OMRON LIMIT SWITCH,V-166-1C5

OMRON LIMIT SWITCH,V-166-1C5 Specification

Automation Grade
Manual

Finish Type
Standard

Mechanical Life
10,000,000 operations min.

Rated Voltage
250V AC

Max. Current
16A

Protection Level
IP40

Response Time
Fast, Snap Action

Number of Module
Single

Circuit Type
SPDT (Single Pole Double Throw)

Temperature Range
-25C to +80C

Product Type
Limit Switch

Material
Plastic housing, Silver alloy contacts

Insulation Resistance
100 M min. (at 500 VDC)

Contact Resistance
15 m max. (initial)

Max. Voltage
250V AC

Operating Temperature
-25C to +80C (with no icing or condensation)

Stoke
16 mm

Size
28 x 10.3 x 16 mm (L x W x H)

Color
Black

Weight
About 7g

Mounting Type
Panel Mount

Current Rating
16A at 250V AC

No Of Poles
Single Pole

Actuator Type
Pin Plunger

Switching Frequency
120 operations/min (mechanical), 30 operations/min (electrical)

Operating Force
max. 0.49 N

Terminal Type
Solder Lug

Ambient Humidity
85% RH max.

Contact Form
SPDT

Dielectric Strength
1000V AC, 50/60Hz for 1 min between terminals of same polarity

Electrical Life
100,000 operations min.

OMRON LIMIT SWITCH,V-166-1C5 About

Discover the must-have OMRON LIMIT SWITCH, V-166-1C5-an embodiment of value and precision designed for demanding automation tasks. This dominant switch features a noble SPDT contact form, a robust plastic housing, and silver alloy contacts for terrific conductivity. With an electrical life of 100,000 operations minimum and a mechanical life of 10,000,000 operations, durability is never ephemeral. Its fast snap action and 16A current rating at 250V AC ensure superior performance for industrial control. Panel mounting and IP40 protection make installation swift and adaptable, solidifying this switch as a trusted choice for professionals.

Industry-Wide Adoption and Versatile Application

The OMRON LIMIT SWITCH, V-166-1C5, is extensively used by automation engineers and industrial machine operators. Its reliable operation makes it ideal for conveyor systems, control panels, and safety mechanisms. This value-driven switch adapts to surfaces such as industrial machinery frames, automated assembly lines, and robotics. Its compact build ensures seamless integration, enhancing performance across diverse applications. Whether for equipment modernisation or new installations, the V-166-1C5 remains a favored essential in manufacturing environments.

Supply Chain Efficiency and Sample Policies

We support your business with timely order processing and express shipping on the OMRON LIMIT SWITCH, V-166-1C5, ensuring safe goods transport and swift delivery. With a strong supply ability, large orders are consistently fulfilled for traders and wholesalers. Sample policies are flexible-samples are available to validate compatibility or quality before your bulk purchase. Our customer-centric approach extends from initial inquiry through to after-sales support, guaranteeing your satisfaction with every order.

FAQ's of OMRON LIMIT SWITCH,V-166-1C5:

Q: How is the OMRON V-166-1C5 limit switch mounted?

A: The OMRON V-166-1C5 limit switch is designed for panel mounting, allowing for secure installation on industrial equipment and control panels.

Q: What benefit does the SPDT contact form provide in this switch?

A: The Single Pole Double Throw (SPDT) contact form allows the switch to control two circuits, offering flexible wiring options and more versatile automation control.

Q: Where can the V-166-1C5 limit switch be used?

A: This limit switch is ideal for industrial settings such as automated assembly lines, conveyor systems, robotics, and other machinery requiring precise and reliable position detection.
