OMRON PROGRAMMBLE CONTROLLER, CP1H-XA40DR-A

OMRON PROGRAMMBLE CONTROLLER, CP1H-XA40DR-A Specification

Type
Programmable Logic Controller (PLC)

Theory
Sequential Control

Capacity
40 I/O Points

Exterior Material
ABS Resin

Interior Material
Polycarbonate/ABS Mix

Insulation Material
Insulating Resin

Internal Size
Standard Compact Size for CP1H Series

External Size
90mm (H) x 130mm (W) x 85mm (D)

Controller System
Microprocessor-based Control System

Humidity Range
10% to 90% (Non-condensing)

Temperature Range
0°C to 55°C (Operating)

Programming Language
Ladder Diagram and Structured Text

Display
LED Indication for Status and I/O

Power Supply Voltage
AC100 to 240V

Analogue Inputs
4 channels (Voltage/Current)

Maximum Input Voltage
26.4V DC

Output Points
16 (Relay, 250V AC/30V DC, 2A per point)

Expansion Units
Up to 7 Expansion Units

Input Points
24 (Digital, 24V DC)

Communication Ports
RS232C, USB, Option: Ethernet

Maximum Output Current
2A/point

Memory Capacity
20K steps program capacity, 10K words data memory

Protection Structure
IP20

Analogue Outputs
2 channels (Voltage)

Weight
Approx. 950g

Mounting Method
DIN Rail/Panel Mounted

Model
CP1H-XA40DR-A

About OMRON PROGRAMMBLE CONTROLLER, CP1H-XA40DR-A

Buy online the ineffable OMRON PROGRAMMBLE CONTROLLER, CP1H-XA40DR-A and elevate your automation to transcendent levels. Now with a price cut, seize this promotion for reliability and superior sequential control. With 24 digital input points (24V DC) and 16 relay output points (250V AC/30V DC), its design remains unassailable in performance. Enjoy 4 analogue inputs and 2 analogue outputs for flexible operation. Expand up to 7 units, program with Ladder Diagram or Structured Text, and utilize RS232C, USB, or Ethernet options. Perfect for suppliers, traders, and wholesalers seeking robust solutions.

Exceptional Usage & Features of CP1H-XA40DR-A

The OMRON PROGRAMMBLE CONTROLLER CP1H-XA40DR-A is designed for seamless microprocessor-based sequential control. Begin with easy DIN rail or panel mounting, set status using the LED indicators, and program via Ladder Diagram or Structured Text. It boasts IP20 protection, 40 I/O points, and up to 7 expansion units. Its advanced communication ports and compact size make it ideal for versatile industrial applications, ensuring both performance and adaptability.

Sample Policy, Delivery Timeline & Payment Structure

Our sample policy allows for proposal amount evaluation before confirming your outlay. Shipped goods are dispatched within a reliable timeframe, typically aligning with industry standards for swift delivery. Payment terms are flexible, ensuring suppliers and traders can manage their financial commitments efficiently. We prioritize transparency in each transaction, guaranteeing that every order-from the first inquiry to shipment-meets your business requirements promptly and professionally.

FAQ's of OMRON PROGRAMMBLE CONTROLLER, CP1H-XA40DR-A:

Q: How does the CP1H-XA40DR-A ensure unassailable operational reliability?

A: The controller utilizes robust microprocessor-based control, ensures stable input and output points, and features IP20 protection, delivering consistent and secure performance.

Q: What programming languages does the OMRON CP1H-XA40DR-A support for configuration?

A: This model supports both Ladder Diagram and Structured Text programming languages, offering flexibility for a wide range of automation tasks.

Q: Where can users mount the CP1H-XA40DR-A?

A: The controller is designed for easy installation on DIN rails or panel mounts, fitting seamlessly into various industrial setups.

Q: When will shipped goods typically arrive after placing an order online?

A: Goods are usually shipped promptly following order confirmation, with delivery times depending on the shipping method and destination provided with your proposal amount.

Q: How does the expansion unit feature benefit users?

A: Users can connect up to 7 expansion units, enabling scalable system growth and accommodating increasing automation requirements as their needs evolve.

Q: What forms of payment are accepted for this programmable controller?

A: We accept multiple payment forms to suit suppliers, traders, and wholesalers, facilitating efficient transactions for purchasing the CP1H-XA40DR-A online.
