ORBITAL INCREMENTAL ENCODER,ISC5810-001G-1024-ABZ1-5-30K

ORBITAL INCREMENTAL ENCODER,ISC5810-001G-1024-ABZ1-5-30K Specification

Features
Incremental encoder, ABZ outputs, sturdy aluminiun housing

Noise Level
Low

Standard
ISC5810-001G-1024-ABZ1-5-30K

Sealed Type
Sealed Housing

Bearing Type
Ball Bearing

Current Type
DC

Ambient Temperature
-20C to +85C

Rated Voltage
5 V DC

Voltage
5 V DC

Product Type
Rotary Encoder

Protect Feature
Reverse polarity protection

Phase
2 Phase, ABZ Channels

Speed
Max. 5000 RPM

Color
Black/Silver

Dimension (L*W*H)
58 mm diameter x 50 mm length

Weight
Approx. 350 g

Shaft Diameter
8 mm

Mounting Type
Clamping Flange

IP Rating
IP30

Response Time
1 s

Insulation Resistance
100 M min. (at 500 V DC)

Cable Length
2 meters

Vibration Resistance
10~55 Hz, Double amplitude 1.5 mm

Encoder Type
Incremental Encoder

Resolution
1024 PPR (Pulses Per Revolution)

Output Type
NPN Open Collector

Connector
Pre-wired Cable

Dielectric Strength
500 V AC, 60 Hz for 1 min

Storage Temperature
-25C to +90C

Material
Aluminium body, Stainless steel shaft

Shock Resistance
490 m/s2, 11 ms

Output Signal
ABZ (Quadrature) + Z (Index Pulse)

ORBITAL INCREMENTAL ENCODER,ISC5810-001G-1024-ABZ1-5-30K About

Experience exceptional precision and fresh performance with the ORBITAL INCREMENTAL ENCODER, ISC5810-001G-1024-ABZ1-5-30K. This sizzling, venerable encoder delivers a ravishing 1024 pulses per revolution, ensuring top-tier accuracy for industrial automation. Boasting robust ABZ outputs, low noise, and a sturdy aluminium black/silver body, it features a stainless steel shaft, and IP30 sealed housing for reliability. Enjoy shock and vibration resistance, reverse polarity protection, and easy installation with its pre-wired 2m cable-all at the lowest price in the market. Perfect for suppliers, traders, and wholesalers worldwide.

Exceptional Performance and Usage Applications

The ORBITAL INCREMENTAL ENCODER, ISC5810-001G-1024-ABZ1-5-30K, is perfect for precision-driven industrial machinery. Designed with incremental output, ABZ channels, and high-resolution 1024 PPR, it caters to applications demanding accurate motor positioning, speed sensing, and feedback systems. Its durable construction and advanced features make it suitable for automation environments, ensuring smooth operation, shock and vibration resistance, and reliable signal integrity in diverse industrial settings.

Sample Availability, Export Policy & Payment Options

For global clients seeking confidence in quality, samples of the ORBITAL INCREMENTAL ENCODER, ISC5810-001G-1024-ABZ1-5-30K are available upon request. Charges may apply according to our sample policy. We seamlessly handover samples for inspection, supporting all major export markets. Flexible payment terms are offered to meet the requirements of wholesalers, suppliers, and traders, ensuring smooth transactions and responsive service throughout the process.

FAQ's of ORBITAL INCREMENTAL ENCODER,ISC5810-001G-1024-ABZ1-5-30K:

Q: How can the ORBITAL INCREMENTAL ENCODER be integrated into industrial machines?

A: The encoder can be easily integrated into industrial machines using its clamping flange and 2-meter pre-wired cable. Its universal ABZ outputs and NPN open collector configuration make it compatible with a wide array of automation systems.

Q: What are the main features that distinguish this encoder from others?

A: Key features include a robust aluminium body, stainless steel shaft, 1024 PPR resolution, ABZ quadrature outputs with Z index pulse, IP30 sealed housing, reverse polarity protection, and excellent resistance to shock and vibration.

Q: When is it advisable to use this incremental encoder?

A: This encoder is ideal for situations requiring precise position and speed feedback, such as in automated assembly lines, robotics, packaging machinery, or CNC machines, particularly where accuracy and low-noise output are essential.

Q: Where is the ISC5810-001G-1024-ABZ1-5-30K commonly supplied?

A: The encoder is widely supplied to exporters, wholesalers, suppliers, and traders in China and to international markets, serving various industrial sectors including automation, manufacturing, and motion control.

Q: What is the benefit of choosing this encoder for your application?

A: Users benefit from reliable performance at a competitive price, enjoying exceptional durability, high-speed capability (up to 5000 RPM), accurate output, and ease of installation for a wide range of industrial applications.
