ORBITAL INCREMENTAL ENCODER,ISC5810-001G-720-ABZ3-5/24L

ORBITAL INCREMENTAL ENCODER,ISC5810-001G-720-ABZ3-5/24L Specification

Noise Level
Low

Features
ABZ3 Output, Robust and compact design, Wide voltage range

Sealed Type
Sealed

Efficacy
High Accuracy

Rated Voltage
5-24V DC

Starting Type
Direct

Standard
CE, RoHS

Voltage
5-24V DC

Ambient Temperature
-20C to +85C

Cooling Method
Air Cooled

Current Type
DC

Bearing Type
Ball Bearing

Product Type
Incremental Encoder

Protect Feature
Reverse Polarity Protection

Phase
Single

Speed
Up to 6000 RPM

Color
Black

Dimension (L*W*H)
50 mm diameter x 38 mm length (approx.)

Weight
Approx. 150 g

Shaft Diameter
8 mm

Mounting Type
Clamp Mount

IP Rating
IP54

Model Number
ISC5810-001G-720-ABZ3-5/24L

Output Mode
NPN/PNP or Differential (Line Driver)

Cable Length
2 m (standard)

Withstand Voltage
AC 500V 60s

Operating Humidity
35-85% RH

Storage Temperature
-25C to +90C

Output Signal
ABZ, Complementary 3 Channels

Insulation Resistance
>100M (500VDC)

Resolution
720 PPR (Pulses Per Revolution)

Body Material
Aluminium Alloy Housing

Response Time
1 s

Connection Type
Radial Lead with Connector

Shaft Type
Solid Shaft

About ORBITAL INCREMENTAL ENCODER,ISC5810-001G-720-ABZ3-5/24L

Presenting the ORBITAL INCREMENTAL ENCODER, ISC5810-001G-720-ABZ3-5/24L, now in Clearance for unrivaled value and personalization to your automation needs. With invincible performance, this encoder boasts a crowning 720 PPR resolution, solid shaft, and robust aluminium alloy housing, ensuring reliability under demanding conditions. The versatile output signal (NPN/PNP or Differential) and comprehensive protective features-including IP54 rating and reverse polarity protection-make it ideal for diverse industrial environments. Quick to install via clamp mount and radial connector, it's the ultimate choice for accuracy, efficiency, and long-term durability.

Applications and Competitive Advantage

Ideal for industrial automation, CNC machinery, and robotics, the ORBITAL INCREMENTAL ENCODER excels in high-accuracy position sensing and control. Its usage type suits both new installations and system upgrades. The robust build quality, wide operating voltage, and invincible protection features distinguish it from competitors, delivering crowning performance and long service life in challenging environments.

Export Markets and Delivery Excellence

Our encoder is exported globally to major industrial markets including Europe, Asia, and the Americas. With quick dispatch times, cost-effective transport services, and minimal expenditure on shipping, we ensure your order reaches you without delay. The product is shipped from China's prime FOB ports, promising swift logistics and seamless delivery for your business operations.

FAQ's of ORBITAL INCREMENTAL ENCODER,ISC5810-001G-720-ABZ3-5/24L:

Q: How can I integrate the ORBITAL INCREMENTAL ENCODER into my existing automation system?

A: Integration is simple-connect the encoder using the provided radial lead with connector, and select from NPN/PNP or Differential (Line Driver) output types to fit your system configuration. The standard 2 m cable and clamp mount make installation efficient.

Q: What primary benefits does this encoder offer over similar products?

A: The encoder delivers unrivaled value through high 720 PPR resolution, robust aluminium housing, invincible protective features like IP54 and reverse polarity protection, and low noise. Its versatile output modes and wide voltage range make it exceptionally adaptable.

Q: Where is the ORBITAL INCREMENTAL ENCODER typically used?

A: It is widely applied in industrial automation, conveyor systems, CNC machines, robotics, and equipment requiring accurate position feedback and rapid response times.

Q: What is the process for ordering and receiving this encoder internationally?

A: Place your order via our supplier, trader, or wholesaler channels. Quick dispatch and reliable transport services are utilized to ensure delivery from China's main FOB ports with minimal expenditure on logistics.

Q: What are the storage and operational temperature ranges for this encoder?

A: The storage temperature range is -25C to +90C, while operational ambient temperatures span from -20C to +85C, supporting versatility in various environments.
