PANASONIC DIGITAL PRESSURE SENSOR, DP-102

PANASONIC DIGITAL PRESSURE SENSOR, DP-102 Specification

Mounting Type
Panel or DIN rail mounting

Wireless
No

Operating Temperature
-10C to +50C (No freezing or condensation)

Measurement Range
-100 to +100 kPa

Sensor Type
Pressure Sensor

Response Time
2.5 ms (ch1), 5 ms (ch2)

Application
Air and non-corrosive gas pressure monitoring

Features
Dual display, compact size, easy setting via buttons

Interface
3-wire connection

IP Rating
IP40

Sensitivity
Adjustable

Power Consumption
Max. 960 mW

Cable Length
2 meters

Signal Type
Digital / Analog

Product Type
Digital Pressure Sensor

Material
ABS Resin

Input
Pressure Input

Output
NPN Open Collector/Analog Voltage Output

Function
Detection of pressure and display of measured value

Usage
Industrial automation, process control

Accuracy
2% F.S. (at +25C)

Resolution
0.01 kPa

Voltage
12-24V DC 10%

Weight
Approx. 65g (including cable)

Pressure Type
Gauge Pressure

Shock Resistance
100 m/s², 3 times each (X, Y, Z axis)

Display Digits
4-digit dual display

Control Output
2 outputs, NPN open-collector

Surge Protection
Built-in

Process Connection
Rc(PT) 1/8, M5 female thread

Vibration Resistance
10 to 150 Hz, amplitude 0.75 mm (X, Y, Z directions)

Repeatability
±0.2% F.S. ± 1 digit

Reverse Polarity Protection
Available

Hysteresis
Variable

Enclosure Material
Polycarbonate front panel

Display
2-Color Digital LCD (Red/Green)

About PANASONIC DIGITAL PRESSURE SENSOR, DP-102

Shop Now to experience the resplendent performance of the PANASONIC DIGITAL PRESSURE SENSOR, DP-102-one of the most sought-after devices in industrial automation. This distinguished sensor boasts a top-rated, 2-color digital LCD (Red/Green), a 4-digit dual display, and advanced features such as a variable hysteresis and built-in surge protection. Engineered with precision, it ensures 0.2% repeatability and 2% F.S. accuracy. Easily mountable on panels or DIN rails, the DP-102 is perfect for detecting and displaying air or non-corrosive gas pressure. Redeem reliability and exceptional performance today!

Versatile Applications & Distinct Features

The PANASONIC DIGITAL PRESSURE SENSOR, DP-102 excels in areas like industrial process control, automation systems, and air or non-corrosive gas pressure monitoring. Engineered for panel or DIN rail mounting, it fits seamlessly on surfaces within machinery, assembly lines, and control cabinets. Distinguished special features include dual digital displays, adjustable sensitivity, and easy button-based settings, while its robust construction ensures performance even in demanding environments. Benefit from enhanced functionality and seamless integration in any industrial context.

Export Markets, Domestic Reach & Swift Supply

The PANASONIC DIGITAL PRESSURE SENSOR, DP-102 commands attention in major export markets, particularly in China and other industrial hubs. Domestically, it serves diverse sectors requiring reliable pressure detection. Our efficient packaging process and competitive sale price make this product accessible to traders, wholesalers, and suppliers. Thanks to our quick dispatch and ample supply ability, orders are fulfilled promptly-ensuring your automation or process control project stays on track and your business keeps thriving.

FAQ's of PANASONIC DIGITAL PRESSURE SENSOR, DP-102:

Q: How does the DP-102 sensor enhance industrial automation processes?

A: The DP-102 sensor provides precise pressure detection and dual digital displays, allowing for real-time monitoring and control in automation systems. Its compact design and easy setup streamline integration, contributing to efficient process management.

Q: What surfaces and applications is the DP-102 suitable for?

A: This sensor is ideal for mounting on panels, DIN rails, control cabinets, and within machinery assemblies. It is optimized for monitoring air and non-corrosive gas pressure in industrial settings.

Q: When should businesses consider using the DP-102 pressure sensor?

A: The DP-102 is recommended when accuracy, repeatability, and reliability in air or non-corrosive gas pressure monitoring are essential-particularly in automated production lines, equipment monitoring, and process control.

Q: Where can I purchase and redeem the DP-102 for my projects?

A: You can acquire the DP-102 from authorized suppliers, traders, and wholesalers specializing in industrial automation components. Look for quick dispatch and competitive pricing to maximize value for your business.

Q: What are the benefits of the sensor's advanced features, like dual outputs and built-in protections?

A: Dual NPN open-collector outputs enable flexible control, while surge and reverse polarity protections safeguard the sensor against electrical hazards, increasing reliability and service life.
