OMRON PROGRAMMABLE RELAY, ZEN-10C1DR-D-V2

OMRON PROGRAMMABLE RELAY, ZEN-10C1DR-D-V2 Specification

Coil Power
Approx. 4.5W

Working Temperature
-10C to +55C

Contact Form
SPDT

Ambient Temperature
-10C to +55C

Contact Material
Silver alloy

Mechanical Life
20,000,000 operations min.

Dielectiric Strength
2,000 VAC, 50/60 Hz for 1 min

Protect Feature
Overvoltage, Short-circuit protection

Power Consumption
Approx. 4.5W

Contact Resistance
50 m max.

Coil Voltage
24V DC

Product Type
Programmable Relay

Insulation Resistance
100 M min. (at 500 VDC)

Theory
Programmable Logic Relay

Usage
Industrial Automation, Control Panels

Contact Load
8A @ 250V AC/30V DC (Resistive Load)

Operate Time
10 ms max.

Terminal Type
Screw terminal

Rated Voltage
24V DC

Supply Terminal
Screw terminal block

Size
Compact

Color
Grey

Dimension (L*W*H)
90 70 56 mm

Weight
Approx. 150g

Standards Compliance
CE, cULus, EN 61010-1

Expansion Units
Supports I/O expansion units

Memory Backup
EEPROM (retains user program during power loss)

Vibration Resistance
10 to 55 Hz, 0.5 mm double amplitude

Shock Resistance
300 m/s2, 3 times each in 6 directions

Input Points
6 inputs (4 digital/2 analog)

Output Points
4 relay outputs

Ingress Protection
IP20 (main unit)

Programming Method
Front panel keys or PC software

Storage Temperature
-20C to +75C

Display
LCD with backlight

Mounting Type
DIN-rail or screw mounting

OMRON PROGRAMMABLE RELAY, ZEN-10C1DR-D-V2 About

Get It Now-the OMRON PROGRAMMABLE RELAY, ZEN-10C1DR-D-V2, your elite solution for cost-effective industrial automation. This top-tier programmable logic relay offers 6 versatile input points (4 digital/2 analog) and 4 classic relay outputs, further enhanced by a crisp LCD backlit display. Its inestimable reliability is ensured by EEPROM memory backup, overvoltage, and short-circuit protection. Easily installed via DIN-rail or screw mounting, this compact grey powerhouse supports seamless programming through front panel keys or PC software. Compliant with CE and cULus standards, its robust design assures longevity and safety for any control panel setup.

Competitive Edge and Typical Applications

OMRON's ZEN-10C1DR-D-V2 stands out for its robust protections and flexible expansion capability. It's ideal for classic control panels and sophisticated industrial automation systems. Designed with a user-friendly interface, it suits on-site adjustments and remote PC programming. Incorporate this relay for efficient, reliable machinery or process control in manufacturing, HVAC systems, or utility management, supporting both new installations and system upgrades.

Supply Capacity and Export Markets

Our supply ability ensures bulk delivery at an attractive asking price to meet diverse client needs. Rates are competitive for global markets, with efficient transportation solutions available. Samples can be arranged for assessment. The main export markets include Asia, the Middle East, Europe, and Africa. Partner with us to secure swift availability and quality for your automation projects, with service tailored to traders, suppliers, and wholesalers.

FAQ's of OMRON PROGRAMMABLE RELAY, ZEN-10C1DR-D-V2:

Q: How do I program the OMRON ZEN-10C1DR-D-V2 relay?

A: Programming can be done directly using the front panel keys or through dedicated PC software, providing flexibility for both on-site adjustments and remote configuration.

Q: What competitive advantages does this relay offer for industrial automation?

A: It combines dual programming options, memory backup to retain user settings during power loss, robust protection features, and expansion capability, all within a compact top-tier design.

Q: When should I use an expansion unit with this relay?

A: Expansion units are recommended when your application requires more input or output points than the basic unit provides, ensuring scalability for complex automation projects.

Q: Where is this programmable relay commonly used?

A: This relay finds application in control panels for manufacturing machinery, HVAC systems, utility management, and various other industrial automation solutions.

Q: What is the process for ordering and transportation?

A: To order, contact us for the current asking price and rate. We offer sample availability and arrange for reliable transportation across our main export markets, ensuring prompt delivery.
