Autonics Temperature Controller, Tcn4l-24r

Autonics Temperature Controller, Tcn4l-24r Specification

Temperature Accuracy
0.5% of full scale

Protection Class
Not specified (typically IP20 for panel devices)

Standard
CE, RoHS (varies by batch); see datasheet

Operating Temperature
0 to 50C

Label
Autonics TCN4L-24R

Configuration
Panel Mount

Manipulation
Push Button/Keypad

Weight
Approx. 200g

Shell Material
Plastic

Dimension (L*W*H)
48mm x 96mm (Front Panel Size, Standard for TCN4L Series)

Alarm Limit
Assignable, AL1 OUT and AL2 OUT (250VAC 1A1a)

Type
Temperature Controller

Theory
PID/On-Off control

Capacity
Relay: 250VAC 3A1a; SSR: 12VDC2V, 20mA Max; AL1 OUT: 250VAC 1A1a; AL2 OUT: 250VAC 1A1a

Exterior Material
Plastic (ABS/Polycarbonate)

Controller System
Microprocessor-based, digital display

Temperature Range
Depends on sensor, standard for TCN4L: -199 to 1999C (with appropriate probe)

Power Supply
100-240VAC, 50/60Hz, 5VA

Output Type
Relay and SSR (Solid State Relay) Drive

Display
7-Segment LED, 4-digit

Mounting Method
Panel Mount

Compatible Sensors
Thermocouple (J, K, T, E, L, N, R, S, B), RTD (Pt100, JPt100)

Panel Cut Size
92mm x 45mm (approximate, standard for TCN4L)

Use Case/Application
Industrial and Laboratory Temperature Control

Sensor Input
Thermocouple (TC), RTD (PT100)

Control Mode
PID, Auto-tuning, Manual Setting

Response Time
Fast response <1s depending on sensor type

Model
TCN4L-24R

Autonics Temperature Controller, Tcn4l-24r About

The Autonics Temperature Controller, TCN4L-24R, commands attention with its monumental precision and celebrated functionality. Highly regarded by professionals for its top-tier performance, it boasts favorable reviews and is offered at the best price for exporters, suppliers, traders, and wholesalers. Designed for superior industrial and laboratory temperature control, this panel mount unit utilizes PID, auto-tuning, and manual modes for fast, accurate results. Its robust 7-segment LED display ensures clarity, while broad sensor compatibility guarantees versatile usage. Built with enduring ABS/polycarbonate, it's an essential choice for demanding environments.

Advantages and Wide Application Areas

The Autonics TCN4L-24R Temperature Controller offers commanding operation with reliable PID control and auto-tuning, ensuring precise thermal management. Favored across various industries, it excels in industrial automation, laboratory research, and process engineering. Its adaptability extends to equipment manufacturing, testing facilities, and quality assurance labs. Its celebrated design supports both relay and SSR output, making it suitable for other heating and cooling applications, such as furnaces, ovens, incubators, and environmental chambers, where accurate temperature control is vital.

Main Domestic Market and Sample Policy

Secure shipping is guaranteed when you purchase the Autonics TCN4L-24R, ensuring peace of mind for all domestic buyers. Shipments are dispatched swiftly, with delivery estimates provided to keep you informed of arrival times. If you wish to evaluate the controller before large-scale procurement, sample units are available upon request. The sample policy is customer-friendly, prioritizing accessibility and tailored to help clients assess suitability for their application before making a full investment.

FAQ's of Autonics Temperature Controller, Tcn4l-24r:

Q: How do I install the Autonics TCN4L-24R Temperature Controller?

A: The TCN4L-24R is designed for easy panel mounting. Ensure the cut size matches approximately 92mm x 45mm, then secure the controller using its mounting brackets. Connect appropriate sensors and power supply as detailed in the datasheet.

Q: What sensor types are compatible with this temperature controller?

A: This controller is compatible with thermocouple sensors (J, K, T, E, L, N, R, S, B) and RTD sensors (Pt100, JPt100), making it suitable for various industrial and laboratory applications.

Q: Where can the TCN4L-24R Temperature Controller be effectively used?

A: It finds application in industrial processes, laboratory environments, ovens, incubators, and environmental chambers-anywhere precise temperature control is essential for process stability or product quality.

Q: What is the process for obtaining a product sample for testing?

A: You can request a sample through authorized suppliers or distributors. Once your request is approved as per the sample policy, the unit will be shipped securely to your location for evaluation.

Q: What are the main benefits of using a microprocessor-based temperature controller?

A: Microprocessor-based controllers like the TCN4L-24R ensure improved accuracy (0.5% of full scale), fast response time (typically less than 1s), flexible control options, and ease of configuration using the intuitive keypad or push buttons.
