AUTONICS ROTARY ENCODER,E40H10-1024-3-T-24

AUTONICS ROTARY ENCODER,E40H10-1024-3-T-24 Specification

Standard
CE Certified

Ambient Temperature
-10C to +70C

Features
100 kHz Response frequency, Compact size, Easy installation

Current Type
DC

Voltage
12-24VDC 5%

Bearing Type
Ball Bearing

Product Type
Incremental Rotary Encoder

Protect Feature
IP50

Speed
6000 rpm max

Color
Black / Silver

Dimension (L*W*H)
40mm x 39mm (body length)

Weight
Approx. 120g

Shaft Diameter
6 mm

Mounting Type
Shaft Mount

IP Rating
IP50

Output Phase
A, B, Z phase

Cable Length
2 meters

Connection Type
Radial Cable, 2 m

Output Type
NPN Open Collector

Dielectric Strength
750VAC, 60Hz for 1 minute

Allowable Impact
300 m/s2 (approx. 30G) in X,Y,Z directions for 3 times each

Operating Humidity
35% to 85% RH (non-condensing)

Model
E40H10-1024-3-T-24

Incremental Output
Yes

Insulation Resistance
Over 100M (at 500VDC megger)

Resolution
1024 PPR (Pulses per revolution)

Allowable Vibration
50 m/s2 (10~200Hz) in X,Y,Z directions for 2 hours each

AUTONICS ROTARY ENCODER,E40H10-1024-3-T-24 About

Spotlighted by favorable reviews and lauded for its fresh, pristine engineering, the AUTONICS ROTARY ENCODER E40H10-1024-3-T-24 stands as a blue-ribbon choice in the world of motion control. Users have remarked on its robust 1024 pulses per revolution resolution, superior IP50 protection, and commendable durability under rigorous conditions. Featuring a compact design with ball bearing support, this incremental encoder ensures flawless output through A, B, Z phases with NPN open collector type. Its easy shaft mount, 2-meter cable, and 100 kHz response frequency seamlessly blend reliability with practical installation, making it the top choice for automation professionals.

Optimized for Commercial Applications

AUTONICS ROTARY ENCODER E40H10-1024-3-T-24 excels in commercial environments, tailored for tasks requiring precise position and speed feedback in automated machinery. Its incremental output and high-resolution performance allow for accurate motion sensing across various industrial equipment. Designed for shaft mounting, it simplifies setup processes, making it an essential component for engineers and technicians focusing on automation upgrades. Reliable in both direction and usage type, this encoder can be implemented in conveyors, robotics, and motor-driven systems with minimal effort.

Speedy Delivery & Secure Packaging

Enjoy quick dispatch and secure packaging with the AUTONICS ROTARY ENCODER E40H10-1024-3-T-24. Each order is carefully packaged to ensure pristine condition upon arrival. Payment terms are flexible to suit procurement needs, and minimal shipping charges may apply based on location. Standard delivery ensures the product reaches you efficiently, allowing uninterrupted workflows for traders, suppliers, and wholesalers seeking quality automation components from South Korea.

FAQ's of AUTONICS ROTARY ENCODER,E40H10-1024-3-T-24:

Q: How is the AUTONICS ROTARY ENCODER E40H10-1024-3-T-24 typically used in commercial settings?

A: This encoder is primarily used for motion detection, speed, and position feedback in industrial machines such as conveyors, robotics, and automation equipment, offering reliable control signals during operation.

Q: What are the main benefits of the E40H10-1024-3-T-24's NPN open collector output?

A: The NPN open collector output delivers compatibility with a wide range of industrial control systems, providing high response frequency and versatility for integration into various automated setups.

Q: Where can I install the AUTONICS E40H10-1024-3-T-24 rotary encoder?

A: You can install this encoder in machinery that utilizes a shaft mount system. Its compact size allows for easy integration into limited-space industrial setups.

Q: What is the process for maintaining the encoder to ensure long-term performance?

A: Ensure the encoder operates within specified humidity and temperature ranges, and avoid exceeding allowable vibration and impact thresholds. Periodic inspection for dust and secure mounting is recommended.

Q: When can I expect delivery and what packaging methods are used?

A: Orders are dispatched quickly with careful packaging to maintain product integrity. Standard delivery times depend on location, and express options may be available upon request.
