OMRON SMART SENSOR, ZX1-LD100A81

OMRON SMART SENSOR, ZX1-LD100A81 Specification

Signal Type
Analog + Digital Output

Mounting Type
Surface/Panel Mount

Wireless
No

Sensitivity
High (Model-dependent, refer datasheet)

Features
High-speed and high-precision displacement/position measurement

Cable Length
2 meters (standard)

Response Time
0.5 ms (minimum, model dependent)

IP Rating
IP67

Spectral Range
Infrared (standard for ZX1-LD models)

Ingress Protection
IP67

Measurement Range
100 mm

Operating Temperature
0 to +50C

Application
Detection, Positioning, Distance Measurement

Sensor Type
Laser displacement sensor

Power Consumption
Max. 1.2 W

Housing Material
Plastic

Interface
Cable Connection

Product Type
Smart Sensor

Material
Plastic and Electronic Components

Input
DC 12-24V

Output
Analog and Digital (Model Specific)

Function
Displacement Measurement

Usage
Industrial Sensing/Automation

Accuracy
High accuracy (typically micron level, refer datasheet)

Resolution
0.008 mm

Voltage
12-24V DC

Weight
Approx. 110g (without cable)

Supply Current
70 mA max.

Shock Resistance
300 m/s2, 3 times in each of X, Y, Z directions

Linearity
0.25% F.S. (Full Scale)

Control Output
NPN/PNP (according to selection)

Storage Temperature
-15C to +60C

Repeatability
0.008 mm at 100 mm range

Light Source
Red Semiconductor Laser, Class 2

Ambient Humidity
35% to 85% RH

OMRON SMART SENSOR, ZX1-LD100A81 About

Explore the phenomenal OMRON SMART SENSOR, ZX1-LD100A81-your gateway to transcendent accuracy in industrial sensing solutions. As a new release, this first-rate laser displacement sensor offers unmatched precision with a repeatability of 0.008 mm at a 100 mm range, ensuring reliable results down to the micron level. Enjoy versatility with NPN/PNP control output selection and robust durability rated at IP67. Experience the lowest price for a sensor that redefines detection, positioning, and distance measurement-perfect for automation and demanding environments.

Optimal Uses and Application Guidance

The OMRON SMART SENSOR, ZX1-LD100A81 is used as a high-precision displacement sensor for automation and industrial environments. Apply it on smooth, rigid surfaces for best results in measurement and positioning. Mount the unit securely via surface or panel installation, and connect the standard 2-meter cable for power and data retrieval. Its robust IP67 housing and high accuracy make it ideal for demanding detection and distance control applications across various industries.

Export Markets, Certifications, and Delivery Information

Delivered worldwide, the OMRON SMART SENSOR, ZX1-LD100A81 is trusted in major export markets including Asia, Europe, and North America. Each unit is provided with reliable certifications to ensure compliance and quality standards. With prompt delivery times, traders and wholesalers will find the exchange seamless, and the asking price highly competitive. Buyers benefit from swift shipping, secure transactions, and comprehensive after-sales service.

FAQ's of OMRON SMART SENSOR, ZX1-LD100A81:

Q: How does the OMRON ZX1-LD100A81 sensor achieve high measurement accuracy?

A: The sensor utilizes a red semiconductor laser and advanced electronics to ensure high repeatability (0.008 mm at 100 mm range) and linearity, enabling precise displacement and position measurements in industrial settings.

Q: What applications is the OMRON ZX1-LD100A81 best suited for?

A: It excels in industrial sensing, automation for detection, position monitoring, and distance measurement, particularly where high accuracy and fast response times are crucial.

Q: When should I choose the OMRON ZX1-LD100A81 for my automation project?

A: Select this sensor when your project requires reliable, micron-level precision, robust IP67 protection, and compatibility with both analog and digital outputs for versatile integration.

Q: Where can this sensor be mounted and used?

A: The ZX1-LD100A81 supports surface and panel mounting, making it suitable for use in factories, automation lines, and industrial machinery across various ambient conditions.

Q: What is the process for connecting and operating this sensor?

A: Connect the sensor using the provided 2-meter cable, select your desired output type (NPN/PNP), supply DC 12-24V power, and calibrate according to your measurement requirements using its analog and digital outputs.

Q: What are the benefits of using the OMRON ZX1-LD100A81 over traditional sensors?

A: This sensor offers phenomenal speed (0.5 ms response), high precision, robust shock resistance, and ensures reliable results even in challenging environments-a step above conventional displacement sensors.
