OMRON DIGITAL TEMPERATURE CONTROLLER, E5CC-RX2ASM-802

OMRON DIGITAL TEMPERATURE CONTROLLER, E5CC-RX2ASM-802 Specification

Type
Digital Temperature Controller

Theory
PID (Proportional-Integral-Derivative) Control

Capacity
N/A (Controller Device)

Exterior Material
Plastic, Flame-resistant

External Size
48 mm 48 mm 100 mm (H W D)

Heating System
Control by relay or SSR

Cooling System
Control by relay or SSR

Controller System
Microprocessor-based digital control

Temperature Range
-200 to 2,300 C (sensor-dependent)

Input Type
Thermocouple/RTD/Current/Voltage

Control Output
Relay (SPDT), 250 VAC, 3A

Weight
Approx. 150 g

Accuracy
0.2% of process value

Panel Cutout Size
45 45 mm

Ingress Protection
IP66 front panel

Supply Voltage
100 to 240 VAC, 50/60 Hz

Input Sampling Cycle
50 ms

Communication
RS-485 (Modbus/RTU)

Display
White PV/SV 4-digit 7-segment LED

Mounting Method
Panel mount

Model Number
E5CC-RX2ASM-802

Setting Method
Digital key operation

Environment
Operating temp: -10 to 55C, humidity: 25 to 85% RH (non-condensing)

Alarm Outputs
2 (optional)

About OMRON DIGITAL TEMPERATURE CONTROLLER, E5CC-RX2ASM-802

Experience the kingly performance and dazzling precision of the scarce OMRON DIGITAL TEMPERATURE CONTROLLER, E5CC-RX2ASM-802. This fresh, new model boasts an imposing 4-digit, white LED display, operating seamlessly on 100 to 240 VAC. Offering versatile input compatibility (thermocouple, RTD, current, voltage) and a relay control output, it ensures pinpoint accuracy (0.2%) with a swift 50 ms sampling cycle. The robust IP66-rated front panel and digital key operation deliver reliability and ease-of-use for critical industrial temperature management, making it an elite choice for modern, demanding environments.

Advanced Features & Application Versatility

The OMRON E5CC-RX2ASM-802 shines with extra features including dual optional alarm outputs, RS-485 Modbus communication, and a flame-resistant exterior. This imposing digital controller is suitable for industrial ovens, refrigeration, plastic molding, and baking processes where reliable, responsive temperature control matters. Its compact panel mount design (45 x 45 mm cutout), digital key operation, and microprocessor-based PID control ensure precise adjustment across a wide range, achieving optimal results in diverse surface applications efficiently.

Export Markets, Sample Availability & Packaging Details

The OMRON DIGITAL TEMPERATURE CONTROLLER, E5CC-RX2ASM-802 is designed for markets with high-quality control expenditure, suitable for global supply and distribution. Samples are available for potential buyers, facilitating assessment before bulk investment. Secure packaging safeguards the device during transport, protecting its dazzling display and imposing functionality. This ensures that from supply chain to operational settings, the controller arrives in pristine condition, ready for installation and reliable service in various international markets.

FAQ's of OMRON DIGITAL TEMPERATURE CONTROLLER, E5CC-RX2ASM-802:

Q: How does the OMRON E5CC-RX2ASM-802 controller maintain temperature accuracy?

A: The controller employs advanced microprocessor-based PID (Proportional-Integral-Derivative) control, with a high sampling rate of 50 ms, ensuring precise and stable temperature regulation for various applications.

Q: What surfaces or environments can the OMRON E5CC-RX2ASM-802 be used in?

A: This device is ideal for use in industrial settings such as ovens, refrigeration units, plastic molding, and food processing environments, where precise temperature control and robust ingress protection are required.

Q: When should I use the relay or SSR outputs of the controller?

A: Use the relay output for traditional switching and the SSR output for applications requiring rapid, noise-free, and long-lasting control, depending on your system's specific heating or cooling requirements.

Q: Where can I install the OMRON E5CC-RX2ASM-802?

A: This controller is designed for panel mount installation, fitting perfectly into a 45 x 45 mm panel cutout. Its compact and robust design ensures it is suitable for tight and demanding industrial control panels.

Q: What is the process for setting up and operating this temperature controller?

A: Configuration is achieved through digital key operation on the front panel. Users can easily set control parameters, alarm outputs, and adjust settings through the intuitive user interface for quick commissioning.

Q: How does the ingress protection rating benefit the controller's usage?

A: With an IP66-rated front panel, the controller is safeguarded against dust ingress and powerful water jets, making it highly reliable in harsh or moist environments.
