AUTONICS,ROTARY ENCODER, E40H8-2000-6-L-5

AUTONICS,ROTARY ENCODER, E40H8-2000-6-L-5 Specification

Ambient Temperature
-10C to +70C (non-freezing, non-condensing)

Features
2000 pulses per revolution multiple outputs (OUT-A OUT-B OUT-Z) shield grounding

Sealed Type
Not Specified

Rated Voltage
5VDC

Current Type
DC

Bearing Type
Ball bearing

Noise Level
Not Specified

Voltage
5VDC 5%

Product Type
Rotary Encoder

Protect Feature
Shield grounding

Color
Silver/Black

Dimension (L*W*H)
40 mm (outer diameter x height not specified)

Weight
Approximately 200 g

Shaft Diameter
6 mm

Mounting Type
Clamping (servo mount)

IP Rating
IP50

Allowable Radial Load
Max. 40 N

Connector Type
Cable Type

Vibration Resistance
5-150 Hz, amplitude 0.75 mm, 2 hours in each of X, Y, Z axes

Resolution
2000 PPR (Pulses Per Revolution)

Response Frequency
Max. 200 kHz

Model
E40H8-2000-6-L-5

Material
Housing - Aluminum, Shaft - Stainless Steel

Output Phase
A, B, Z (Line Driver Output)

Output Method
Line Driver (RS-422 Compatible)

Cable Length
2 meters (Standard)

Shock Resistance
50 G, 3 times X, Y, Z directions

Allowable Axial Load
Max. 20 N

About AUTONICS,ROTARY ENCODER, E40H8-2000-6-L-5

Select superior performance for industrial automation with the AUTONICS E40H8-2000-6-L-5 Rotary Encoder, the kingly choice for reliable motion control. This distinguished incremental encoder delivers 2000 PPR with triple output phases (A, B, Z) using a line driver robustly compatible with RS-422. Its aluminum housing and stainless steel shaft fortify durability, while shield grounding elevates noise immunity. Dominant in both cost-effectiveness and design, the E40H8 ensures accurate, stable readings even under rigorous vibration or shock, giving your systems a top-tier, trusted edge.

Exceptional Competitive Edge & Advanced Features

AUTONICS E40H8-2000-6-L-5 Rotary Encoder impresses with dominant vibration and shock resistance, premium ball bearings, and secure shield grounding. Distinguished by 2000 PPR high-resolution incremental output, its servo mount clamping guarantees reliable installation. Cost-effective and lightweight at just 200g, the kingly aluminum construction and stainless-steel shaft ensure durability. Superior compatibility and advanced line driver outputs support precise, consistent feedback for distinguished automation performance. Choose this encoder for optimal efficiency, extended lifespan, and seamless integration in demanding applications.

Availability, Market Reach & Rapid Fulfillment

Sample units of the AUTONICS E40H8-2000-6-L-5 can be handed over promptly upon request, with sample charges applying where necessary. Widely available across the main domestic market and regions through select suppliers and traders, this encoder benefits from quick dispatch and responsive shipping schedules. Wholesalers ensure the product reaches clients on time, making it easy for automation specialists to acquire reliable samples and receive full orders swiftly, streamlining the procurement process for urgent automation needs.

FAQs of AUTONICS,ROTARY ENCODER, E40H8-2000-6-L-5:

Q: How does the AUTONICS E40H8-2000-6-L-5 Rotary Encoder function in industrial automation?

A: This incremental rotary encoder provides precise positional feedback by delivering up to 2000 pulses per revolution via A, B, and Z output phases, compatible with RS-422 line drivers, aiding in accurate motion and speed control of automated systems.

Q: What are the primary benefits of using this encoder over others?

A: Its kingly combination of high resolution, robust aluminum and stainless steel build, cost-effectiveness, and shielding for noise immunity distinguishes it among top performers, ensuring stable operation even in harsh industrial settings.

Q: Where can samples or full units of the E40H8-2000-6-L-5 be obtained?

A: Select suppliers, traders, and wholesalers, especially in China and the main domestic market, offer sample and bulk purchase options for this distinguished encoder, with options for quick dispatch and on-time delivery.

Q: When is the best time to use shield grounding in this encoders installation?

A: Shield grounding should be implemented whenever the encoder is set up in environments prone to electrical noise, as it enhances signal integrity and reliable data transmission.

Q: What is the process for acquiring a sample, and is there a charge involved?

A: A sample can be requested from authorized suppliers or traders; typically, a sample charge applies, and the unit will be handed over or shipped promptly for evaluation prior to bulk procurement.
