HE SUGARCUBE RELAY,JQC3F-C-S-10-DC24V

HE SUGARCUBE RELAY,JQC3F-C-S-10-DC24V Specification

Coil Voltage
24V DC

Working Temperature
-40C to +85C

Mechanical Life
10,000,000 operations

Coil Power
0.36W

Protect Feature
Sealed

Contact Form
SPDT

Contact Resistance
100 m

Power Consumption
0.36W

Contact Material
Ag Alloy

Dielectiric Strength
1500VAC, 50/60Hz (between coil and contacts)

Ambient Temperature
-40C to +85C

Product Type
Electromagnetic Relay

Insulation Resistance
>100 M (500VDC)

Theory
Electromagnetic Relay

Usage
Electrical equipment, automation systems, PCB, industrial control

Contact Load
10A 250VAC / 10A 30VDC

Operate Time
10 ms

Terminal Type
PCB Mount

Rated Voltage
24V DC

Supply Terminal
2 Pin / 4 Pin

Color
Blue

Dimension (L*W*H)
19 mm x 15.5 mm x 15.3 mm

Weight
About 10 g

Coil Resistance
1600 10%

Dropout Voltage (Min)
2.4 VDC

Max Switching Voltage
250VAC / 30VDC

Pickup Voltage (Max)
18 VDC

Operating Position
Any position

Mounting Type
PCB Mounting

Max Switching Current
10A

Switching Mode
Single side stable

Storage Temperature
-40C to +125C

HE SUGARCUBE RELAY,JQC3F-C-S-10-DC24V About

Experience transcendent performance with the HE SUGARCUBE RELAY,JQC3F-C-S-10-DC24V, engineered for unassailable reliability in automation systems and industrial control. Enjoy instant savings and instant checkout from top-rated suppliers and wholesalers. This valiant electromagnetic relay features PCB mounting, single side stable switching, and robust contact load capabilities up to 10A at 250VAC/30VDC. With superior insulation resistance and a sealed protective design, it operates seamlessly across broad temperature ranges. Its compact sugar cube size ensures effortless integration, making it the quintessential relay choice for electrical equipment, PCB projects, and beyond.

Feature Highlights: Usage and Direction of Use

The HE SUGARCUBE RELAY,JQC3F-C-S-10-DC24V shines with its versatile application in electrical automation. Designed for seamless PCB mounting, it offers unassailable performance in industrial controls or electronic devices. Its special features include sealed protection, high insulation resistance, and a valiant 10 million mechanical life cycles. Simply mount in any position, connect terminals, and leverage its single side stable switching mode for transcendent operational reliability.

Shipment, Payment, and Domestic Supply

Upon arrival of your order, instant savings and simple transactions await. We accept competitive asking prices for the HE SUGARCUBE RELAY,JQC3F-C-S-10-DC24V, making the payment process efficient. Rapid shipment and reliable supply ability are hallmarks of our service. Delivery covers the main domestic market, ensuring top-rated products reach your facility swiftly, with transparent payment terms tailored to customer needs.

FAQ's of HE SUGARCUBE RELAY,JQC3F-C-S-10-DC24V:

Q: How is the HE SUGARCUBE RELAY,JQC3F-C-S-10-DC24V installed on a circuit board?

A: This relay features a PCB mounting style, allowing easy installation by positioning and soldering the terminals onto your circuit board.

Q: What special features make this relay suitable for automation systems?

A: Its sealed design, high insulation resistance, and wide temperature operating range contribute to unassailable performance in demanding automation environments.

Q: When can I expect my shipment after placing an order?

A: Shipments are processed promptly after payment confirmation, with typical arrival times varying depending on your domestic location and selected shipping method.
