OMRON PHOTOELECTRIC SENSOR,E3JK-TR11

OMRON PHOTOELECTRIC SENSOR,E3JK-TR11 Specification

Power Consumption
2.5 W max.

Application
Industrial automation, conveyor lines, packaging, material handling

Features
Red LED indicator, Long sensing distance, Enhanced durability

Cable Length
2 m

Operating Temperature
-25C to +55C

Sensitivity
Adjustable

Measurement Range
15 m (Transmitter to Receiver)

Mounting Type
Screw mounting

Sensor Type
Through-beam (Transmitter & Receiver)

Response Time
20 ms max.

Signal Type
ON/OFF

Wireless
No

Interface
Cable connection

IP Rating
IP65

Product Type
Photoelectric Sensor

Material
Plastic (Body), Polycarbonate (Lens)

Input
DC

Output
Relay (SPDT), 250V AC, 5A

Function
Photoelectric detection of objects

Usage
Object presence, position or counting detection

Accuracy
High precision detection

Voltage
12-24V DC

Weight
Approx. 110 g

Control Output
Relay output, SPDT (Normally Open/Normally Closed)

Response Frequency
25 Hz

Indicator
Operation indicator (Red), Stability indicator (Green)

Connection Method
Pre-wired cable (2m standard)

Operating Humidity
35% to 85% RH (no condensation)

Protection Circuit
Reverse polarity protection, Surge absorber

Adjuster
Sensitivity volume (potentiometer)

Light Source
Red LED (660 nm)

Ambient Light Immunity
Incandescent: 3,000 lx max., Sunlight: 10,000 lx max.

Case Color
Black

Lens Material
Polycarbonate Lens

OMRON PHOTOELECTRIC SENSOR,E3JK-TR11 About

Discover the OMRON PHOTOELECTRIC SENSOR, E3JK-TR11-a grand addition to industrial automation that offers matchless precision and acclaimed durability. Equipped with a Red LED (660 nm) light source, this sensor ensures high-accuracy detection for object presence, position, or counting applications. Its monumental 15-meter sensing distance and adjustable sensitivity suit demanding conveyor and material handling environments. Featuring reliable relay SPDT output, superior ambient light immunity, and a robust IP65-rated build, this bargain sensor guarantees long-lasting operation. Secure your order now from a trusted China-based supplier, trader, or wholesaler.

Versatile Applications and Competitive Advantages

The OMRON PHOTOELECTRIC SENSOR, E3JK-TR11 is widely used as an object detector in conveyor systems, packaging, and material handling sectors. It excels in both specific tasks like position detection and general object counting. Thanks to its high-precision sensing, adjustable sensitivity, protection circuits, and robust polycarbonate lens, it stands out as a primary choice. Competitive advantages include long sensing range, enhanced durability, and in-built surge absorption-making it ideal for demanding automated operations.

Swift Delivery, Secure Arrival, and Reliable Packaging

Experience timely arrival with streamlined transport services, ensuring order completion meets your schedule. The OMRON PHOTOELECTRIC SENSOR, E3JK-TR11 is available for prompt dispatch to major domestic markets. Each sensor is securely packaged to safeguard against transit shock and moisture, ensuring pristine condition upon delivery. Trust our organized logistics to deliver your order efficiently, with detailed tracking provided at every step until your sensor arrives at your facility.

FAQ's of OMRON PHOTOELECTRIC SENSOR,E3JK-TR11:

Q: How does the OMRON E3JK-TR11 photoelectric sensor detect objects?

A: The sensor uses a through-beam system with a red LED light source (660 nm). It detects objects when an object interrupts the light beam between the transmitter and receiver, causing a relay output change.

Q: What are the primary benefits of using the E3JK-TR11 sensor?

A: Its major benefits include high detection accuracy, long sensing distance (15 m), easy sensitivity adjustment, robust construction for industrial environments, and strong immunity to ambient light, ensuring reliable operation.

Q: Where is this photoelectric sensor typically used?

A: The E3JK-TR11 is commonly used in industrial automation applications such as conveyor lines, packaging machinery, and material handling, where precise presence, position, or counting detection is essential.

Q: When should the sensor's sensitivity be adjusted?

A: Sensitivity should be adjusted when dealing with varying object types, distances, or environmental conditions to ensure consistent and accurate detection performance.

Q: What is the process for ordering the E3JK-TR11 from your company?

A: Simply place your order through our official channels. We ensure efficient transport services, secure packaging, and timely delivery to major domestic markets. Tracking information is provided for smooth order completion.
