AUTONICS PROXIMITY SENSOR,CR30-15DP

AUTONICS PROXIMITY SENSOR,CR30-15DP Specification

IP Rating
IP67

Interface
Wired

Application
Industrial Automation, Object Positioning, Counting, Metal Detection

Sensor Type
Inductive Proximity Sensor

Response Time
2ms

Cable Length
2m (Standard)

Sensitivity
Adjustable via sensing distance

Wireless
No

Measurement Range
15mm

Signal Type
Digital

Power Consumption
Max. 25mA

Mounting Type
Flush/Non-flush (Refer datasheet)

Features
Short-circuit Protection, Polarity Protection, LED indicator

Operating Temperature
-25C to +70C

Product Type
Proximity Sensor

Material
Nickel-plated brass (Housing), PBT (Head)

Input
DC 3-wire (PNP)

Output
PNP Normally Open (NO)

Function
Non-contact Detection

Usage
Sensing presence/absence of metal objects

Accuracy
10% of sensing distance

Resolution
High

Voltage
Operating Voltage: 12-24V DC

Weight
Approx. 190g

Max Load Current
200mA

Shock Resistance
500m/s2 (approx. 50G) 3 times each in X, Y, Z directions

Withstand Voltage
1,000V AC 50/60Hz for 1 min

Connection Type
Cable type

Control Output
PNP Open Collector

LED Indicator
Yes (operation indicator)

Insulation Resistance
50 M min. (at 500V DC)

Residual Voltage
Max. 1.5V

Vibration Resistance
10 to 55 Hz, 1.5mm double amplitude, each in X, Y, Z directions

Detection Object
Ferrous Metals (Best), Non-ferrous (Reduced range)

Sensing Method
Inductive

Model Number
CR30-15DP

About AUTONICS PROXIMITY SENSOR,CR30-15DP

Unlock unassailable performance with the acclaimed AUTONICS PROXIMITY SENSOR, CR30-15DP. As a best-in-class inductive sensor, it champions reliability in detecting ferrous metals, even under harsh industrial conditions. Featuring a robust nickel-plated brass housing, high vibration and shock resistance, and an IP67 rating, this sensor ensures peak operation. With adjustable sensitivity, non-contact detection, and PNP open collector output, it excels in automation, metal detection, and object positioning. Benefit from special discount offers-shop now from leading suppliers, traders, and wholesalers direct from China.

Versatility and Material Excellence

The AUTONICS PROXIMITY SENSOR, CR30-15DP offers high-resolution, non-contact detection for metal objects at up to 15mm. Installation is simplified with its flush or non-flush mounting options, and instant LED feedback indicates operation. Crafted from nickel-plated brass and PBT, the sensor withstands industrial demands, while adjustable sensitivity widens the scope to applications like counting, object positioning, and metal presence detection-making it a reliable champion in various sectors.

Packaging, Sample Policy, and Delivery Information

Each sensor is carefully packed to ensure safe shipment. Sample policies are available upon request for qualified partners. Faster order processing means your sensor is quickly handed over to shipping providers. Expect efficient delivery with timely arrival at your facility. Comprehensive documentation is included for smooth installation and operation. Connect with us to learn more about bulk order arrangements and how you benefit from streamlined logistical support on every shipment.

FAQ's of AUTONICS PROXIMITY SENSOR,CR30-15DP:

Q: How does the AUTONICS CR30-15DP Proximity Sensor operate?

A: The AUTONICS CR30-15DP operates by emitting an inductive field to detect the presence or absence of ferrous metal objects, providing high-accuracy digital output with a 15mm sensing range.

Q: What is the process for installing this proximity sensor?

A: Installation is straightforward-choose flush or non-flush mounting as per the datasheet, connect via the 2m cable, and adjust sensitivity if necessary. The LED operation indicator confirms successful setup.

Q: Where can the AUTONICS CR30-15DP be used?

A: This sensor is perfect for industrial automation, object positioning, counting, and metal detection across automotive, manufacturing, packaging, and assembly operations.

Q: What are the benefits of using this sensor over traditional switches?

A: Unlike mechanical switches, the CR30-15DP offers non-contact detection, longer lifespan, resistance to harsh conditions, and quick 2ms response, ensuring low-maintenance and unassailable performance.

Q: How soon can the sensor be delivered after order placement?

A: Orders are swiftly processed for shipment, with sensors usually handed over to carriers within defined lead times. Arrival at your location is prompt, depending on your shipping method and region.
