ORBITAL INCREMENTAL ENCODER, ISC3806-H03-G-2000-ABZ3-5/24L

ORBITAL INCREMENTAL ENCODER, ISC3806-H03-G-2000-ABZ3-5/24L Specification

Starting Type
Direct On Line

Features
2000 PPR, ABZ+3 Phase Output, Short Circuit Protection, Wide Voltage Input

Noise Level
Low

Current Type
DC

Efficacy
High Accuracy

Ambient Temperature
-20C to +80C

Sealed Type
Sealed

Standard
CE

Bearing Type
Ball Bearing

Rated Voltage
5-24V DC

Voltage
5-24V DC

Product Type
Rotary Incremental Encoder

Protect Feature
Reverse Polarity Protection

Phase
Single Phase

Speed
Up to 6000 RPM

Color
Black and Silver

Dimension (L*W*H)
External Diameter: 38mm; Length: 42mm (housing excl. shaft)

Weight
Approx. 180g

Shaft Diameter
6mm

Mounting Type
Shaft Mount

IP Rating
IP50

Output Signals
A, B, Z, A-, B-, Z- (ABZ3) channels

Cable Length
2 meters

Pulses Per Revolution (PPR)
2000 PPR

Response Frequency
200 kHz Max.

Signal Output
Quadrature

Shaft Material
Stainless Steel

Housing Material
Aluminum Alloy

Output Phase
A, B, Z (plus complementary)

Insulation Resistance
500 M at 500V DC

Model Number
ISC3806-H03-G-2000-ABZ3-5/24L

Dielectric Strength
AC 500V 60Hz 1min

Storage Temperature
-30C to +85C

Connector Type
Lead Wire/Cable

Shock Resistance
1000 m/s2, 6 ms

Vibration Resistance
50 m/s2 (10-2000 Hz)

Output Type
NPN Open Collector

About ORBITAL INCREMENTAL ENCODER, ISC3806-H03-G-2000-ABZ3-5/24L

Buy Online the hot-selling ORBITAL INCREMENTAL ENCODER, ISC3806-H03-G-2000-ABZ3-5/24L and experience top-notch precision in industrial automation! This trending incremental encoder delivers a magnificent 2000 PPR count with dazzling ABZ3 channel output for high-accuracy positioning. Featuring robust aluminum housing and stainless steel shaft, it withstands extreme environments with IP50 sealing, reverse polarity protection, and shock/vibration resistance. Its wide 5-24V DC input, short-circuit protection, quad-phase output, and low noise ensure reliability. Perfect for suppliers, traders, and wholesalers in China seeking reliable, direct-on-line, high-speed motion control solutions.

Key Features and Versatile Applications

The ISC3806-H03-G-2000-ABZ3-5/24L shines with special features like its 2000 pulses per revolution, multiple phase outputs (A, B, Z plus complementary), and short-circuit protection. Its high response frequency and robust build allow deployment in automation, robotics, textile machines, conveyors, and CNC systems. The sealed, ball-bearing design ensures durability in harsh settings, making it a dependable choice for electronics manufacturing, assembly lines, and industrial process control environments alike.

Supply, Transit, and Delivery Estimates

We estimate a consistent supply ability for the ORBITAL INCREMENTAL ENCODER, enabling prompt shipment from our China FOB port. Goods transport is streamlined for both domestic and international delivery, typically reaching your destination within 7-15 days depending on location and order size. Our established logistics ensure quick processing and reliable transit, so you can plan your production schedules with confidence and minimal downtime.

FAQ's of ORBITAL INCREMENTAL ENCODER, ISC3806-H03-G-2000-ABZ3-5/24L:

Q: How does the ORBITAL INCREMENTAL ENCODER ensure high accuracy in applications?

A: The encoder delivers 2000 pulses per revolution with ABZ3 phase output signals, providing precise position and speed feedback for high-accuracy applications in automation and motion control systems.

Q: What types of usage environments is this encoder suitable for?

A: With its IP50 rating, shock and vibration resistance, and a broad ambient temperature range, this encoder is ideal for challenging industrial environments such as robotics, conveyor systems, and CNC machinery.

Q: When can I expect my order of the ISC3806-H03-G-2000-ABZ3-5/24L to be delivered?

A: Delivery typically takes 7-15 days after shipment, depending on your location and order volume. All units are shipped from our FOB port in China using reliable goods transport partners.

Q: Where can the ISC3806-H03-G-2000-ABZ3-5/24L encoder be installed?

A: Designed for shaft mounting, this encoder easily integrates into a wide range of rotary applications requiring precise movement detection and feedback.

Q: What benefits does the complementary output (ABZ3) provide?

A: Complementary outputs reduce signal interference, enabling better noise immunity and giving more reliable readings in electrically noisy industrial environments.

Q: How does the encoder address safety and reliability concerns?

A: The device features reverse polarity and short-circuit protection, low noise level, and high insulation resistance to ensure safe operation and long-term reliability.
