OMRON RELAY , GR2-1

OMRON RELAY , GR2-1 Specification

Dielectiric Strength
1000 V AC for 1 minute Kilopascals (KPa)

Contact Resistance
Below 50 m Milliohm (m)

Ambient Temperature
Up to 55C Celsius (oC)

Protect Feature
Dustproof enclosure

Contact Material
Silver Alloy

Working Temperature
-40C to 55C Celsius (oC)

Coil Voltage
12 VDC Volt (V)

Coil Power
Approximately 1 W

Contact Form
SPDT (Single Pole Double Throw)

Product Type
Electromechanical Relay

Insulation Resistance
Minimum 100 M at 500VDC

Theory
Electromagnetic

Usage
General-purpose switching applications

Contact Load
Other

Terminal Type
Other

Rated Voltage
250VAC Volt (V)

Supply Terminal
Standard pin type terminals

Color
Transparent casing with copper coil

Dimension (L*W*H)
Approximately 28mm x 22mm x 16mm Millimeter (mm)

Weight
Approximately 20g Kilograms (kg)

Warranty
1 year manufacturer warranty

OMRON RELAY , GR2-1 About

The OMRON RELAY GR2-1 is a robust and reliable electromagnetic relay designed for general-purpose switching applications. Encased in a dustproof transparent housing with a visible copper coil, this relay ensures durability and performance under varying conditions. It features a Single Pole Double Throw (SPDT) contact form, crafted with silver alloy material for efficient conductivity and low contact resistance below 50 milliohms. Operating within a wide temperature range from -40C to 55C, the relay handles ambient temperatures up to 55C and boasts a rated voltage of 250VAC with a coil voltage of 12VDC. With standard pin-type terminals for easy installation, it has a minimum insulation resistance of 100 megohms at 500VDC and a dielectric strength of 1000VAC for up to 1 minute. Compact and lightweight, with dimensions of approximately 28mm x 22mm x 16mm and a weight of just 20g, it is suitable for tight spaces and portable applications. The relay features a coil power of approximately 1W, reinforcing its energy efficiency. Backed by a 1-year manufacturer warranty, this relay is the perfect choice for reliable switching operations across diverse industrial needs.
