. Its glorious compact design, splash-proof IP64 rating, and precise two-phase quadrature output ensure unmatched accuracy for your automation needs. Major price cut being offered-don't miss out on this exclusive offer to upgrade your controls with this advanced, CE and RoHS-compliant encoder.

Exceptional Application Performance

The OMRON ROTARY ENCODER 12-24VDC, E6B2-CWZ5G 1500P/R delivers ravishing precision across various application media including robotics, assembly lines, and conveyance systems. Its compact, solid-shaft design with a durable aluminum case excels on mounting surfaces requiring reliable speed detection and control. High vibration and shock resistance offer glorious advantages, securing consistent signal quality in demanding environments. Ideal for robust industrial applications, this encoder is prized for its high accuracy and versatile surface compatibility.

Payment, Packaging & Domestic Delivery

The asking price for this OMRON Rotary Encoder reflects a recent rate drop, making now the best time to invest. Secure transactions and flexible payment terms ensure a smooth purchase experience. Each unit is shipped in protective packaging to guarantee safe arrival. Our main domestic market covers widespread regions across China, offering reliable delivery and prompt service for all customers. Don't miss the chance to acquire industry-leading performance at this highly competitive price point.

FAQ's of OMRON ROTARY ENCODER 12-24VDC, E6B2-CWZ5G 1500P/R:

Q: How is the OMRON E6B2-CWZ5G 1500P/R rotary encoder typically used in automation systems?

A: This rotary encoder is widely used for position and speed sensing in industrial automation systems, such as in robotics, conveyor belts, and assembly machinery, due to its high accuracy and reliable quadrature output signals.

Q: What advantages does the solid shaft and aluminum case provide?

A: The solid shaft ensures stable, durable mounting while the aluminum case offers robust protection against vibration, shock, and environmental factors, extending the encoder's operational life.

Q: Where can I install this rotary encoder for optimal performance?

A: It can be installed on a wide range of application surfaces, particularly where servo mount configurations are required. It is ideal for compact spaces demanding high-speed and precise feedback.

Q: What are the benefits of the IP64 protection rating for this device?

A: The IP64 rating signifies dust-tight construction and splash-proof operation, making the encoder suitable for harsh environments where moisture or dust may be present.
