AUTONICS ROTARY ENCODER 12-24VDC, ENC-1-2-T-24

AUTONICS ROTARY ENCODER 12-24VDC, ENC-1-2-T-24 Specification

Ambient Temperature
-10C to +70C

Sealed Type
Dust proof (non-oil seal)

Standard
CE approved

Features
2 channel output, high resolution, durable metal housing

Rated Voltage
12-24VDC

Starting Type
Direct

Bearing Type
Ball bearing

Voltage
12-24VDC

Current Type
DC

Product Type
Incremental rotary encoder

Protect Feature
IP50 protection

Speed
Max. 5000 rpm

Color
Silver with black cover

Dimension (L*W*H)
40 mm (Body Diameter) x 38 mm (Length)

Weight
Approx. 200g

Shaft Diameter
6 mm

Mounting Type
Servo Mount (Clamp Type)

IP Rating
IP50

Storage Temperature
-25C to +85C

Shaft Type
Solid shaft

Model
ENC-1-2-T-24

Shock Resistance
Max. 300 m/s2 (approx. 30G)

Allowable Radial Load
10 N

Resolution
100 pulses per revolution

Operating Humidity
35 to 85% RH

Output Type
NPN Open Collector

Connection Type
Cable type (Standard cable length: 2 m)

Output Phase
A, B (2-phase)

Vibration Resistance
10~55 Hz, Double amplitude 1.5 mm

Allowable Axial Load
5 N

About AUTONICS ROTARY ENCODER 12-24VDC, ENC-1-2-T-24

The AUTONICS ROTARY ENCODER 12-24VDC, Model ENC-1-2-T-24, is a top-rated device favored by professionals seeking precision at an unbeatable price. Now available with a remarkable price cut, this encoder guarantees first-class performance with its unmatchable resolution of 100 pulses per revolution and robust metal housing. Featuring Astonishing durability, IP50 protection, and high-speed operation up to 5000 rpm, it's engineered for demanding applications. Enjoy reliable dual-phase output, solid shaft construction, CE certification, and versatile mounting-all packed in a compact, lightweight design from a trusted supplier.

Versatile Commercial Applications and Usage Types

AUTONICS ROTARY ENCODER 12-24VDC, ENC-1-2-T-24 is designed for a wide array of commercial uses, including automation systems, robotics, and industrial machinery. Its solid shaft and high-resolution output make it ideal for precise position sensing in manufacturing processes. This device caters to usage types ranging from continuous monitoring to batch production, serving professionals in factories, equipment controls, and assembly lines seeking reliability and consistency.

Efficient Delivery, Packing, and Sample Policy

We prioritize swift and secure shipment for AUTONICS ROTARY ENCODER 12-24VDC, ENC-1-2-T-24. Each unit is carefully packed for safe dispatch and reliable goods transport, ensuring that products arrive in top condition. Delivery times depend on location and order volume, typically completed within standard timeframes. For your confidence, samples are available upon request, following our transparent sample policy, helping you evaluate performance before bulk ordering.

FAQ's of AUTONICS ROTARY ENCODER 12-24VDC, ENC-1-2-T-24:

Q: How do I install the AUTONICS ROTARY ENCODER 12-24VDC, ENC-1-2-T-24 in commercial machinery?

A: The encoder features a servo mount (clamp type) for easy, secure installation. Simply connect the cable type output (2-meter standard length) to your system following the wiring instructions. Ensure the mounting surface supports the shaft diameter (6 mm) and maintain the allowed axial and radial loads during setup.

Q: What makes the AUTONICS ENC-1-2-T-24 encoder suitable for industrial use?

A: Its solid shaft construction, high resolution (100 pulses/rev), and durable metal housing provide long-lasting, precise performance in harsh environments. It is CE approved, dust-proof (IP50), and designed to cope with vibration, shock, and fluctuations in temperature and humidity.

Q: When can I expect my order to be shipped and delivered?

A: After order confirmation, shipment and packing are promptly initiated. Delivery typically adheres to standard industry timelines, dependent on your location and chosen quantity. You'll receive regular updates regarding dispatch and goods transport status.

Q: Where can I request a product sample or review your sample policy?

A: Samples can be requested directly from the supplier or trader. Our sample policy is transparent-please contact our sales team for detailed information on eligibility, process, and availability.

Q: What are the primary benefits of using the AUTONICS ENC-1-2-T-24 encoder?

A: You will benefit from precision motion control, robust build quality, exceptional reliability, and first-class performance at an unbeatable price. Its ease of installation and compatibility with diverse systems further enhances its appeal for commercial and industrial users.
