PEPPERL FUCHS PROXIMITY SENSOR , NBN8-18GM50-E2-V1

PEPPERL FUCHS PROXIMITY SENSOR , NBN8-18GM50-E2-V1 Specification

Signal Type
Digital

Power Consumption
10 mA (without load)

Housing Material
Nickel-plated brass

Cable Length
Not applicable (connector type)

IP Rating
IP67

Mounting Type
Flush (embeddable)

Features
Short-circuit protection, reverse polarity protection, LED indication

Operating Temperature
-25C to +70C

Mounting Thread
M18 x 1

Spectral Range
Not applicable (inductive sensor)

Ingress Protection
IP67

Interface
M12 x 1 connector, 4-pin

Measurement Range
Sensing distance 8 mm flush

Sensor Type
Inductive

Application
Position sensing, metal object detection, assembly automation

Response Time
< 1 ms

Sensitivity
Detects iron, steel, and similar metals

Wireless
No

Product Type
Inductive Proximity Sensor

Material
Nickel-plated brass, plastic

Input
10-30 V DC

Output
PNP, NO (normally open)

Function
Detects metallic objects without physical contact

Usage
Industrial automation, object detection

Accuracy
High repeat accuracy 0.3 mm

Resolution
Standard inductive precision

Voltage
Operating voltage 10-30 V DC

Weight
Approx. 60 g

Polarity Reversal Protection
Yes

Switching Frequency
0-2000 Hz

Minimum Residual Current
0.5 mA

Repeat Accuracy
0.3 mm

Status Indication
Yellow LED

Protection Class
II, rated insulation voltage 50 V

Connection Type
Plug, M12 x 1

Output Type
3-wire

Sensing Face Material
Plastic

Short-circuit Protection
Yes

Housing Length
50 mm

Max Load Current
200 mA

PEPPERL FUCHS PROXIMITY SENSOR , NBN8-18GM50-E2-V1 Trade Information

Minimum Order Quantity
20 Number

Delivery Time
7 Days

About PEPPERL FUCHS PROXIMITY SENSOR , NBN8-18GM50-E2-V1

Discover blue-ribbon performance and cost savings with the PEPPERL FUCHS PROXIMITY SENSOR, NBN8-18GM50-E2-V1-a virtuoso in the field of industrial automation. Special rates available for bulk orders allow you to personalise your solution while securing first-rate quality. This sensor boasts a finest precision of 0.3 mm repeat accuracy and a robust build with IP67, nickel-plated brass housing. Embedded with advanced protection features, it's designed for seamless, contactless detection of metallic objects, making it a superior choice for object detection, position sensing, and assembly automation.

Superior Advantages & Competitive Edge

Benefit from the highest-grade detection accuracy and repeatability with the PEPPERL FUCHS NBN8-18GM50-E2-V1. Its primary competitive advantages include advanced protection mechanisms, blue-ribbon sensing capabilities, and effortless flush mounting via M18 x 1 threads. Application is simple: connect the sensor via M12 plug for reliable position sensing and object identification. These features result in fewer downtimes, faster response, and optimal integration within industrial environments, ensuring seamless automation processes.

Sample Policy, Certification, & Export Markets

Samples can be handed over upon request after confirming a formal quotation. Minimal charges may apply depending on the region and order scale. The sensor adheres to leading certifications, confirming its reliability and safety standards. Main export markets include Europe, Asia, North America, and beyond, making this a trusted component for global industrial supply pipelines. Full documentation and compliance certificates are available to ensure smooth international trade transactions.

FAQ's of PEPPERL FUCHS PROXIMITY SENSOR , NBN8-18GM50-E2-V1:

Q: How do I install the PEPPERL FUCHS PROXIMITY SENSOR, NBN8-18GM50-E2-V1?

A: To install the sensor, mount it flush using the M18 x 1 thread and connect it with the M12 x 1, 4-pin interface. Ensure correct polarity and verify the status with the yellow LED indicator.

Q: What benefits does this proximity sensor offer in industrial automation?

A: This sensor provides high repeat accuracy, quick response time, robust protection features, and long-lasting durability, all contributing to improved automation efficiency and reduced maintenance costs.

Q: Where can this sensor be used?

A: The sensor is ideal for position sensing, metal object detection, and assembly automation within industrial automation systems, suitable for environments up to IP67 protection levels.

Q: When can I expect to receive samples for evaluation?

A: Samples are usually handed over after a formal quotation and arrangement, with timelines depending on your location and order specifications.

Q: What certifications does the NBN8-18GM50-E2-V1 hold?

A: The sensor is certified to meet international standards, ensuring safety, quality, and operational reliability for use across major export markets.
