DELTA PROXIMITY SENSOR, 18MM DIA, SD 12MM, NPN-NC, IS-N1812-BNCB2

DELTA PROXIMITY SENSOR, 18MM DIA, SD 12MM, NPN-NC, IS-N1812-BNCB2 Specification

Interface
3-wire DC

Sensor Type
Inductive Proximity

Power Consumption
15 mA max

Operating Temperature
-25C to +70C

Measurement Range
Sensing Distance 12 mm

Sensitivity
Stable, Factory Set

Response Time
<2 ms

Mounting Type
Flush or Non-flush, Threaded Body

Signal Type
Digital (NO/NC)

Cable Length
2 m

Features
LED Indication, Short-circuit Protection

Application
Position Sensing, Metal Detection

Wireless
No

IP Rating
IP67

Product Type
Proximity Sensor

Material
Metal/Plastic Housing

Input
12-24V DC

Output
NPN-NC

Function
Object Detection

Usage
Industrial Automation, Position Sensing

Accuracy
High

Resolution
1 mm

Voltage
12-24V DC

Weight
Approx. 100g

Protection Circuit
Reverse Polarity, Surge Protection

Housing Material
Nickel-plated Brass

Model Number
IS-N1812-BNCB2

Storage Temperature
-40C to +80C

Standards
CE Certified

Switching Frequency
500 Hz

Body Diameter
18 mm

Cable Type
PVC, Oil-Resistant

Sensing Face Diameter
12 mm

Humidity Range
35% to 95% RH (non-condensing)

Connection Type
Pre-wired (Flying lead)

About DELTA PROXIMITY SENSOR, 18MM DIA, SD 12MM, NPN-NC, IS-N1812-BNCB2

Discover the DELTA PROXIMITY SENSOR, model IS-N1812-BNCB2-offered at a Special Rate for a limited time only. This sensor is engineered for Optimum performance, featuring a robust 18 mm nickel-plated brass body, a 12 mm sensing face, and remarkable accuracy with 1 mm resolution. It offers noteworthy functions such as metal detection and high-sensitivity object detection. The reduced power consumption (max 15 mA) and oil-resistant, PVC cable ensure a long operational life. With its astonishing IP67 rating and comprehensive protection circuits, this device stands out as a special solution for industrial automation needs.

Why Choose DELTA PROXIMITY SENSOR?

The DELTA PROXIMITY SENSOR, IS-N1812-BNCB2, brings the advantage of high accuracy and stable sensitivity, ideal for demanding industrial conditions. Its flush or non-flush mounting flexibility allows versatile use types, including position sensing and metal detection. Trusted by automation professionals and manufacturers globally, this sensor's CE certification and durable construction ensure lasting performance even in challenging environments.

Export Excellence & Delivery Commitment

We serve Premium packaging for each DELTA PROXIMITY SENSOR, fully prepared for global export markets in Asia, Europe, and the Middle East. Products are promptly dispatched within the specified delivery time to main domestic markets across India. Our swift dispatch process and secure packaging guarantee the sensor arrives in optimum condition, reinforcing our steadfast commitment to customer satisfaction and timely service.

FAQ's of DELTA PROXIMITY SENSOR, 18MM DIA, SD 12MM, NPN-NC, IS-N1812-BNCB2:

Q: How does the DELTA PROXIMITY SENSOR enhance industrial automation processes?

A: The sensor delivers high accuracy, swift object detection, and stable performance, making it invaluable for position sensing and metal detection in automated manufacturing lines.

Q: What is the switching frequency and sensing range of this sensor?

A: It features a 500 Hz switching frequency and a sensing distance of 12 mm, ensuring reliable speed and detection accuracy.

Q: When should the DELTA IS-N1812-BNCB2 sensor be used?

A: This sensor is ideal for use when high-precision, contactless detection is required-particularly in environments demanding resilient performance and high durability.

Q: Where can this sensor be mounted?

A: The sensor supports both flush and non-flush mounting, accommodating various installation requirements in industrial setups.

Q: What makes the DELTA PROXIMITY SENSOR noteworthy in terms of protection and reliability?

A: It is engineered with reverse polarity and surge protection circuits, oil-resistant cable, short-circuit protection, and carries an IP67 rating, offering astonishing durability against water, dust, and harsh industrial conditions.
