OMRON RELAY, MY2N-GS

OMRON RELAY, MY2N-GS Specification

Contact Material
Silver Alloy

Power Consumption
Approx. 0.9W (DC), 1.3VA (AC)

Coil Power
DC: 0.9W, AC: 1.3VA

Protect Feature
Finger Protection

Contact Form
DPDT (2 Form C)

Working Temperature
-55C to +60C

Contact Resistance
50 m Max.

Dielectiric Strength
2,000VAC (Between coil & contacts, 1 min.)

Mechanical Life
10,000,000 operations min

Coil Voltage
24VDC 220/240VAC

Ambient Temperature
-55C to +60C

Product Type
Relay

Insulation Resistance
100 M Min. (at 500VDC)

Theory
Electromagnetic Relay

Usage
General Purpose Relay

Contact Load
5A 250VAC / 5A 30VDC

Operate Time
20ms Max

Terminal Type
Plug-in

Rated Voltage
24VDC 220/240VAC

Size
21.5 mm (W) x 27.5 mm (D) x 35.5 mm (H)

Color
Transparent with Blue Cap

Dimension (L*W*H)
21.5 x 27.5 x 35.5 mm

Weight
Approx. 35 g

Mounting Type
Socket Mount

Switching Voltage
250 VAC / 30 VDC Max

Minimum Switch Load
10 mA @ 5VDC

Number of Pins
8

Vibration Resistance
10 to 55 Hz, 1.0 mm double amplitude

Model Number
MY2N-GS

Shock Resistance
1,000 m/s2

Release Time
20 ms Max

Frequency
50/60 Hz (AC coil type)

About OMRON RELAY, MY2N-GS

Experience an extraordinary promotion with the OMRON RELAY, MY2N-GS now available through our special offer. This immaculate relay is designed for dazzling performance and reliability in general-purpose applications. Featuring 8 pins and a socket mount for easy installation, MY2N-GS handles up to 250 VAC/30 VDC, with a swift 20 ms operate and release time. Its transparent body accented by a blue cap reflects its superior construction. Enjoy finger protection, robust shock and vibration resistance, and outstanding mechanical life exceeding 10 million operations. Bring precision and sophistication to your control panels with this Japanese-engineered marvel.

Commercial Applications and User Instructions

The OMRON RELAY, MY2N-GS is widely used by engineers, technicians, and maintenance professionals in automation, industrial controls, and manufacturing sectors. To use, simply plug the relay into a compatible socket and ensure the correct coil voltage is applied before connecting to your circuit. This versatile relay supports extensive commercial uses, from automation panels to instrumentation, offering reliable switching for diverse control needs while maintaining immaculate operational integrity.

Transportation, Delivery and Certifications Offered

Our OMRON RELAY, MY2N-GS is shipped through secure transportation channels from Japans principal FOB port, ensuring prompt and protected delivery. Benefit from reduced lead times, with most deliveries completed within 510 days. All units are supplied with international safety certifications, offering peace of mind and market value assurance. Take advantage of this offer and elevate your projects with certified, authentic OMRON products seamlessly delivered to your location.

FAQs of OMRON RELAY, MY2N-GS:

Q: How do I install the OMRON MY2N-GS relay?

A: The OMRON MY2N-GS relay features a socket-mount and plug-in terminal design for easy installation. Simply align the relay with a compatible 8-pin socket, press gently to ensure proper seating, and connect your input and output wires as per your circuit requirements.

Q: What are the primary commercial uses of the OMRON MY2N-GS relay?

A: The MY2N-GS relay is commonly used in industrial automation, control panels, instrumentation, and manufacturing applications. It is ideal for situations requiring reliable switching and high endurance in demanding environments.

Q: Where does OMRON MY2N-GS relay shipment originate and how long is the delivery time?

A: The relay is supplied directly from Japan, typically via a principal FOB port. Standard delivery time is 510 days, depending on your location and chosen transportation method.

Q: What benefits does the transparent blue cap design provide?

A: The transparent body with a blue cap allows for easy visual inspection of relay contacts, ensuring quick assessment of operational status and facilitating maintenance in complex setups.

Q: When should I use the MY2N-GS relay over other types?

A: Choose the MY2N-GS relay when you need a dependable, general-purpose DPDT (Double Pole Double Throw) solution that offers high mechanical life, finger protection, and excellent resistance to vibration and shock.
