OMRON SMART SENSOR, ZX1-LD50A81

OMRON SMART SENSOR, ZX1-LD50A81 Specification

IP Rating
IP67

Wireless
No

Measurement Range
50 15 mm (35-65 mm)

Housing Material
Aluminum alloy

Operating Temperature
-10C to +55C

Cable Length
2 m

Power Consumption
Max. 1.0 W

Sensor Type
Laser Displacement Sensor

Response Time
0.5 ms/1 ms/2 ms/4 ms selectable

Application
Industrial automation, quality control, thickness measurement

Ingress Protection
IP67

Interface
Connectors (M8, 4-pin)

Mounting Thread
M3 (mounting holes)

Sensitivity
Adjustable

Mounting Type
Panel or bracket mount

Spectral Range
650 nm (red visible laser)

Signal Type
Analog and digital

Features
Compact design, high-precision, easy installation

Product Type
Smart Sensor

Material
Aluminum, Plastic

Input
24 VDC (power supply)

Output
NPN/PNP selectable, analog output (voltage/current)

Function
Laser displacement measurement

Usage
Position and distance measurement

Accuracy
0.05% of F.S.

Resolution
10 m

Voltage
12 to 24 VDC

Weight
Approx. 100 g

Shock Resistance
500 m/s2, 3 times in each direction

Laser Class
Class 2 (IEC60825-1)

Vibration Resistance
10 to 55 Hz, 1.5 mm double amplitude

Linearity
0.25% F.S.

Case Color
Silver / Black

Light Source
Red semiconductor laser

Indicator
Operation status LED

Ambient Humidity
35% to 85% RH (non-condensing)

Control Output
NPN/PNP open-collector, 100 mA max.

Storage Temperature
-20C to 70C

OMRON SMART SENSOR, ZX1-LD50A81 About

Discover the exclusive OMRON SMART SENSOR ZX1-LD50A81-a rarefied advancement in laser displacement measurement. With a noble red semiconductor laser (Class 2, IEC60825-1), this compact device offers astounding accuracy of 0.05% of F.S. and resolution up to 10 m. Engineered with IP67 ingress protection and robust aluminum alloy housing, it withstands harsh environments. Procure this affordable, high-precision solution for position, distance, or thickness measurements in industrial automation and quality control. NPN/PNP output, analog signals, and selectable response times ensure versatile, reliable performance for demanding applications.

Versatile Application and Surface Compatibility

The OMRON SMART SENSOR ZX1-LD50A81 is engineered for use on a diverse range of surfaces, including metals, plastics, and composites. Ideal for industrial automation, it excels in quality control and thickness measurement tasks. This sensor is typically used as a precise position and distance measurement instrument, ensuring consistent results at production sites, laboratories, or inspection stations. Its compact design and adjustable sensitivity make it suitable for seamless integration across multiple industry environments.

Efficient Supply and Transport Solutions

OMRON SMART SENSOR ZX1-LD50A81 is supplied with robust transport services, ensuring timely delivery and secure handling. Our main export markets include Asia, Europe, and North America, with competitive list prices and flexible supply abilities to meet bulk orders. Goods are typically shipped from the designated FOB port in China, with transportation coordinated for both small-scale and large-scale requirements. Expert logistical support guarantees that your procurement needs are met with reliability and affordability.

FAQ's of OMRON SMART SENSOR, ZX1-LD50A81:

Q: How does the OMRON SMART SENSOR ZX1-LD50A81 perform in harsh industrial environments?

A: The sensor features a rugged aluminum alloy housing and IP67 ingress protection, making it highly resistant to dust, water, vibrations, and shocks, and ensuring reliable performance even in demanding settings.

Q: What are the main applications for the OMRON ZX1-LD50A81 sensor?

A: This sensor is widely used in industrial automation for position and distance measurement, quality control, thickness assessment, and precise monitoring of various materials including metals, plastics, and more.

Q: Where can I install the ZX1-LD50A81 sensor?

A: The sensor can be mounted on panels or brackets within manufacturing lines, inspection stations, or laboratory environments, offering flexible integration options via M3 mounting threads and 2-meter cable connections.

Q: What benefits does the ZX1-LD50A81 offer for quality control processes?

A: It delivers high-precision measurement with stringent linearity (0.25% F.S.) and resolution, supporting rapid response times (as fast as 0.5 ms) and ensuring accurate detection to uphold stringent quality standards.

Q: What is included in the supply process for the ZX1-LD50A81?

A: Our supply process involves secure packaging, efficient export via FOB China ports, and careful transportation to international markets, accompanied by transport services tailored to suit order volumes and delivery timelines.
