PEPPERL FUCHS PROXIMITY SENSOR, ML100-55/103/155

PEPPERL FUCHS PROXIMITY SENSOR, ML100-55/103/155 Specification

Signal Type
Digital (Switching)

IP Rating
IP67

Sensor Type
Photoelectric Proximity Sensor

Cable Length
2 m

Measurement Range
0-8 m (Diffusion Range)

Response Time
<1 ms

Power Consumption
<20 mA

Interface
3-wire, M8 Connector or Cable

Operating Temperature
-25C to +55C

Features
Compact Design, LED Status Indicator, Short-circuit Protection

Wireless
No

Mounting Type
Through-Hole or Bracket Mount

Sensitivity
Adjustable via Potentiometer

Application
Automation Systems, Conveyor Control, Packaging Machinery

Product Type
Proximity Sensor

Material
Plastic Housing

Input
10-30 V DC

Output
PNP, NO/NC

Function
Diffuse Mode Sensor

Usage
Object Detection

Accuracy
High Repeatability

Resolution
Fine Spot Resolution

Voltage
10-30 V DC (Operating Voltage)

Weight
Approx. 50 g

Reverse Polarity Protection
Yes

Short Circuit Protection
Yes

Connection Type
Cable or Connector

Housing Dimensions
18 mm x 47 mm x 30 mm

Operating Current
Max. 100 mA

Reference Standards
CE, cULus

Start-up Delay
<100 ms

Switching Frequency
Up to 800 Hz

Light Source
Red Light, LED

EMC
EN 60947-5-2 Compatible

Adjustable Range
Yes (Potentiometer)

About PEPPERL FUCHS PROXIMITY SENSOR, ML100-55/103/155

Order the PEPPERL+FUCHS PROXIMITY SENSOR, ML100-55/103/155 to elevate your automation systems with ephemerally fast response and enlightened precision. This sterling sensor features a masterfully compact design, equipped with an adjustable range via potentiometer, fine spot resolution, and a high repeatability standard, ensuring accurate object detection. Its robust plastic housing and IP67 rating enable enduring performance, while the red light LED provides consistency. Add to Cart today for a masterpiece in diffuse mode photoelectric sensing, trusted worldwide by suppliers, traders, and wholesalers from China.

Applications & Reliable Materials for Precision Sensing

The PEPPERL FUCHS PROXIMITY SENSOR, ML100-55/103/155 applies seamlessly in diverse automation environments including conveyor control and packaging machinery. Its reliable object detection is powered by a user-adjustable range and fine spot resolution, set within a durable plastic housing. Well-suited for sensing a variety of materials and objects, it utilizes red-light LED technology with an innovative diffuse mode method. This sensor excels in modern manufacturing processes, providing high accuracy in tough operating conditions.

Premium Packaging, Global Delivery, and Expert Logistics

Each PEPPERL FUCHS PROXIMITY SENSOR, ML100-55/103/155 is shipped in premium packaging designed to protect its compact, precision-engineered structure. We cater to main export markets worldwide, ensuring safe and timely deliveries through expert logistics networks. Customers can expect a swift delivery time, with orders processed efficiently for prompt dispatch. Whether you're sourcing for local needs or international projects, our logistics and packaging standards guarantee the product arrives in excellent condition.

FAQ's of PEPPERL FUCHS PROXIMITY SENSOR, ML100-55/103/155:

Q: How does the ML100-55/103/155 proximity sensor ensure accurate object detection?

A: The sensor achieves accurate object detection through high repeatability, fine spot resolution, and sensitivity adjustment using an integrated potentiometer, making it suitable for a range of automation scenarios.

Q: What applications are ideal for the PEPPERL FUCHS ML100-55/103/155 sensor?

A: This sensor is ideal for automation systems including conveyor control, packaging machinery, and any application requiring precise, quick, and reliable object detection in varying environmental conditions.

Q: Where can the sensor be installed, and what mounting options are offered?

A: The sensor supports both through-hole and bracket mountings, allowing installation flexibility on automation machines, conveyor belts, and similar equipment.

Q: What are the benefits of the sensor's material and design?

A: The compact plastic housing and IP67 rating provide durability against dust and moisture, while the lightweight design and adjustable settings enhance integration and operational longevity.

Q: What output options and interfaces does the sensor support?

A: The ML100-55/103/155 offers digital PNP output with NO/NC configuration, and connects via a 3-wire, M8 connector or a 2-meter cable for versatile system compatibility.
