PEPPERL FUCHS ,INCREMENTAL ROTARY ENCODER, TVI40N-09TK2T6TN-01000

PEPPERL FUCHS ,INCREMENTAL ROTARY ENCODER, TVI40N-09TK2T6TN-01000 Specification

Voltage
4.75 V to 30 V DC

Ambient Temperature
-20 C to +85 C operating

Features
Robust design, high resolution, high accuracy, compact dimensions

Current Type
DC

Bearing Type
Ball bearing

Torque
Starting torque 1.5 Ncm at 20C

Standard
CE

Product Type
Incremental Rotary Encoder

Protect Feature
Reverse polarity protection, short-circuit protection (outputs)

Speed
6000 rpm max.

Color
Black/Silver

Dimension (L*W*H)
40 mm dia x approx. 36 mm length (without shaft)

Weight
Approx. 0.2 kg

Shaft Diameter
6 mm solid shaft

Mounting Type
Clamp flange, servo or synchro flange (customer selectable)

IP Rating
IP65 (shaft side), IP50 (housing side)

Model
TVI40N-09TK2T6TN-01000

Light Source
Infrared LED

Electrical Connection
Connector, M23, 12-pin

Permissible Rotational Speed
Up to 12000 rpm (mechanical)

Output Signal Type
TTL/RS422 (differential)

Shaft Load
Axial 40 N / Radial 60 N

Pulse Count (ppr)
1000 pulses per revolution

Material
Aluminium housing, stainless steel shaft

About PEPPERL FUCHS ,INCREMENTAL ROTARY ENCODER, TVI40N-09TK2T6TN-01000

Ending Soon at a Reduced Price-introducing the meritorious PEPPERL FUCHS Incremental Rotary Encoder TVI40N-09TK2T6TN-01000. This distinguished encoder features robust aluminium housing, a stainless steel shaft, and high-resolution 1000 pulses per revolution with TTL/RS422 output. The gorgeous black and silver compact design includes advanced reverse polarity and short-circuit protection, supporting up to 12000 rpm. Ideal for precise, high-speed industrial applications, its IP65 shaft-side rating ensures resilience. Achieve top performance, reliability, and accurate measurement-ultimately setting benchmarks as a preferred choice among suppliers, traders, and wholesalers.

Versatile Use and Noteworthy Features

PEPPERL FUCHS TVI40N-09TK2T6TN-01000 delivers remarkable precision across various commercial settings including automation systems and robotics. Its advanced safety features, high mechanical speed tolerance, and robust build withstand demanding environments. Using common mounting types such as clamp, servo, or synchro flange, installation is flexible and straightforward. The encoder's high accuracy and reliable outputs make it indispensable for manufacturing and processing plants that demand consistent, meritorious performance.

Domestic Market Coverage and Delivery Terms

This top-tier encoder primarily serves the robust Indian domestic market, with suppliers also offering FOB shipping from China. Products are expertly freighted, ensuring prompt delivery and secure arrival. Multiple payment terms facilitate smoother transactions, including advance payments and net terms on approval. Customers can expect their distinguished rotary encoder to be delivered efficiently, ensuring seamless incorporation into their automation lines or machinery with minimal delay.

FAQ's of PEPPERL FUCHS ,INCREMENTAL ROTARY ENCODER, TVI40N-09TK2T6TN-01000:

Q: How do I install the PEPPERL FUCHS Incremental Rotary Encoder TVI40N-09TK2T6TN-01000?

A: Installation is straightforward with selectable mounting options such as clamp flange, servo, or synchro flange. Ensure the 6 mm solid shaft is correctly aligned, and connect using the M23, 12-pin connector for optimal signal transmission.

Q: What are the primary commercial applications for this rotary encoder?

A: This encoder is ideal for industrial automation, packaging machinery, robotics, and process control systems where high accuracy, speed, and durable operation are required.

Q: What benefits does the encoder's high IP rating provide?

A: The IP65 rating on the shaft side protects against dust and water ingress, enhancing equipment longevity and reliability, while the compact housing's IP50 rating supports versatile integration in controlled environments.

Q: When should the encoder be selected based on its output signal?

A: Select this model when TTL/RS422 (differential) output is needed, especially for applications requiring noise immunity and fast, accurate feedback in motor control or automated processes.

Q: Where is the main supply and distribution conducted from?

A: Although available domestically throughout India, primary supply and FOB shipments are coordinated from China, ensuring wide-reaching access and streamlined logistics for diverse industries.

Q: What is the process for ensuring safe delivery and arrival?

A: Encoders are freighted securely from the supplier, packaged to prevent damage during transit, and tracked to ensure timely arrival at your designated location.
