OMRON LIMIT SWITCH, AP-Z

OMRON LIMIT SWITCH, AP-Z Specification

Max. Current
5A

Automation Grade
Manual Operation

Mechanical Life
5,000,000 operations min.

Response Time
Less than 10ms

Temperature Range
-10C to +80C

Protection Level
IP65

Number of Module
Single

Rated Voltage
250V AC

Circuit Type
SPDT (Single Pole Double Throw)

Finish Type
Matte Finish

Product Type
Limit Switch

Material
Zinc Alloy Die-cast Housing

Insulation Resistance
100M min. (at 500VDC)

Contact Resistance
25m max. (initial)

Max. Voltage
250V AC/DC

Operating Temperature
-10C to +80C

Stoke
17.5mm (Plunger travel)

Size
Standard, Compact Body (Approx. 54mm x 30mm x 26mm)

Color
Grey

Weight
Approx. 100g

Mounting Type
Panel/Surface Mounting

Current Rating
5A 250VAC

No Of Poles
1 Pole

Terminal Type
Screw Terminal

Vibration Resistance
10 to 55 Hz, 1.5mm double amplitude

Shock Resistance
1000m/s2 (approx. 100G)

Actuator Type
Plunger

Contact Type
Snap Action

Operating Force
approx. 14.7N max.

Electrical Life
500,000 operations min.

Series
AP-Z

Standards Compliance
CE, CCC certified

About OMRON LIMIT SWITCH, AP-Z

Discover the highly recommended OMRON LIMIT SWITCH, AP-Z - now available fresh from clearance stocks! This astounding switch features a supreme snap action contact, robust plunger actuator, and secure screw terminal for perfect connectivity. Renowned for its 500,000+ operations electrical life and up to 5,000,000 mechanical operations, it promises reliability with a compact design and rugged zinc alloy housing. With CE and CCC certification, 100G shock resistance, and IP65 protection, the AP-Z is ideal for demanding industrial environments. Panel or surface mount installation is effortless. Grab this perfect automation solution at an unbeatable value!

Astounding Versatility & Machine Features

The OMRON LIMIT SWITCH, AP-Z is designed for supreme performance on various application surfaces, including machinery panels and industrial surfaces. It's highly suitable for use in demanding automation, factory equipment, and safety applications. The machine features a robust plunger actuator, 17.5mm stroke, SPDT circuit, and a secure zinc alloy die-cast housing. Its compact, matte finish body offers both aesthetic appeal and practical durability, making it a perfect fit for modern industrial environments.

Stock Ready: Supply Rates & Certifications

With market-leading supply capability, the OMRON LIMIT SWITCH, AP-Z is available in stock ready to ship for bulk and wholesale orders. Samples are available upon request, ensuring confidence in your rate of selection before bulk purchase. This product maintains high market value due to its CE and CCC certifications, guaranteeing compliance and quality standards recognized internationally. Secure your supply for optimal performance and assured standards in all your automation projects.

FAQ's of OMRON LIMIT SWITCH, AP-Z:

Q: How is the OMRON LIMIT SWITCH, AP-Z installed?

A: The AP-Z limit switch can be panel or surface mounted, allowing for flexible integration into various industrial setups. Its standard, compact body ensures that installation is straightforward, even in space-constrained environments.

Q: What benefits does the snap action contact type provide?

A: The snap action contact delivers quick and precise switching with a response time of less than 10ms, enhancing reliability and safety in automation circuits.

Q: Where is the OMRON LIMIT SWITCH, AP-Z most suitable for use?

A: It's ideally suited for use in industrial automation, factory equipment, and machinery where robust, reliable limit detection is required under demanding conditions.

Q: What certifications does this limit switch offer?

A: This model is fully CE and CCC certified, meeting strict international safety and quality standards for electrical and electronic equipment.

Q: How long is the operational life of this switch?

A: The OMRON AP-Z boasts a mechanical life of at least 5,000,000 operations and an electrical life exceeding 500,000 operations, ensuring long-term reliability.
