OMRON ROTARY ENCODER 12 TO 24VDC, E6B2-CWZ5B 360P/R

OMRON ROTARY ENCODER 12 TO 24VDC, E6B2-CWZ5B 360P/R Specification

Ambient Temperature
Operating: -10 to +70C (no icing or condensation)

Features
Incremental rotary encoder, high accuracy, compact size

Bearing Type
Ball bearings

Current Type
DC

Voltage
12 to 24V DC 5%

Standard
CE, RoHS

Product Type
Rotary Encoder

Protect Feature
Reverse connection protection, Surge absorber

Phase
2-phase

Color
Black/Metal

Dimension (L*W*H)
Approx. 40mm x 39.5mm (Body)

Weight
Approx. 200 g (including cable)

Shaft Diameter
6 mm

Mounting Type
Shaft mounting (with bracket)

IP Rating
IP64

Insulation Resistance
100 M min. (at 500 VDC megger)

Model
E6B2-CWZ5B

Output Phase
A, B, Z (phase shifted)

Allowable Thrust Load
30 N (at shaft end)

Resolution
360 pulses/revolution (P/R)

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude

Shaft Length
13 mm

Rotation Direction
Clockwise/Counterclockwise (as viewed from shaft end)

Cable Type
Standard cable length 2 m, pre-wired

Output Configuration
NPN open-collector output

Shock Resistance
1,000 m/s, 3 times each in X, Y, Z directions

Humidity
35% to 85% RH (operating)

Maximum Response Frequency
100 kHz

Material
Aluminum housing, stainless steel shaft

Allowable Radial Load
50 N (at shaft end)

Connection method
Lead wire (Pre-wired)

About OMRON ROTARY ENCODER 12 TO 24VDC, E6B2-CWZ5B 360P/R

Limited stock available - Get it Now! The OMRON Rotary Encoder E6B2-CWZ5B is a champion among incremental encoders, offering incomparable precision and reliability. With 360 pulses per revolution, crackerjack NPN open-collector output, and robust construction featuring a stainless steel shaft and aluminum housing, it excels in high-accuracy applications. Top features include reverse connection protection, surge absorber, and IP64 rating for dust and water resistance. Ideal for automation, robotics, and industrial control. Secure this high-performing, compact encoder for optimal results before it's gone!

Applications and Advantages of OMRON E6B2-CWZ5B Encoder

The OMRON Rotary Encoder E6B2-CWZ5B 360P/R is perfect for industrial automation, robotics, and conveyor systems, ensuring precise rotation detection and speed control. Its incremental pulse output and robust design offer a competitive edge, meeting CE and RoHS standards. The compact size and high accuracy make it ideal for integration into demanding machinery, guaranteeing stable performance in manufacturing processes.

Supply Ability, Packaging, and Market Reach

Freight and transportation are efficiently managed to ensure timely delivery of OMRON E6B2-CWZ5B encoders. Secure packaging guarantees product safety during transit. Order processing is streamlined for both bulk and single purchases, catering to vendors and manufacturers across China's main domestic market. Rapid dispatch and reliable logistics support your supply needs, making acquisition and integration seamless.

FAQ's of OMRON ROTARY ENCODER 12 TO 24VDC, E6B2-CWZ5B 360P/R:

Q: How is the OMRON E6B2-CWZ5B rotary encoder installed for optimal performance?

A: The encoder is designed for shaft mounting with a bracket. Ensure secure installation on machinery shafts, and connect the pre-wired standard 2m cable for stable electrical interface. Proper alignment and mounting help achieve accurate pulse output.

Q: What are the primary applications for the OMRON E6B2-CWZ5B encoder?

A: This encoder is widely used in industrial automation, robotics, conveyor systems, and manufacturing equipment requiring precise speed and position control, thanks to its high resolution and durable design.

Q: When should I consider using this rotary encoder in my equipment?

A: Choose the E6B2-CWZ5B when your system needs accurate rotational measurement, robust shock and vibration tolerance, and compact size for tight installation spaces, especially in environments with variable temperature and humidity.

Q: Where is this encoder mainly supplied and distributed?

A: The OMRON E6B2-CWZ5B rotary encoder is primarily supplied across China's main domestic market, with efficient freight, distribution, and support for suppliers, traders, and wholesalers.

Q: What advantages does the encoder's output configuration offer?

A: Its NPN open-collector output provides flexible connectivity with most control systems, ensuring reliable signal processing and compatibility with diverse industrial automation platforms.

Q: How does the protection feature benefit the encoder's longevity?

A: Reverse connection protection and surge absorber safeguard the encoder's internal electronic components, enhancing durability and minimizing maintenance or downtime in demanding environments.
