PEPPERL FUCHS INCREMENTAL ROTARY ENCODER, TVI40N-09TK2T6TN-01000

PEPPERL FUCHS INCREMENTAL ROTARY ENCODER, TVI40N-09TK2T6TN-01000 Specification

Ambient Temperature
-25C to +85C

Voltage
10-30 V DC

Bearing Type
Ball bearing

Standard
CE, RoHS

Features
Optical sensing method, Robust metal housing, short-circuit and reverse polarity protected, High precision, Compact design

Current Type
DC

Rated Voltage
10-30 V DC

Product Type
Incremental Rotary Encoder

Protect Feature
Reverse polarity protection, Short-circuit protection

Speed
Max. 6000 rpm

Color
Silver/Black

Dimension (L*W*H)
Approx. 40 mm diameter

Weight
Approx. 250 g

Shaft Diameter
6 mm (solid shaft)

Mounting Type
Clamp flange

IP Rating
IP65

Material
Aluminum housing, Stainless steel shaft

Max. Shaft Load (Radial/Axial)
40 N / 20 N

Operating Voltage Range
10-30 V DC

Connection
Radial cable, 2 meters

Output Type
Push-pull (HTL)

Storage Temperature
-40C to +100C

Pulses Per Revolution (PPR)
1000

Model
TVI40N-09TK2T6TN-01000

Encoder Type
Incremental

About PEPPERL FUCHS INCREMENTAL ROTARY ENCODER, TVI40N-09TK2T6TN-01000

Experience superior engineering and glorious precision with the PEPPERL FUCHS INCREMENTAL ROTARY ENCODER, TVI40N-09TK2T6TN-01000. Benefit from instant savings and instant checkout when you select this top-drawer encoder, crafted with an aluminum housing and robust stainless steel shaft for exceptional durability. Its ephemeral profile, compact dimensions, and high precision optical sensing make it perfect for space-sensitive applications. Backed by IP65 protection, advanced safety features, and an impressive 6000 rpm speed, this encoder delivers unrivaled reliability and effortless integration for industrial needs.

Applications, Advantages, and Installation Method

The PEPPERL FUCHS INCREMENTAL ROTARY ENCODER, TVI40N-09TK2T6TN-01000 is suitable for automation systems, conveying equipment, and machinery demanding precision. Its high-resolution 1000 PPR and HTL push-pull output offer outstanding advantage in signal accuracy. Installation is easy thanks to its solid shaft design, clamp flange mounting, and 2-meter radial cable, enabling seamless integration and rapid setup for superior operational efficiency.

Domestic Market, Delivery, and Supply Readiness

Serving major domestic markets, our shipment and transportation services ensure prompt delivery of the PEPPERL FUCHS INCREMENTAL ROTARY ENCODER, TVI40N-09TK2T6TN-01000. With reliable supply ability and streamlined logistics, your orders are dispatched efficiently, minimizing downtime. Immediate shipment options combined with a robust supply chain provide outstanding accessibility, guaranteeing your operations remain uninterrupted with swift delivery and trusted availability.

FAQ's of PEPPERL FUCHS INCREMENTAL ROTARY ENCODER, TVI40N-09TK2T6TN-01000:

Q: How do I install the PEPPERL FUCHS TVI40N-09TK2T6TN-01000 encoder?

A: Installation is straightforward using its clamp flange mount. Align the 6 mm solid shaft carefully, secure the flange, and connect the 2-meter radial cable to your system following the provided wiring diagram for push-pull output.

Q: What makes this encoder suitable for industrial environments?

A: Its robust aluminum housing, stainless steel shaft, IP65 rating, and protection features such as short-circuit and reverse polarity protection make it ideal for challenging industrial settings where durability and reliability are essential.

Q: When can I expect the delivery after placing an order?

A: Orders are shipped promptly, ensuring swift and reliable delivery. Typical shipment times depend on your location, but expedited options are available to minimize operational delays.

Q: Where can this incremental rotary encoder be effectively used?

A: It is highly effective in automation systems, conveyor machinery, and other industrial equipment requiring precise position feedback and speed monitoring.

Q: What are the key advantages of using this PEPPERL FUCHS encoder?

A: Key benefits include high precision with 1000 PPR, compact and sturdy design, easy integration, and superior protection features, ensuring top-drawer performance in demanding operations.
