OMRON ROTARY ENCODER 5VDC,E6B2-CWZ1X 1000P/R

OMRON ROTARY ENCODER 5VDC,E6B2-CWZ1X 1000P/R Specification

Features
Compact size, high resolution, robust design, wide operating temperature, reverse connection and short circuit protection

Bearing Type
Ball bearing

Voltage
5 VDC

Current Type
DC

Standard
RoHS Compliant

Rated Voltage
5 VDC

Efficacy
High efficiency

Ambient Temperature
-10°C to +70°C (no freezing)

Product Type
Rotary Encoder

Protect Feature
Reverse connection protection, output short-circuit protection

Color
Black & Silver

Dimension (L*W*H)
Approx. 38 mm (diameter) × 56.5 mm (length) (including shaft)

Weight
Approx. 200 g

Shaft Diameter
6 mm

Mounting Type
Clamp mounting

Output Type
Line driver output

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude

Allowable Rotation Speed
6000 rpm max.

Input Voltage Range
4.75 VDC to 5.25 VDC

Maximum Response Frequency
100 kHz

Application
Industrial automation, robotics, position and speed detection

Cable Length
2 meters (standard)

Connection Type
Pre-wired cable

Operating Humidity
35% to 85% RH (no condensation)

Output Phases
A, B, Z (three output phases)

Model
E6B2-CWZ1X 1000P/R

Material
Shaft: Stainless steel, Housing: Aluminium alloy

Dielectric Strength
500 VAC 50/60 Hz for 1 minute

Resolution
1000 pulses per revolution (P/R)

Insulation Resistance
100 M min. (at 500 VDC)

Shaft Loading
Radial: 5 N, Axial: 3 N

Starting Torque
5 mNm max. at room temperature

Shock Resistance
1,000 m/s2 (approx. 100G), 3 times each in 6 directions

OMRON ROTARY ENCODER 5VDC,E6B2-CWZ1X 1000P/R About

Unlock unbeatable precision and performance with the OMRON ROTARY ENCODER 5VDC, E6B2-CWZ1X 1000P/R. This premier rotary encoder offers top-notch reliability and high efficiency, with a robust design tailored for industrial automation, robotics, and motion control. Featuring a customizable configuration with 1000 pulses per revolution, line driver output, and protective features, it adapts seamlessly to diverse applications. Order today to secure a great deal on this compact, RoHS-compliant solution, engineered for durability and unbeatable accuracy in every movement.

Versatile Application Across Industries

The OMRON ROTARY ENCODER 5VDC, E6B2-CWZ1X 1000P/R excels in various areas such as industrial automation, robotics, position, and speed detection. Its high-resolution and robust design make it ideal for specific uses like assembly lines and conveyor systems, as well as general use in machinery requiring precise feedback and motion control. Enjoy reliable performance across manufacturing, packaging, and process automation with this dependable encoder.

Packaging and Market Reach Details

Each OMRON rotary encoder is packed securely for safe drop-off and delivery, ensuring the product reaches you in pristine condition. Whether you are a domestic buyer or an international client, you receive the lowest price estimates and efficient shipping. Our encoders see widespread demand in the main domestic markets and are also exported globally, making them a trusted choice for traders, suppliers, and wholesalers across continents.

FAQs of OMRON ROTARY ENCODER 5VDC,E6B2-CWZ1X 1000P/R:

Q: How can the OMRON E6B2-CWZ1X rotary encoder be integrated into existing automation systems?

A: The OMRON E6B2-CWZ1X encoder utilizes a pre-wired cable and clamp mounting for straightforward installation, allowing seamless integration into most industrial automation and robotics systems that require pulse or position feedback.

Q: What specific protection features does this rotary encoder offer?

A: This encoder includes reverse connection and output short-circuit protection, ensuring its durability and reliable operation even in demanding industrial environments.

Q: Where is the OMRON E6B2-CWZ1X encoder most effectively used?

A: It is best suited for applications such as position and speed detection in automated machinery, robotics, conveyors, and general systems requiring accurate motion feedback.

Q: What is the process to order this product for custom specifications?

A: You can place your order today by contacting our sales team with your requirements, ensuring you receive customizable options, the best deals, and timely delivery.

Q: How does the OMRON rotary encoder benefit automation setups?

A: With its high resolution, wide operating temperature range, and robust shock and vibration resistance, the encoder delivers stable, top-notch performance and enhances system reliability and accuracy.
