AUTONICS ROTARY ENCODER 12-24VDC, EP50S8-1024-2F-P-24

AUTONICS ROTARY ENCODER 12-24VDC, EP50S8-1024-2F-P-24 Specification

Current Type
DC

Standard
CE Certified

Features
Incremental encoder, Compact size, Durable construction

Ambient Temperature
-10C to +70C

Bearing Type
Ball Bearing

Voltage
12-24 VDC

Rated Voltage
12-24 VDC

Product Type
Rotary Encoder

Protect Feature
Reverse polarity protection

Color
Silver/Black

Dimension (L*W*H)
50 mm diameter (approx.)

Weight
Approx. 200 g

Shaft Diameter
8 mm

Mounting Type
Shaft Mount

Insulation Resistance
Over 100M (at 500VDC)

Shock Resistance
300 m/s (X, Y, Z for 3 times)

Vibration Resistance
50m/s (10Hz~55Hz, 1 min.)

Cable Type
5-core, 2m length cable

Shaft Type
Solid Shaft

Encoder Type
Incremental Rotary Encoder

Dielectric Strength
AC 500V 60Hz/1min

Maximum Response Frequency
100 kHz

Resolution
1024 PPR (Pulses Per Revolution)

Output Type
PNP Open Collector

Model Number
EP50S8-1024-2F-P-24

Housing Material
Aluminum Die-cast

Rotation Direction
Bi-directional

Output Phase
A, B, Z Phase (Quadrature Output)

Supply Current
Max. 80 mA

Allowable Shaft Load
Radial 30N, Axial 20N

About AUTONICS ROTARY ENCODER 12-24VDC, EP50S8-1024-2F-P-24

Redeem the inestimable value of the AUTONICS ROTARY ENCODER 12-24VDC, EP50S8-1024-2F-P-24-a gilt-edged solution for accurate motion feedback in industrial automation. With ultimate precision boasting 1024 PPR, this incremental rotary encoder offers bi-directional shaft rotation, durable aluminum die-cast housing, and robust shock and vibration resistance. Access reliable quadrature output (A, B, Z phase) via a 5-core, 2m cable, and benefit from advanced clearance and reverse polarity protection. Enjoy peace of mind with CE certification, ensuring gilt-edged performance in demanding settings.

Versatile Applications and Users

The AUTONICS EP50S8-1024-2F-P-24 rotary encoder is suitable for use in automated machinery, robotics, assembly lines, and factory automation systems. Used by engineers, system integrators, and maintenance professionals, it serves as an essential component for precise positioning, speed control, and monitoring applications in industrial environments. This compact encoder is utilized as a reliable sensor for detecting rotational movement and delivering accurate pulse outputs required for feedback systems.

Certifications, Payment Terms, and Sampling Policy

CE certified for global acceptance, this rotary encoder upholds industrial standards. Packing & Dispatch processes ensure safe delivery and product integrity. We accept major payment terms, providing flexibility for diverse market needs. Samples can be provided upon request, though a nominal charge may apply based on order value and requirements. Our sample policy is designed to balance both market value and customer satisfaction, supporting informed purchasing decisions.

FAQ's of AUTONICS ROTARY ENCODER 12-24VDC, EP50S8-1024-2F-P-24:

Q: How is the AUTONICS EP50S8-1024-2F-P-24 rotary encoder typically used in automation systems?

A: The encoder is typically integrated into automation machinery to deliver precise feedback on position, speed, and direction, supporting closed-loop control in industrial applications.

Q: What process should I follow to redeem a sample for evaluation?

A: To request a sample, contact our sales team. A nominal charge may be applicable based on market value, and we provide prompt Packing & Dispatch upon sample confirmation.

Q: What are the primary benefits of using this encoder in machinery?

A: Key benefits include its high-resolution feedback (1024 PPR), robust construction, resistance to shock and vibration, and reliable PNP open collector output for seamless integration.

Q: When is this encoder most suitable for deployment?

A: This encoder is most suitable for environments requiring precise movement detection and feedback, such as manufacturing, robotics, and conveyor systems.
