OMRON, PROXIMITY SENSOR E2B-S08LS02-MC-C1

OMRON, PROXIMITY SENSOR E2B-S08LS02-MC-C1 Specification

Cable Length
2 m

Features
LED Operation Indicator, Robust Design

Sensor Type
Inductive

IP Rating
IP67

Response Time
<1 ms

Mounting Type
Flush Mount (Shielded)

Measurement Range
2 mm (Sensing Distance)

Power Consumption
10 mA max (no load)

Application
Metal Object Detection

Wireless
No

Interface
3-wire DC

Operating Temperature
-25C to +70C

Signal Type
Digital

Sensitivity
Detects ferrous metals

Product Type
Proximity Sensor

Material
Stainless Steel Housing

Input
DC

Output
PNP (Normally Open)

Function
Object Detection (Non-Contact)

Usage
Industrial Automation, Object Sensing

Accuracy
High Repeatability

Resolution
0.01 mm

Voltage
10-30 V DC

Weight
Approx. 25 g

Model Number
E2B-S08LS02-MC-C1

Compliance
RoHS

Enclosure
Cylindrical metal shell

Maximum Load Current
200 mA

Barrel Diameter
8 mm

Reverse Polarity Protection
Yes

Shock Resistance
500 m/s²

Switching Frequency
1 kHz

Connection Type
Pre-wired cable

Indicator
Operation indicator (red LED)

Body Length
35 mm

Vibration Resistance
10 to 55 Hz, 1.5 mm double amplitude

Material of Sensing Face
PBT

Storage Temperature
-40°C to +85°C

About OMRON, PROXIMITY SENSOR E2B-S08LS02-MC-C1

Experience the latest in object detection technology with the OMRON PROXIMITY SENSOR E2B-S08LS02-MC-C1, a must-have for industrial automation. Capitalise on its top-tier 2 mm sensing distance, high repeatability, and best-in-class durability with an IP67-rated stainless steel housing. This decorated sensor features a robust cylindrical body (8 mm diameter, 35 mm length), reverse polarity protection, and a vibrant red LED indicator. With reliable PNP (Normally Open) output and low power consumption, it delivers superior accuracy and lightning-fast response under challenging conditionsa perfect choice for precision metal detection tasks.

Applications & Competitive Advantages

The OMRON PROXIMITY SENSOR E2B-S08LS02-MC-C1 excels in heavy-duty industrial environments such as assembly lines, metalworking machines, and robotics. Its robust, flush-mount design and high resistance to shock and vibration provide a competitive edge. Beyond metal object detection, it is ideal for conveyor systems, automotive production, and high-speed automation. Engineered for accuracy and resilience, this sensor delivers consistent performance, making it the preferred choice for maintaining operational efficiency in demanding applications.

Export, Certifications, and Trading Info

OMRONs PROXIMITY SENSOR E2B-S08LS02-MC-C1 is trusted in top export markets across Europe, Asia, and the Americas. The product is RoHS compliant, ensuring safety and adherence to international standards. FOB Port: China, with competitive charges and quotations available upon request. Packaging is robust to guarantee product integrity during transit. As a leading supplier and wholesaler, OMRON assures timely delivery and dedicated aftersales support for global customers.

FAQs of OMRON, PROXIMITY SENSOR E2B-S08LS02-MC-C1:

Q: How does the OMRON E2B-S08LS02-MC-C1 proximity sensor detect objects?

A: The sensor uses non-contact inductive technology to detect the presence of ferrous metal objects within a 2 mm sensing distance, offering reliable digital output for automation systems.

Q: What are the main benefits of using this proximity sensor in industrial applications?

A: It offers top-tier durability, high repeatability, fast response times under 1 ms, and robust resistance to shock and vibration, ensuring dependable operation in harsh industrial environments.

Q: Where is the ideal place to install this sensor?

A: The flush-mount, shielded design allows installation in confined or exposed locations on industrial machinery where precise metal object detection is required.

Q: When should I consider replacing my proximity sensor with this latest OMRON model?

A: Upgrade when your existing sensor lacks high repeatability, requires improved shock and vibration resistance, or you need compliance with RoHS and enhanced operational precision.
