OMRON RELAY, G9SE-201

OMRON RELAY, G9SE-201 Specification

Contact Material
AgSnO2 alloy

Dielectiric Strength
2,500 VAC, 50/60 Hz for 1 min between all circuits

Working Temperature
-10C to +55C

Power Consumption
Approx. 2 W

Contact Form
2NO (Normally Open)

Contact Resistance
100 m max. (initial)

Mechanical Life
10,000,000 operations min.

Coil Voltage
24 V DC

Protect Feature
Finger-safe, EN standards compliant

Ambient Temperature
-10C to +55C

Coil Power
Approx. 2 W

Product Type
Safety Relay Unit

Insulation Resistance
100 M min. (at 500 VDC)

Theory
Electromagnetic Relay

Usage
Industrial Safety Applications

Contact Load
6A at 250VAC / 24VDC (resistive load)

Operate Time
20 ms max.

Terminal Type
Screw terminal

Rated Voltage
24 V DC

Supply Terminal
Screw terminal block

Size
Compact (45 x 87 x 90 mm)

Color
Yellow / Grey

Dimension (L*W*H)
87 mm x 45 mm x 90 mm

Weight
Approx. 180g

Output Type
Relay output

Response Time
25 ms max. (OFF to ON), 25 ms max. (ON to OFF)

Vibration Resistance
10 to 55 Hz, 0.35 mm amplitude

Standards
CE, cULus, TUV, EN 60947-5-1/IEC 60947-5-1

Relative Humidity
35% to 85% (no condensation)

Rated Control Input Voltage
24 V DC (20.4 to 26.4 V)

Safety Category
Category 4, PLe (EN ISO 13849-1/IEC 61508)

IP Rating
IP20

Case Material
Flame-resistant resin

Applications
Emergency stop and safety door monitoring

Mounting Type
DIN Rail Mounting

Shock Resistance
300 m/s²

Permissible Wire Size
0.2 to 2.5 mm² (24 to 14 AWG)

Model Number
G9SE-201

Number of Output Contacts
2NO

Indicator
LED (for Power, Input, AND Feedback)

About OMRON RELAY, G9SE-201

Order Today the splendiferous OMRON RELAY, G9SE-201-a pivotal choice for industrial safety. This blue-ribbon device delivers unparalleled protection, conforming to top international standards: CE, cULus, TUV, and EN 60947-5-1/IEC 60947-5-1. Its Category 4, PLe safety level and robust flame-resistant resin construction ensure reliability. Select this must-have relay for emergency stop and safety door monitoring, featuring a compact design, rapid response, LED indicators, screw terminals, and finger-safe protection for superior safety control. Engineered for excellence, it's the prime solution for your automation needs.

Exceptional Performance in Industrial Safety Applications

The OMRON RELAY, G9SE-201 is expertly designed for emergency stop and safety door monitoring across various industrial environments. Its application media includes both general and specific use, ensuring adaptable implementation. With EN standards compliance and mechanical life of over 10 million operations, it offers primary competitive advantages in reliability and durability, making it an essential choice for demanding safety processes in manufacturing, automation, and process control.

Efficient Transport and Sampling Policies

FOB Port arrangements for the OMRON RELAY, G9SE-201 facilitate streamlined shipping from China. Customers may estimate delivery timelines based on order completion and chosen transport services. Sample policy is straightforward-sample availability ensures clients can assess product quality prior to large orders. With transparent logistics processes and easy access to samples, businesses benefit from efficient planning and confident purchasing.

FAQ's of OMRON RELAY, G9SE-201:

Q: How does the OMRON RELAY, G9SE-201 enhance industrial safety?

A: The G9SE-201 relay delivers category 4, PLe safety, providing reliable operation for emergency stop and safety door monitoring. Its compliance with key international standards and robust construction help protect personnel and equipment.

Q: What are the primary applications for this relay?

A: This relay is primarily used for emergency stop circuits and safety door monitoring within manufacturing and automation sectors, ensuring crucial safety functions are always maintained.

Q: Where can the OMRON RELAY, G9SE-201 be installed?

A: Thanks to its compact size and DIN rail mounting type, the G9SE-201 can be conveniently installed in control panels and various industrial machinery setups.

Q: What is the process for obtaining a sample of this relay?

A: Clients can request a sample through the supplier's sample policy. Upon approval, a sample will be provided, allowing users to evaluate the relay's performance before completing a full order.

Q: When can customers expect delivery of their relay orders?

A: Delivery timelines depend on the FOB port and selected transport services. Customers may estimate arrival dates at the time of order completion and confirmation from the supplier.

Q: What are the standout benefits of selecting the G9SE-201 relay?

A: Its foremost benefits include advanced safety compliance, rapid response time, finger-safe design, LED status indicators, and exceptional mechanical durability-making it a must-have for high-demand industrial environments.
