OMRON , ROTARY ENCODER, E6C2-CWZ6C 600P/R

OMRON , ROTARY ENCODER, E6C2-CWZ6C 600P/R Specification

Voltage
5-24VDC

Bearing Type
Ball Bearing

Rated Voltage
5-24VDC

Features
600P/R Incremental encoder

Ambient Temperature
10C to 70C

Current Type
DC

Sealed Type
Sealed (IP64)

Product Type
Rotary Encoder

Protect Feature
IP64

Color
Black/Metallic

Dimension (L*W*H)
Approx. 50mm diameter x 48.5mm length

Weight
Approx. 200g

Shaft Diameter
8mm

Mounting Type
Flange Mount

IP Rating
IP64

Resolution
600 Pulses Per Revolution (P/R)

Model
E6C2-CWZ6C

Housing Material
Aluminum

Maximum Response Frequency
100 kHz

Rotation Direction
Clockwise/Counterclockwise compatible

Shaft Length
13mm

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude

RoHS Compliant
Yes

Cable Type
Pre-wired (standard cable 2m)

Output Phase
A, B, Z Phase

Connection Type
Cable Lead

Supply Voltage
5 to 24VDC 5%

Additional Product Specifications

Shock Resistance
1,000 m/s2, 3 times each in X, Y, Z directions

Storage Temperature
-25C to 85C

Output Type
NPN Open Collector Output

Output Capacity
40mA max per output

Shaft Type
Solid Shaft

Operating Humidity
35% to 85% RH (no condensation)

About OMRON , ROTARY ENCODER, E6C2-CWZ6C 600P/R

Experience the remarkable precision of the OMRON ROTARY ENCODER E6C2-CWZ6C 600P/R, crafted with a lofty standard in mind. This marvelously engineered device features an NPN open collector output with 600 pulses per revolution, supporting A, B, Z phases and a solid 13mm shaft in an aluminum body. Order now to benefit from IP64-sealed protection, reliable ball bearing rotary motion, and RoHS compliance. With impressive vibration and shock resistance, grab yours today to ensure accurate and consistent performance for industrial applicationspurchase with confidence from leading suppliers in China.

Versatile Application, Advanced Features

The OMRON ROTARY ENCODER E6C2-CWZ6C 600P/R is ideal for industrial automation, robotics, and motion control systems. Commonly used as a position or speed sensor, it offers extra features such as clockwise/counterclockwise compatibility, incremental encoding, and robust IP64 protection. With ease of integration and pre-wired cable, this encoder is perfectly suited for complex machinery in manufacturing, assembly, and quality assurance environments.

Swift Delivery and Export Solutions

Goods transport for the E6C2-CWZ6C rotary encoder is efficiently managed to main export markets including Asia, Europe, and beyond. Shipped goods promptly reach your location with reliable logistics ensuring timely arrival. Sample policies are designed to offer clarity and confidence, allowing new buyers to assess product performance before full purchase commitments. Trust our seamless process for fast delivery and exemplary customer service.

FAQs of OMRON , ROTARY ENCODER, E6C2-CWZ6C 600P/R:

Q: How can the OMRON E6C2-CWZ6C rotary encoder be used in automation systems?

A: The OMRON E6C2-CWZ6C rotary encoder is used to provide precise feedback on position, speed, and direction in automation systems, making it ideal for robotics, conveyor belts, and machinery requiring accurate motion control.

Q: What are the benefits of choosing an IP64-rated encoder like this model?

A: An IP64 rating ensures robust protection against dust and water splashes, prolonging the encoders life and stability in demanding industrial environments.

Q: When will my shipped goods typically arrive after placing an order?

A: Delivery times vary by location and export market, but prompt shipping arrangements ensure your goods are transported efficiently, usually arriving within the designated timeframe communicated upon order confirmation.

Q: Where is the OMRON E6C2-CWZ6C encoder commonly supplied from?

A: This rotary encoder is primarily distributed by suppliers, traders, and wholesalers in China, catering to global export markets.

Q: What is the process for obtaining a product sample?

A: You can request a sample according to the suppliers sample policy, which may include conditions like nominal charges or return requirements. The process is designed to let you review the encoders features before making a full purchase.

Q: How does the NPN open collector output benefit my system integration?

A: NPN open collector outputs ensure compatibility with industrial control devices and simplify signal interfacing, allowing seamless integration into various automation setups.
