OMRON SPATTER PROOF METAL FACE SENSOR 12MM , E2EW-QX3D112-M1TGJ

OMRON SPATTER PROOF METAL FACE SENSOR 12MM , E2EW-QX3D112-M1TGJ Specification

Ingress Protection
IP67

Power Consumption
15 mA (No Load)

Features
Spatter Proof, High Durability, Resistant to Welding Spatter

Sensitivity
Factory Set, Stable Operation in Spatter Environment

Spectral Range
Not Applicable (Inductive Sensor)

Signal Type
DC, 3-wire, PNP output

Wireless
No

Response Time
1 ms

Cable Length
2m Cable

Mounting Type
Flush/Embedded Mounting

Interface
Cable Connection

Application
Spatter Proof Applications, Automotive, Robotics, Manufacturing

Housing Material
Metal (Spatter Proof)

IP Rating
IP67

Measurement Range
3mm Sensing Distance

Sensor Type
Inductive Proximity

Operating Temperature
-40C to +85C

Mounting Thread
M12

Product Type
Inductive Proximity Sensor

Material
Stainless Steel (Sensor Face and Body)

Input
DC 3-wire

Output
PNP, NO (Normally Open)

Function
Object Detection (Proximity Sensing)

Usage
Industrial Automation / Welding Environments

Accuracy
High Detection Accuracy

Resolution
Standard for Inductive Proximity (No specific value provided)

Voltage
12-24V DC

Weight
Approximately 80g

Connector Type
Pre-wired Cable

Protection Circuit
Short-circuit and Reverse Polarity Protection

Shock Resistance
500 m/s2, 3 times each in X, Y, and Z directions

Vibration Resistance
10 to 55Hz, 1.5-mm double amplitude in X, Y, and Z directions for 2 hrs each

Model Number
E2EW-QX3D112-M1TGJ

Operating Voltage Range
10 to 30 VDC

Temperature Influence
+23C 2C (reference temperature)

Switching Frequency
Up to 1kHz

About OMRON SPATTER PROOF METAL FACE SENSOR 12MM , E2EW-QX3D112-M1TGJ

Experience the latest in sensor innovation with the OMRON Spatter Proof Metal Face Sensor (12mm), model E2EW-QX3D112-M1TGJ. This matchless proximity sensor delivers remarkable object detection accuracy, even in intense welding and industrial automation environments. Engineered with a customizable switching frequency up to 1kHz, its spatter-proof stainless-steel housing resists harsh conditions for unprecedented durability. Equipped with a pre-wired cable for easy installation and protected against short-circuits, reverse polarity, vibration, and shock, this sensor assures stable, high-performance operation. Take advantage of this exceptional deal for export, supply, or wholesale needs.

Versatile Industrial Applications

The OMRON Spatter Proof Metal Face Sensor 12MM, E2EW-QX3D112-M1TGJ, is widely used for object detection in welding environments, automotive assembly lines, robotics, and precision manufacturing. Its sturdy and spatter-resistant construction allows for reliable usage across demanding industrial automation tasks. With its flexible mounting options, this sensor adapts to a variety of custom applications, making it the ideal choice for both embedded and flush installations where resilience and high detection accuracy are crucial.

Payment & Logistics Details

Stock is ready for immediate dispatch, ensuring swift delivery upon order. Benefit from our competitive sale price and seamless logistics support. Payment terms are flexible to accommodate client needs, and samples are available for qualified inquiries. Shipments depart from our FOB port, providing efficient international and domestic delivery options. Partner with us as your trusted supplier, exporter, or wholesaler for OMRON's reliable E2EW-QX3D112-M1TGJ sensor solutions.

FAQ's of OMRON SPATTER PROOF METAL FACE SENSOR 12MM , E2EW-QX3D112-M1TGJ:

Q: How does the OMRON E2EW-QX3D112-M1TGJ sensor enhance industrial automation?

A: This sensor offers high detection accuracy in challenging environments, supporting stable object detection even with welding spatter or vibrations, significantly upgrading industrial automation reliability.

Q: What protection features does this proximity sensor provide?

A: It incorporates short-circuit and reverse polarity protection, along with robust shock and vibration resistance, ensuring safe and uninterrupted operation in demanding settings.

Q: Where can the spatter proof 12mm sensor be used most effectively?

A: It is ideal for applications in automotive manufacturing, robotics, welding environments, and other industrial settings prone to metal spatter, ensuring consistent performance.

Q: What are the usage benefits of the IP67-rated E2EW-QX3D112-M1TGJ sensor?

A: Its IP67 rating guarantees dust-tight and water-resistant operation. The spatter-proof design allows use in harsh environments without compromising functionality or sensor lifespan.

Q: When should I consider using a spatter proof metal face sensor over standard models?

A: Choose this sensor when operating in environments with high risk of metal spatter, mechanical shock, or frequent vibrations, to maintain dependable detection and reduce maintenance.
