AUTONICS ROTARY ENCODER, E50S8-200-3-T-1

AUTONICS ROTARY ENCODER, E50S8-200-3-T-1 Specification

Bearing Type
Ball Bearing

Ambient Temperature
-10°C to 70°C

Features
Incremental rotary encoder

Product Type
Rotary Encoder

Shaft Diameter
8 mm

Mounting Type
Servo Mount

IP Rating
IP50

Connector Type
Cable Type

Shaft Load
Radial 10N / Axial 5N

Insulation Resistance
Min. 100 M (at 500 VDC)

Resolution
200 pulses per revolution (P/R)

Output
NPN Open Collector

Shock Resistance
300 m/s2

Output Phase
3-phase (A, B, Z)

Model
E50S8-200-3-T-1

Supply Voltage
5-24 VDC

Vibration Resistance
50 m/s2 (10~500 Hz)

Body Material
Aluminum Housing

Rotational Speed
Max. 5000 rpm

Response Frequency
Max. 300 kHz

Encoder Type
Incremental

Cable Length
2 m

About AUTONICS ROTARY ENCODER, E50S8-200-3-T-1

Experience a noteworthy Price Cut on the AUTONICS ROTARY ENCODER, E50S8-200-3-T-1, the paragon of precision in motion detection. Get fresh performance with a distinguished incremental encoder, featuring 200 pulses per revolution and robust NPN Open Collector output. Suited for demanding applications, its aluminum housing and servo mounting deliver reliability under harsh vibration and shock. With a max rotational speed of 5000 rpm and broad supply voltage (5-24 VDC), this encoder meets high industrial standards. Available through leading supplier, trader, and wholesaler networks in Vietnam.

Versatile Plant and General Applications

The AUTONICS ROTARY ENCODER, E50S8-200-3-T-1 excels in plant automation, offering superior feedback for motors, conveyor systems, and positioning tasks. Its incremental design, rugged aluminum housing, and 3-phase output make it ideal for both specialized and general industrial applications such as packaging lines, textile machinery, and robotics. This encoders reliability ensures precise motion detection in demanding environments, supporting a wide range of manufacturing facilities and automation projects where performance consistency is paramount.

Reliable Packaging, Export Strength, and Supply

We offer the AUTONICS ROTARY ENCODER with careful valuation and secure packaging, ensuring the product reaches you in optimal condition. Each unit is boxed with protective materials for safe domestic and international transport services. With strong export capabilitiesmainly throughout Southeast Asiaour supply chain guarantees continuous availability. Bulk orders are easily accommodated, and our dedicated logistics partners ensure timely delivery, making us a trustworthy source for your industrial and automation requirements.

FAQs of AUTONICS ROTARY ENCODER, E50S8-200-3-T-1:

Q: How does the AUTONICS E50S8-200-3-T-1 encoder operate in industrial environments?

A: This encoder is designed to function reliably in harsh industrial settings, featuring an aluminum housing, high vibration and shock resistance, and a wide operating temperature range from -10C to 70C.

Q: What is the process of installing this rotary encoder?

A: The encoder uses a servo mount and ball bearing structure, making the installation process straightforward. The 2-meter cable type connection is flexible for diverse machine layouts.

Q: When is it beneficial to use this encoder over other models?

A: Its high pulse resolution (200 P/R) and robust construction make it beneficial for applications demanding precise feedback, such as conveyor systems, motor controls, and automated assembly lines.

Q: Where can the AUTONICS ROTARY ENCODER be applied?

A: This distinguished encoder is suitable for a range of settings: manufacturing plants, packaging facilities, textile production lines, and automation systems requiring accurate position feedback.

Q: What are the main advantages of the E50S8-200-3-T-1 encoder?

A: Key benefits include its sturdy aluminum construction, extensive supply voltage range (5-24 VDC), exceptional response frequency (up to 300 kHz), and reliable three-phase output suitable for advanced control systems.
