ORBITAL INCREMENTAL ENCODER, ISC5810-001G-250-ABZ1-5-30K

ORBITAL INCREMENTAL ENCODER, ISC5810-001G-250-ABZ1-5-30K Specification

Ambient Temperature
-20C to +85C

Voltage
5-30V DC

Features
ABZ+Reverse Signal Output

Standard
IEC/CE

Bearing Type
Ball Bearing

Sealed Type
Sealed Housing

Product Type
Incremental Encoder

Color
Silver & Black

Dimension (L*W*H)
58mm (diameter)

Weight
Approx. 300g

Shaft Diameter
10mm

Mounting Type
Clamp/Servo Mount

IP Rating
IP65

Vibration Resistance
50 m/s2 (10Hz to 55Hz)

Electrical Connection
Radial Cable Outlet

RoHS Compliance
Yes

Operating Humidity
35%-85% RH (Non-condensing)

Application
Industrial Automation, Motion Control, Robotics

Model Number
ISC5810-001G-250-ABZ1-5-30K

Shaft Type
Solid Shaft

Operating Voltage Tolerance
5%

Output Signal
A, B, Z, Reverse (Line Driver/Push-Pull)

Resolution
250 PPR (Pulses Per Revolution)

Maximum Response Frequency
100kHz

Life Expectancy
More than 100 million pulses

Cable Length
Standard 2 meters

Housing Material
Aluminum Alloy

Shock Resistance
980 m/s2, 6ms

About ORBITAL INCREMENTAL ENCODER, ISC5810-001G-250-ABZ1-5-30K

Capitalise on precision and reliability with the acclaimed ORBITAL INCREMENTAL ENCODER, ISC5810-001G-250-ABZ1-5-30K. Explore crackerjack performance with elite 250 PPR resolution, ABZ plus reverse output signals, and robust aluminum alloy housing. This exquisite encoder promises exceptional vibration and shock resistance, an impressive 100kHz max frequency response, and a sealed IP65-rated exterior for demanding environments. Compatible with industrial automation, robotics, and motion control, this elite device ensures seamless integration and longevity exceeding 100 million pulses. RoHS compliant and engineered to IEC/CE standards, it's your solution for precision and durability.

Versatile Applications & Key Features

The ISC5810-001G-250-ABZ1-5-30K Incremental Encoder finds invaluable use in industrial automation, robotics, and advanced motion control systems. Its solid 10mm shaft, precise 250 PPR resolution, and ABZ+Reverse signal output are tailored for real-time position and speed monitoring. To maximise efficiency, mount the unit via clamp or servo mounts, and connect using its radial cable outlet. Operating between -20C to +85C, with an IP65-sealed aluminum housing, this elite encoder ensures steadfast performance in diverse conditions.

Packaging, Delivery & Domestic Market Details

Your Purchase Order for the ISC5810-001G-250-ABZ1-5-30K encoder is carefully managed-each unit is shipped in secure, industrial-grade packaging to ensure safe arrival. We serve the main domestic market across China, catering to suppliers, traders, and wholesalers with prompt delivery options. Sample policy allows prospective clients to request evaluation units before bulk orders. Expect swift processing and reliable shipping logistics from confirmation to delivery at your facility.

FAQ's of ORBITAL INCREMENTAL ENCODER, ISC5810-001G-250-ABZ1-5-30K:

Q: How can I use the ISC5810-001G-250-ABZ1-5-30K incremental encoder in my automation system?

A: Simply install the encoder using a clamp or servo mount, connect the radial cable outlet to your motion control device, and configure the A, B, Z, and reverse signals for real-time position feedback in your industrial automation setup.

Q: What application areas benefit most from this encoder?

A: This encoder is ideal for applications in industrial automation, robotics, and motion control systems where high reliability and precision feedback are necessary for accurate positioning and speed measurement.

Q: What are the main benefits of choosing the ISC5810-001G-250-ABZ1-5-30K?

A: Key benefits include high durability (exceeding 100 million pulses), a sealed IP65 aluminum alloy housing, elite shock and vibration resistance, and compliance with IEC/CE and RoHS standards, making it reliable for demanding environments.

Q: When will my order be shipped after placing a purchase order?

A: Orders are typically processed promptly upon receipt, with shipping schedules depending on the order quantity. For most standard orders, delivery is arranged swiftly through trusted logistics partners.

Q: Where does the product ship from, and which markets does it serve?

A: The ISC5810-001G-250-ABZ1-5-30K encoder ships from China and primarily serves the domestic Chinese market, including suppliers, traders, and wholesalers.

Q: How do I request a sample for evaluation before placing a bulk order?

A: Our sample policy allows you to request evaluation units. Simply contact our sales team with your requirements, and we will process your request and arrange shipment as per policy guidelines.
