OMRON PHOTOELECTRIC SENSOR , E3FA-RP21

OMRON PHOTOELECTRIC SENSOR , E3FA-RP21 Specification

Cable Length
2 m

Interface
Cable

Sensitivity
Adjustable

Sensor Type
Retro-reflective Photoelectric

Response Time
1 ms

Mounting Type
Panel/Bracket Mounting

Signal Type
Digital

Measurement Range
0.1 m to 4 m (with E39-R1 reflector)

IP Rating
IP67

Wireless
No

Features
Red LED, Compact Housing, High Immunity to Ambient Light

Application
Conveyor Control, Packaging, Material Handling, Position Detection

Operating Temperature
-25C to 55C

Power Consumption
Max. 25 mA

Product Type
Photoelectric Sensor

Material
Plastic Housing

Input
12-24V DC

Output
PNP

Function
Retro-reflective

Usage
Industrial Automation

Accuracy
High Precision Detection

Resolution
Standard

Voltage
12 to 24 VDC

Weight
Approx. 50 g (including cable)

Case Material
PBT (polybutylene terephthalate)

Light Source
Red LED (660 nm)

Maximum Load Current
100 mA max. (output)

Approvals / Certifications
CE, cULus

Sensing Object
Opaque materials

Shock Resistance
500 m/s2, 3 times each in X, Y, and Z directions

Connection Method
Pre-wired type (standard)

Lens Material
PMMA (polymethyl methacrylate)

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude

Storage Temperature
-40C to +70C

Indicator Display
LED Indicator (Operation/Output, Stability)

Ambient Humidity
35% to 85% RH (non-condensing)

Protection Circuit
Reverse polarity, Surge protection, Output short-circuit protection

Emitting Element
High-brightness Red LED

About OMRON PHOTOELECTRIC SENSOR , E3FA-RP21

Experience distinguished performance with the OMRON PHOTOELECTRIC SENSOR E3FA-RP21. Designed for optimum accuracy and valorous reliability, this sensor is ideal for industrial automation tasks such as conveyor control, packaging, and position detection. Its PNP open collector output supports up to 100 mA, while robust protection features and an IP67 rating ensure longevity. Crafted with a top-quality PBT case and PMMA lens, it is resistant to vibration and shock. Achieve high precision at the lowest price-order today from China's renowned supplier, trader, or wholesaler.

Optimum Functionality and Competitive Edge

The E3FA-RP21 delivers specific and general use for industrial environments, providing high-precision detection across conveyor, packaging, and material handling applications. Its adjustable sensitivity and retro-reflective detection offer a primary competitive advantage in automation, with high immunity to ambient light. Distinguished by robust construction and easy panel/bracket mounting, it enhances workflow efficiency and productivity-making it a valorous choice for modern industry leaders.

Export and Domestic Market Reach & Sample Policy

Delivered efficiently to both export and domestic markets, the E3FA-RP21's reach spans globally with main export destinations in Asia, Europe, and the Middle East. In the domestic mar, quick freight logistics guarantee prompt delivery. Suppliers provide flexible sample policies, enabling clients to assess the sensor's superior features before placing substantial orders. Whether shipped internationally or domestically, every unit meets stringent quality standards and is securely packaged for transit.

FAQ's of OMRON PHOTOELECTRIC SENSOR , E3FA-RP21:

Q: How does the OMRON E3FA-RP21 ensure high precision detection in automation tasks?

A: The E3FA-RP21 sensor utilizes a red LED light source, adjustable sensitivity, and a sensing range of 0.1 m to 4 m to deliver high precision detection. Its digital signal output and swift 1 ms response time enhance accuracy in applications like conveyor control and packaging.

Q: What competitive features distinguish the E3FA-RP21 from other photoelectric sensors?

A: This sensor stands out with reverse polarity and short circuit protection, IP67 waterproof rating, robust construction, compact design, and high immunity to ambient light. Its PBT case and PMMA lens contribute to superior durability in demanding industrial settings.

Q: Where can the E3FA-RP21 be used most effectively?

A: The E3FA-RP21 is ideal for industrial automation, especially in conveyor control, packaging, material handling, and position detection. Its mounting flexibility and rugged structure make it suitable for both new and retrofit installations.

Q: What is the process for ordering and receiving the sensor in export or domestic markets?

A: Customers can order the E3FA-RP21 from reputable suppliers, traders, or wholesalers in China. Upon order confirmation, the product is securely packaged and delivered via freight to domestic or international destinations. Sample units are available upon request as part of flexible purchasing policies.

Q: How does the sensor benefit operations in harsh environments?

A: With strong vibration and shock resistance, an IP67 rating, and high operation reliability within a wide temperature and humidity range, the sensor maintains both accuracy and longevity, even in demanding industrial conditions.
