OMRON, PHOTOELECTRIC SENSOR, E3FA-DP13

OMRON, PHOTOELECTRIC SENSOR, E3FA-DP13 Specification

Sensor Type
Photoelectric

Interface
Pre-wired cable

Cable Length
2 meters pre-wired cable

Application
Conveyor belt monitoring, packaging systems, automation equipment

Sensitivity
Adjustable (Potentiometer)

Measurement Range
100 mm max (Detects at 100mm)

Wireless
No

IP Rating
IP67

Power Consumption
Under 1.0W (30mA max at 24V DC)

Operating Temperature
-25 to +55°C

Signal Type
Digital (ON/OFF Output)

Features
Robust housing, Compact size, Short-circuit protection, Reverse polarity protection

Response Time
0.5 ms max

Mounting Type
Through-hole/Panel mount

Product Type
Photoelectric Sensor

Material
Plastic (Housing Material: PBT)

Input
12-24V DC

Output
PNP, Normally Open (NO)

Function
Diffuse Reflective Detection

Usage
Object Detection / Industrial Automation

Accuracy
High Repeatability

Resolution
Fine Spot

Voltage
12 to 24 VDC

Weight
About 60g (including cable)

Detection Method
Diffuse-reflective

Vibration Resistance
10 to 55 Hz, 1.5 mm double amplitude

Protective Functions
Reverse polarity protection, Output short-circuit protection

Shock Resistance
500 m/s2, 3 times each in X, Y, and Z directions

Connector Type
Pre-wired (2m cable, 3-wire)

Light Source
Red LED (660 nm)

Control Output Capacity
PNP open collector 100 mA max

Ambient Illumination
Ambient: 3,000 lux max, Incandescent/fluorescent

Set Distance
100 mm (White Paper 200x200 mm as standard object)

About OMRON, PHOTOELECTRIC SENSOR, E3FA-DP13

Discover impeccable precision and reliability with the OMRON PHOTOELECTRIC SENSOR, E3FA-DP13, an ephemeral best-seller designed to meet crowning industrial needs. Fitted with a splendiferous Red LED (660 nm) light source and equipped with high-repeatability diffuse-reflective detection, it promises fine-spot resolution at a set distance of 100 mm. Shop now to experience robust protection featuresfrom reverse polarity to output short-circuit safeguarding. Its compact, durable housing blends seamlessly into automation systems, delivering unmatched quality for conveyor belt monitoring, packaging systems, and beyond.

OMRON E3FA-DP13: Competitive Edge & Application

The OMRON PHOTOELECTRIC SENSOR, E3FA-DP13 shines with primary advantages like IP67-rated robust housing, adjustable sensitivity, and short-circuit protection. Ideally suited for object detection in conveyor belt monitoring and packaging systems, it excels in high-speed, high-accuracy industrial automation. Its compact build and fine spot resolution ensure seamless integration and top-tier performance for manufacturers and automation solution providers.

Order & Payment Terms for OMRON E3FA-DP13

Enjoy a transparent order process with fair list pricing for the OMRON E3FA-DP13. Samples may be available for qualifying buyers to evaluate product performance before full order completion. Main export markets include Asia, Europe, Africa, and the Middle East. Reliable logistics ensure timely delivery, supporting your project schedules, while flexible payment terms accommodate diverse procurement needs.

FAQs of OMRON, PHOTOELECTRIC SENSOR, E3FA-DP13:

Q: How does the OMRON E3FA-DP13 ensure accurate object detection?

A: The sensor uses a diffuse-reflective detection method with a fine spot Red LED, offering high repeatability and adjustable sensitivity to guarantee precise object detection at distances up to 100 mm.

Q: What are the key benefits of using this photoelectric sensor in automation systems?

A: Its IP67 robust housing, shock and vibration resistance, and compact design make it ideal for the harsh environments of packaging lines, conveyor belts, and automated machinery, ensuring consistent, stable operation.

Q: Where is the best application for the OMRON E3FA-DP13 sensor?

A: This photoelectric sensor is best used in object detection scenarios such as conveyor belt monitoring, packaging systems, and general industrial automation where high-speed, accurate feedback is required.

Q: What is the process for installing the E3FA-DP13 sensor?

A: Installation is straightforward: mount the sensor through-hole or on a panel, connect the pre-wired 2m cable to your system, adjust sensitivity with the potentiometer, and its ready for operation.

Q: When can I expect delivery after order completion?

A: Once your order is confirmed and payment terms are finalized, our logistics team ships promptly to your specified location, aiming to meet your project deadlines efficiently.
