PANASONIC DIGITAL PRESSURE SENSOR, DP-102A-E-P

PANASONIC DIGITAL PRESSURE SENSOR, DP-102A-E-P Specification

IP Rating
IP40

Sensitivity
High (0.01 kPa)

Interface
3-Wire connection (Brown: +V, Blue: 0V, Black: Output)

Wireless
No

Features
Digital display, 3-color LCD, Key lock, Peak hold function, Selectable response time

Power Consumption
Max. 960 mW (40 mA at 24 V DC)

Signal Type
Digital Output

Operating Temperature
0 to +50C (No condensation or freezing)

Response Time
2.5 ms / 5 ms / 100 ms / 500 ms (selectable)

Mounting Type
Panel Mount / DIN Rail Mount

Sensor Type
Electrostatic Capacity Type

Cable Length
2 meters

Measurement Range
-100.0 to +100.0 kPa

Application
Air, Non-corrosive Gas Measurement

Product Type
Digital Pressure Sensor

Material
Plastic / Metal

Input
Pressure

Output
NPN Open Collector

Function
Pressure Measurement and Monitoring

Usage
Industrial Automation, Pneumatic Systems

Accuracy
2% F.S.

Resolution
0.01 kPa

Voltage
12-24 V DC

Weight
Approx. 50g

Display Digits
4 Digit Display

Storage Temperature
-10 to +60C

Hysteresis
Variable (selectable)

Vibration Resistance
10 to 150 Hz, amplitude 0.75 mm, XYZ directions

Set Pressure Units
kPa, kgf/cm2, bar, psi, mmHg, inHg

Shock Resistance
Approx. 500 m/s2 (50G), XYZ directions

Reverse Connection Protection
Yes

Ambient Humidity
35 to 85% RH, non-condensing

Number of Outputs
2 (Independent)

Overcurrent Protection
Yes

Display Type
3-Color Digital LCD

About PANASONIC DIGITAL PRESSURE SENSOR, DP-102A-E-P

Spotlight your industrial setups with the prodigious PANASONIC DIGITAL PRESSURE SENSOR, DP-102A-E-P-blending lustrous precision and redoubtable durability. Trending now among industrial automation experts, this digital sensor offers a brilliant 3-color LCD display, delivering highly accurate, selectable measurements in a plethora of pressure units. Its dual-output versatility and robust protection against vibration, overcurrent, and reverse connection ensure dependable operation. Featuring a sleek plastic/metal build and smart panel or DIN rail mounting, this sensor excels in pneumatic system control where reliability and speed are paramount.

Commercial Excellence: Features & Usage

The PANASONIC DIGITAL PRESSURE SENSOR, DP-102A-E-P is a trending solution in commercial and industrial automation, particularly for pneumatic systems. This advanced sensor features a lustrous 3-color digital LCD with key lock and peak hold functionalities. Its selectable response times and high sensitivity make it ideal for precision air and non-corrosive gas measurements. With variable hysteresis and multiple pressure unit settings, it empowers users to customize readings for diverse commercial applications.

Packaging, Market Reach & Supply Process

Packing & Dispatch of the PANASONIC DIGITAL PRESSURE SENSOR, DP-102A-E-P is handled with meticulous care, ensuring each unit is securely packed for global delivery. Order Processing times are streamlined, optimizing export readiness primarily to major industrial markets across China, Asia, and beyond. With a robust supply ability, orders are fulfilled swiftly to meet urgent project requirements, positioning this sensor as a reliable choice for traders, suppliers, and wholesalers internationally.

FAQ's of PANASONIC DIGITAL PRESSURE SENSOR, DP-102A-E-P:

Q: How is the PANASONIC DP-102A-E-P pressure sensor used in industrial environments?

A: The sensor is primarily used for accurate pressure measurement and monitoring in industrial automation, particularly within pneumatic systems handling air and non-corrosive gases. Its high sensitivity and customizable settings make it suitable for demanding applications.

Q: What features make the DP-102A-E-P a trending sensor in the market?

A: Its prodigious accuracy (2% F.S.), selectable response times, robust build, 4-digit 3-color LCD display, and advanced protection mechanisms distinguish it as a spotlight in modern automation.

Q: Where is the PANASONIC DIGITAL PRESSURE SENSOR mainly applied?

A: This sensor is widely applied in commercial manufacturing processes, automated pneumatic systems, and environments requiring precise, real-time pressure data with digital output.

Q: What is the process for installing the DP-102A-E-P sensor?

A: Installation involves either a panel mount or DIN rail mount, with a straightforward 3-wire electrical connection. The 2-meter cable ensures flexible setup inside automation panels.

Q: What benefits do users gain from the key lock and peak hold functions?

A: Key lock secures settings against accidental changes, while peak hold allows continuous monitoring of maximum pressure values, ensuring operational safety and traceability.
