PEPPERL FUCHS INDUCTIVE PROXIMITY SENSOR,NBN4-12GM50-E2-V1

PEPPERL FUCHS INDUCTIVE PROXIMITY SENSOR,NBN4-12GM50-E2-V1 Specification

Response Time
< 1 ms

Measurement Range
4 mm sensing distance (flush)

Cable Length
Connector (M12, 4-pin)

Operating Temperature
-25 C to +70 C

Mounting Type
Flush mountable, threaded barrel M12

Sensitivity
Detects ferrous metal objects within range

Features
Short, cylindrical type, LED status indication, high EMC resistance

Application
General industrial automation, metal object detection

Wireless
No

Signal Type
Digital

Interface
M12 connector, 4-pin

Sensor Type
Inductive

IP Rating
IP67

Power Consumption
15 mA

Product Type
Inductive Proximity Sensor

Material
Nickel-plated brass housing

Input
3-wire DC

Output
PNP, Normally Open (NO)

Function
Non-contact object detection

Usage
Automation, position sensing, machine safety

Accuracy
High switching precision

Resolution
Standard (discrete output)

Voltage
10 to 30 V DC

Weight
Approx. 35 g

Operating Principle
Inductive, flush mounting

Housing Material
Nickel-plated brass

Protection Circuitry
Short-circuit and overload protection

Switching Frequency
Up to 2 kHz

Status Indication
LED

Housing Dimensions
M12 x 50 mm

Sensing Side Material
Plastic

Installation Type
Cylindrical, threaded barrel

Supply Voltage Reversal Protection
Yes

About PEPPERL FUCHS INDUCTIVE PROXIMITY SENSOR,NBN4-12GM50-E2-V1

Discover the superb PEPPERL FUCHS INDUCTIVE PROXIMITY SENSOR, NBN4-12GM50-E2-V1-engineered for astonishing precision and world-class reliability. Access next-level automation with this highly recommended sensor, perfect for metal object detection in demanding industrial settings. Boasting a switching frequency up to 2 kHz, LED status indication, and high EMC resistance, it ensures non-contact, accurate sensing and seamless integration via M12 connector. Benefit from robust short-circuit and overload protection, IP67 enclosure, and versatile flush mounting. Try now for elevated performance and dependable safety in all automation applications.

Optimized Automation for Industry

PEPPERL FUCHS NBN4-12GM50-E2-V1 stands out in commercial and industrial automation, including packaging, assembly, and machine safety. Special features like the LED status indicator and short-circuit protection ensure maintenance efficiency and overall reliability. Its cylindrical, flush-mountable nickel-plated brass housing supports durability and easy installation. Recommended for metal object sensing, this device elevates operational safety and accuracy in applications like conveyor systems, robotic arms, and position monitoring.

Quick Export and Ready Stock with Trusted Certification

This sensor is highly sought after in global markets with Stock Ready for immediate dispatching, ensuring minimal delay in freight and delivery. As a trusted supplier and wholesaler in Vietnam, we prioritize rapid fulfillment and international standards, complete with the necessary certifications. Our sample policy is flexible, allowing customers to assess quality before ordering in bulk. Experience swift, secure export services and world-class product reliability with PEPPERL FUCHS sensors.

FAQ's of PEPPERL FUCHS INDUCTIVE PROXIMITY SENSOR,NBN4-12GM50-E2-V1:

Q: How does the PEPPERL FUCHS NBN4-12GM50-E2-V1 sensor detect objects?

A: This inductive proximity sensor detects ferrous metal objects within a 4 mm range using non-contact sensing, delivering a digital output signal when an object is present.

Q: What are the main benefits of using this sensor in automation systems?

A: The sensor provides superb accuracy, high switching frequency, and robust protection circuits, ensuring reliable metal object detection, minimal downtime, and enhanced machine safety in automation applications.

Q: Where can this proximity sensor be installed for optimal performance?

A: It is designed for flush mounting in threaded barrel (M12) installations, making it ideal for space-limited or exposed environments in industrial machinery and conveyor systems.

Q: When should I consider choosing this sensor for my operations?

A: Select this sensor when you require world-class reliability, quick response time, and high EMC resistance for critical automation, safety, and position detection tasks in harsh industrial settings.

Q: What is the process for ordering and receiving this sensor internationally?

A: With stock ready in Vietnam, we ensure prompt dispatching and safe freight handling. Customers can request samples to evaluate before placing larger orders, supporting a smooth procurement process.
