OMRON SAFTEY RELAY UNIT,G9SB-3012-C

OMRON SAFTEY RELAY UNIT,G9SB-3012-C Specification

Dielectiric Strength
2,500 VAC, 50/60 Hz for 1 min (between coil and contacts)

Ambient Temperature
-25C to 55C (without condensation or icing)

Contact Form
3NO + 1NC

Protect Feature
Finger protection, Surge suppression

Coil Voltage
24V DC

Coil Power
Approx. 1.1 W

Contact Resistance
100 m max.

Power Consumption
Approx. 1.1 W

Working Temperature
-25C to 55C

Mechanical Life
10,000,000 operations min.

Contact Material
AgSnO2

Product Type
Safety Relay Unit

Insulation Resistance
100 M min. (at 500 VDC)

Theory
Electromagnetic Relay

Usage
Safety relay unit for machine safety circuits

Contact Load
6A at 250VAC, 6A at 30VDC (resistive load)

Operate Time
25 ms max.

Terminal Type
Screw terminal

Rated Voltage
24V DC

Supply Terminal
A1, A2

Size
Compact

Color
Yellow/Black

Dimension (L*W*H)
22.5 mm 102 mm 120 mm

Weight
~140 g

Storage Temperature
-40C to +85C

Standards Compliance
IEC 60947-5-1, EN 60204-1, EN ISO 13849-1 (PLe/Safety Category 4)

Enclosure Material
Polyamide (flame retardant)

Rated Frequency
50/60 Hz

Pollution Degree
2

Reset Method
Manual or automatic reset

Mounting Method
DIN rail mounting (EN 50022)

Model Number
G9SB-3012-C

Response Time
25 ms max.

About OMRON SAFTEY RELAY UNIT,G9SB-3012-C

Buy the OMRON SAFTEY RELAY UNIT, G9SB-3012-C and enjoy flawless machine safety in your control systems. With a compact, robust polyamide enclosure and impeccable compliance to industry standards (IEC 60947-5-1, EN 60204-1, EN ISO 13849-1), this famed safety relay unit ensures advanced finger protection, surge suppression, and reliable performance. Shop Now for this featured solution, offering a 10-million-operation mechanical life, 25 ms response time, and easy DIN rail mounting. Suitable for a variety of machine safety circuits, the G9SB-3012-C delivers impeccable safety with every use!

Advantages and Key Applications of the OMRON SAFTEY RELAY UNIT, G9SB-3012-C

The OMRON G9SB-3012-C safety relay unit offers significant advantages, including fast 25 ms response time and durable polyamide (flame retardant) construction, providing enhanced safety against mechanical and electrical risks. Its application method is straightforward: install on DIN rail (EN 50022) with manual or automatic reset functionality. Notable material features such as finger protection and surge suppression ensure that machine safety is never compromised. This relay is perfect for integration within industrial safety circuits, guaranteeing reliable performance in challenging environments.

Markets and Supply Ability for the OMRON SAFTEY RELAY UNIT, G9SB-3012-C

The OMRON SAFTEY RELAY UNIT, G9SB-3012-C is extensively shipped to main export markets, including Asia, Europe, and Americas, ensuring timely global delivery. The main domestic market is China, where rapid shipments and efficient delivery networks support large-scale distribution. Supply ability is streamlined, with products delivered promptly to meet industrial demands. Customers can expect consistent shipment schedules and reliable delivery worldwide, making this relay unit a preferred choice for both local and international buyers seeking impeccable supply reliability.

FAQ's of OMRON SAFTEY RELAY UNIT,G9SB-3012-C:

Q: How is the OMRON G9SB-3012-C safety relay unit installed in an industrial environment?

A: The OMRON G9SB-3012-C is designed for easy DIN rail mounting (EN 50022), allowing for quick and secure installation into standard control panels used in industrial automation and safety systems.

Q: What are the main applications of the G9SB-3012-C relay unit?

A: This safety relay unit is mainly used in machine safety circuits to ensure reliable isolation and protection, making it ideal for use in manufacturing, packaging, and factory automation settings.

Q: Where can the OMRON G9SB-3012-C be shipped or delivered?

A: OMRON's G9SB-3012-C can be shipped and delivered both domestically within China and internationally to key markets such as Asia, Europe, and the Americas through efficient supply networks.

Q: What are the key material features of the OMRON G9SB-3012-C relay?

A: The relay features a flame-retardant polyamide enclosure, finger protection, surge suppression, and robust screw terminals, making it highly durable and safe for demanding applications.

Q: How does the reset process work for this safety relay unit?

A: The G9SB-3012-C offers both manual and automatic reset methods, allowing users flexibility in operation and facilitating integration into various safety protocols.

Q: What benefit does the G9SB-3012-C provide in terms of operational life?

A: With a mechanical life of 10 million operations and high-quality AgSnO2 contacts, this relay ensures long-lasting, reliable performance while minimizing maintenance requirements.
