AUTONICS ROTARY ENCODER 12-24VDC, E40S6-3600-3-N-24

AUTONICS ROTARY ENCODER 12-24VDC, E40S6-3600-3-N-24 Specification

Ambient Temperature
-10°C to +70°C

Voltage
12-24V DC

Bearing Type
Ball Bearing

Current Type
DC

Standard
CE Certified

Features
Incremental encoder, compact size

Rated Voltage
12-24V DC

Product Type
Rotary Encoder

Color
Silver, Black

Dimension (L*W*H)
40mm diameter (housing)

Weight
Approx. 280g

Shaft Diameter
6mm

Mounting Type
Clamping / Servo Mount

IP Rating
IP50

Resolution
3600 PPR (Pulses Per Revolution)

Output Phase
A, B, Z (3-phase output)

Vibration Resistance
50m/s2 (10~200Hz)

Output Type
NPN Open Collector

Shaft Material
Stainless Steel

Model
E40S6-3600-3-N-24

Shaft Type
Solid Shaft

Application
Industrial Automation, Position Feedback

Shock Resistance
300m/s2 (2 times each in X, Y, Z)

Cable Type
Radial Cable (2m length)

Maximum Allowable Revolution
5000rpm

Cover Material
Aluminum

Maximum Response Frequency
100 kHz

Supply Voltage Range
12-24VDC 5%

AUTONICS ROTARY ENCODER 12-24VDC, E40S6-3600-3-N-24 About

Take advantage of this in-demand AUTONICS ROTARY ENCODER 12-24VDC, E40S6-3600-3-N-24, now available at the lowest price for industrial automation enthusiasts. This unassailable model boasts an opulent construction, featuring a solid stainless steel shaft, robust aluminum housing, and CE certificationideal for position feedback and precision applications. With a remarkable 3600 PPR resolution and NPN open collector output, it ensures high-speed, reliable performance. Its compact design, reinforced bearing type, and shock/vibration resistance make it a remarked choice for trade, wholesale, and distribution needs direct from China.

Exceptional Features & Industrial Applications

The AUTONICS E40S6-3600-3-N-24 rotary encoder stands out with incremental encoding, a robust radial cable, and 3-phase output. Its ball bearing system ensures durability while the compact design allows seamless integration into various setups. This encoder excels in applications such as industrial automation and position feedback. With a solid shaft, IP50 rating, and extended operating temperature range, its engineered for demanding industrial media, assuring elevated reliability under challenging conditions.

Logistics, Delivery, and Sample Ordering Information

Place your purchase order for the AUTONICS E40S6-3600-3-N-24, and benefit from express shipping via major logistics partners through the designated FOB port in China. Standard delivery times are prompt, minimizing production downtime. Sample policy accommodations are available for qualifying inquiries, enabling product verification before bulk commitments. The entire procurement and delivery process is tailored to provide efficient, secure, and timely supply for traders, suppliers, and wholesalers worldwide.

FAQs of AUTONICS ROTARY ENCODER 12-24VDC, E40S6-3600-3-N-24:

Q: How does the AUTONICS E40S6-3600-3-N-24 enhance industrial automation systems?

A: This rotary encoder delivers high-resolution position feedback, making it invaluable for precise motion control in automation systems. Its rugged design and reliability increase system accuracy and uptime.

Q: What benefits does the solid shaft and ball bearing construction provide?

A: The solid shaft and ball bearing design ensure unassailable durability, decreasing wear over time and providing smooth, stable operation even under harsh industrial conditions.

Q: When is express shipping available for this encoder?

A: Express shipping is available after your purchase order is confirmed, with efficient logistics ensuring quick delivery through Chinas primary FOB ports.
