PEPPERL +FUCHS INDUCTIVE PROXIMITY SENSOR,NBN40-L2-A2-V1

PEPPERL +FUCHS INDUCTIVE PROXIMITY SENSOR,NBN40-L2-A2-V1 Specification

Interface
M12 connector, 4-pin

Operating Temperature
-25 C to +70 C Celsius (oC)

Wireless
No

Sensor Type
Inductive

IP Rating
IP67

Sensitivity
Factory calibrated

Measurement Range
40 mm nominal sensing distance

Application
Position sensing in machinery, conveyor systems, factories

Features
LED status indication, short-circuit protection, reverse polarity protection

Mounting Type
Flush mount

Signal Type
Digital

Product Type
Inductive Proximity Sensor

Material
Metal housing, plastic face

Input
3-wire DC

Output
PNP Normally Open (NO)

Function
Object Detection, Non-contact sensing of metallic objects

Usage
Industrial automation, object positioning and detection

Resolution
Standard

Voltage
10-30 V DC Volt (v)

Weight
Approx. 200 g Grams (g)

Shock/Vibration Resistance
Compliant with EN 60068-2-6, EN 60068-2-27

Connection Type
M12 x 1 connector, 4-pin

Max Load Current
200 mA

Type Code
NBN40-L2-A2-V1

Power Supply Ripple
10%

Housing Dimensions
40 x 40 x 66 mm

Switching Frequency
0-300 Hz

Switching Element Function
Normally open (NO)

Ambient Light Immunity
Not influenced by ambient light

Protective Functions
Short-circuit and overload protection, reverse polarity protection

PEPPERL +FUCHS INDUCTIVE PROXIMITY SENSOR,NBN40-L2-A2-V1 Trade Information

Minimum Order Quantity
10 Number

Supply Ability
100 Per Month

Delivery Time
7 Days

About PEPPERL +FUCHS INDUCTIVE PROXIMITY SENSOR,NBN40-L2-A2-V1

Pepperl+Fuchs' illustrious INDUCTIVE PROXIMITY SENSOR, NBN40-L2-A2-V1, stands as a best-seller in top-tier industrial automation. Now offered at a reduced price, this champion sensor excels in non-contact, high accuracy object detection with a remarkable 40 mm sensing range. Engineered to operate reliably amid vibration and shocks, its robust metal housing ensures durability. Key features include IP67 protection, short-circuit/overload safeguards, and resistance to ambient light. Designed for seamless integration using a 4-pin M12 connector, it delivers PNP NO switching, flawless performance, and factory-calibrated sensitivity, making it the preferred choice for position sensing in various machinery and conveyor systems.

Inductive Proximity Sensor: Usage & Competitive Edge

The NBN40-L2-A2-V1 sensor is primarily utilized for precise position sensing in machinery, conveyor systems, and automated factory environments. Its competitive advantages include high switching accuracy, robust build, and advanced protective functions. Favored for object positioning and non-contact detection of metallic objects, it delivers consistent performance and reliability, making it an optimal solution for demanding industrial applications.

Supply Ability & Order Processing Details

Pepperl+Fuchs ensures prompt packing & dispatch of the NBN40-L2-A2-V1, supporting smooth freight handling from Germany to various global destinations. The supply ability accommodates large or bulk orders efficiently, and sample policies allow for pre-order evaluations. With dedicated FOB port logistics and swift order processing, customers benefit from streamlined procurement and reliable delivery schedules.

FAQ's of PEPPERL +FUCHS INDUCTIVE PROXIMITY SENSOR,NBN40-L2-A2-V1:

Q: How does the PEPPERL+FUCHS NBN40-L2-A2-V1 sensor ensure high accuracy in object detection?

A: The sensor is factory calibrated for sensitivity, delivering precise detection with a nominal sensing distance of 40 mm and a response time of 1 ms, ensuring accurate object detection in industrial environments.

Q: What protective features does the NBN40-L2-A2-V1 offer for safe operation?

A: This sensor includes short-circuit and overload protection, reverse polarity safeguards, and compliance with shock and vibration resistance standards (EN 60068-2-6, EN 60068-2-27), enhancing operational safety.

Q: When is the best time to use this sensor in automated systems?

A: The NBN40-L2-A2-V1 is ideal for deployment when reliable position sensing and non-contact detection are required in machinery, production lines, or conveyor systems, ensuring efficiency and accuracy.

Q: Where is the sensor Atypically installed, and what mounting method does it support?

A: Designed for flush mounting, this sensor is commonly installed in factory automation setups, conveyors, or machinery, offering versatile compatibility with industrial equipment.

Q: What is the process for packing & dispatch and freight management for bulk orders?

A: After order placement, Pepperl+Fuchs manages packing and dispatch with secure packaging methods. Orders are processed efficiently and shipped via trusted freight partners from designated FOB ports, ensuring on-time delivery.

Q: What benefits does the sensor's IP67 rating provide in industrial applications?

A: The IP67 rating offers robust protection against dust and water ingress, allowing the sensor to operate dependably even in harsh or challenging industrial environments.
